I have a table like that which i fill with a data

<table > <thead> <tr> <th>Product (Parent Product)</th> <th>Associated Sites</th> <th>Actions</th> </tr> </thead> <tbody> @for (int i = 0; i < Model.Count(); i++) { <tr> <td> <a href="Edit"><strong>@Model.ElementAt(i).Name</strong></a><br /> </td> <td> <span></span> </td> <td>@Html.ActionLink("Edit Product", "Edit", "Products")<br /> @Html.ActionLink("Associate Site", "Associate", "Products") </td> </tr> } <tr> </tbody> </table>

and CSS like that

 #products-table { width: 200px; height: 400px; overflow:scroll; }

but scroll doesn't work, I want to fix the height of the table and if it exceeds, then work with scrollbar

1

9 Answers

Table with Fixed Header

<table cellspacing="0" cellpadding="0" border="0" width="325"> <tr> <td> <table cellspacing="0" cellpadding="1" border="1" width="300" > <tr> <th>Header 1</th> <th>Header 2</th> </tr> </table> </td> </tr> <tr> <td> <div> <table cellspacing="0" cellpadding="1" border="1" width="300" > <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> <tr> <td>new item</td> <td>new item</td> </tr> </table> </div> </td> </tr> </table>

Result

Demo Image

This is working in all browser

Demo jsfiddle

7

Late answer, another idea, but very short.

  1. put the contents of header cells into div
  2. fix the header contents, see CSS
table { margin-top: 20px; display: inline-block; overflow: auto; } th div { margin-top: -20px; position: absolute; }

Note that it is possible to display table as inline-block due to anonymous table objects:

"missing" [in HTML table tree structure] elements must be assumed in order for the table model to work. Any table element will automatically generate necessary anonymous table objects around itself.

/* scrolltable rules */ table { margin-top: 20px; display: inline-block; overflow: auto; } th div { margin-top: -20px; position: absolute; } /* design */ table { border-collapse: collapse; } tr:nth-child(even) { background: #EEE; }
<table> <tr> <th><div>first</div> <th><div>second</div> <tr> <td>foo <td>bar <tr> <td>foo foo foo foo foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar bar bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar <tr> <td>foo <td>bar </table>

As of 2016

The proper way to achieve this is position: sticky - see the demo in the link.

1

For those wondering how to implement Garry's solution with more than one header this is it:

#wrapper { width: 235px; } table { border: 1px solid black; width: 100%; } th, td { width: 100px; border: 1px solid black; } thead>tr { position: relative; display: block; } tbody { display: block; height: 80px; overflow: auto; }
<div> <table> <thead> <tr> <th>column1</th> <th>column2</th> </tr> </thead> <tbody> <tr> <td>row1</td> <td>row1</td> </tr> <tr> <td>row2</td> <td>row2</td> </tr> <tr> <td>row3</td> <td>row3</td> </tr> <tr> <td>row4</td> <td>row4</td> </tr> </tbody> </table> </div>

Works only in Chrome but it can be adapted to other modern browsers. Table falls back to common table with scroll bar in other brws. Uses CSS3 FLEX property.

<table border="1px"> <caption>Lista Sumnjivih vozila:</caption> <thead> <tr> <td>Opis Sumnje</td> <td>Registarski<br>broj vozila</td> <td>Datum<br>Vreme</td> <td>Brzina<br>(km/h)</td> <td>Lokacija</td> <td>Status</td> <td>Akcija</td> </tr> </thead> <tbody> <tr> <td>Osumnjičen tranzit</td> <td>NS182TP</td> <td>23-03-2014 20:48:08</td> <td>11.3</td> <td>Raskrsnica kod pumpe<br></td> <td></td> <td>Prikaz</td> </tr> <tr> <tr> <td>Osumnjičen tranzit</td> <td>NS182TP</td> <td>23-03-2014 20:48:08</td> <td>11.3</td> <td>Raskrsnica kod pumpe<br></td> <td></td> <td>Prikaz</td> </tr> <tr> <tr> <td>Osumnjičen tranzit</td> <td>NS182TP</td> <td>23-03-2014 20:48:08</td> <td>11.3</td> <td>Raskrsnica kod pumpe<br></td> <td></td> <td>Prikaz</td> </tr> <tr> <tr> <td>Osumnjičen tranzit</td> <td>NS182TP</td> <td>23-03-2014 20:48:08</td> <td>11.3</td> <td>Raskrsnica kod pumpe<br></td> <td></td> <td>Prikaz</td> </tr> </tbody> </table>

