UFW - allow range of IP addresees?

I can add a rule using UFW firewall to allow a single known IP 192.168.1.32 to access my test webserver (192.168.1.48 (on a local mostly trusted network) on Ubuntu 14.04 using:

sudo ufw allow proto tcp from 192.168.1.23 to 192.168.1.48 port 80

Is there a way I can add a range of addressees (e.g. 192.168.1.30-192.168.1.50 to allow more machines on my current network)? Using 192.168.1.30-192.168.1.50 and 192.168.1.30-192.168.1.50 don't work and results in ERROR: Bad source address.

3 Answers

You need to use a binary number (2,4,8,16, 32) so either you use a bigger or a smaller range. Exactly 20 hosts just is not possible with a bitmask in a single rule:

• 16 hosts (192.168.1.16 to 192.168.1.31):

  sudo ufw allow proto tcp from 192.168.1.16/28 to 192.168.1.48 port 80

  Details

  Address: 192.168.1.16 11000000.10101000.00000001.0001 0000 Rule Mask: 255.255.255.240 = 28 11111111.11111111.11111111.1111 0000 Wildcard: 0.0.0.15 00000000.00000000.00000000.0000 1111 HostMin: 192.168.1.16 11000000.10101000.00000001.0001 0000 HostMax: 192.168.1.31 11000000.10101000.00000001.0000 1111

• 32 hosts (192.168.1.0 - 192.168.1.31)

  sudo ufw allow proto tcp from 192.168.1.0/27 to 192.168.1.48 port 80

  Details

  Address: 192.168.1.0 11000000.10101000.00000001.000 00000 Rule Mask: 255.255.255.224 = 27 11111111.11111111.11111111.111 00000 Wildcard: 0.0.0.31 00000000.00000000.00000000.000 11111 HostMin: 192.168.1.0 11000000.10101000.00000001.000 00000 HostMax: 192.168.1.31 11000000.10101000.00000001.000 11111

• 64 hosts (192.168.1.0 - 192.168.1.63)

  sudo ufw allow proto tcp from 192.168.1.0/26 to 192.168.1.48 port 80

  Details

  Address: 192.168.1.0 11000000.10101000.00000001.00 000000 Rule Mask: 255.255.255.192 = 26 11111111.11111111.11111111.11 000000 Wildcard: 0.0.0.63 00000000.00000000.00000000.00 111111 HostMin: 192.168.1.0 11000000.10101000.00000001.00 000000 HostMax: 192.168.1.63 11000000.10101000.00000001.00 111111

Explanation

I can't give a better explanation than wikipedia

Allow Incoming from Specific IP Address or Subnet To allow incoming connections from a specific IP address or subnet, specify the source. For example, run this command:

sudo ufw allow from 192.168.1.0/24 to any port 22

OR

sudo ufw allow from 192.168.1.0/24 to 192.168.1.48 port 80

I like this

sudo ufw allow from 192.168.1.0/24 to any port 22

I use ufw all the time, I like the numbering scheme as well which helps me keep track of the packet flow:

sudo ufw insert 1 allow in proto tcp from 192.168.1.0/24 to any port 22 comment "SSH Network Connection"