Style (CSS 3):

caption { display: block; line-height: 3em; width: 100%; -webkit-align-items: stretch; border: 1px solid #eee; } .flexy { display: block; width: 90%; border: 1px solid #eee; max-height: 320px; overflow: auto; } .flexy thead { display: -webkit-flex; -webkit-flex-flow: row; } .flexy thead tr { padding-right: 15px; display: -webkit-flex; width: 100%; -webkit-align-items: stretch; } .flexy tbody { display: -webkit-flex; height: 100px; overflow: auto; -webkit-flex-flow: row wrap; } .flexy tbody tr{ display: -webkit-flex; width: 100%; } .flexy tr td { width: 15%; }

This work for me

Demo: jsfiddle

$(function() { Fixed_Header(); });
function Fixed_Header() { $('.User_Table thead').css({'position': 'absolute'}); $('.User_Table tbody tr:eq("2") td').each(function(index,e){ $('.User_Table thead tr th:eq("'+index+'")').css({'width' : $(this).outerWidth() +"px" }); }); var Header_Height = $('.User_Table thead').outerHeight(); $('.User_Table thead').css({'margin-top' : "-"+Header_Height+"px"}); $('.User_Table').css({'margin-top' : Header_Height+"px"}); }
<div> <table></table> </div>

Try this code for overflow table it will work only on div tag

 .outer { overflow-y: auto; height: 300px; } .outer { width: 100%; -layout: fixed; } .outer th { text-align: left; top: 0; position: sticky; background-color: white; }
<!DOCTYPE html> <html lang="en"> <head> <meta charset="UTF-8"> <meta name="viewport" content="width=device-width, initial-scale=1.0"> <meta http-equiv="X-UA-Compatible" content="ie=edge"> <title>MYCRUD</title> <link rel="stylesheet" href="" integrity="sha384-lZN37f5QGtY3VHgisS14W3ExzMWZxybE1SJSEsQp9S+oqd12jhcu+A56Ebc1zFSJ" crossorigin="anonymous"> <link rel="stylesheet" href="" integrity="sha384-ggOyR0iXCbMQv3Xipma34MD+dH/1fQ784/j6cY/iJTQUOhcWr7x9JvoRxT2MZw1T" crossorigin="anonymous"> </head> <body> <div> <div> <div> <div> <div> <table> <thead> <tr> <th scope="col">ID</th> <th scope="col">Marca</th> <th scope="col">Editar</th> <th scope="col">Eliminar</th> </tr> </thead> <tbody> <tr> <td>4</td> <td>Toyota</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>3</td> <td>Honda </td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>5</td> <td>Myo</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>6</td> <td>Acer</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>7</td> <td>HP</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>8</td> <td>DELL</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> <tr> <td>9</td> <td>LOGITECH</td> <td> <a href="#"> <i></i> </a> </td> <td> <a href="#"> <i></i> </a> </td> </tr> </tbody> </table> </div> </div> </div> </div> </div> </body> </html>
1

Adds a fading gradient to an overflowing HTML table element to better indicate there is more content to be scrolled.

  • Table with fixed header
  • Overflow scroll gradient
  • Custom scrollbar

See the live example below:

$("#scrolltable").html("<table id='cell'><tbody></tbody></table>"); $("#cell").append("<thead><tr><th><div>First col</div></th><th><div>Second col</div></th></tr></thead>"); for (var i = 0; i < 40; i++) { $("#scrolltable > table > tbody").append("<tr><td>" + "foo" + "</td><td>" + "bar" + "</td></tr>"); }
/* Table with fixed header */ table, thead { width: 100%; text-align: left; } #scrolltable { margin-top: 50px; height: 120px; overflow: auto; width: 200px; } #scrolltable table { border-collapse: collapse; } #scrolltable tr:nth-child(even) { background: #EEE; } #scrolltable th div { position: absolute; margin-top: -30px; } /* Custom scrollbar */ ::-webkit-scrollbar { width: 8px; } ::-webkit-scrollbar-track { box-shadow: inset 0 0 6px rgba(0, 0, 0, 0.3); border-radius: 10px; } ::-webkit-scrollbar-thumb { border-radius: 10px; box-shadow: inset 0 0 6px rgba(0, 0, 0, 0.5); } /* Overflow scroll gradient */ .overflow-scroll-gradient { position: relative; } .overflow-scroll-gradient::after { content: ''; position: absolute; bottom: 0; width: 240px; height: 25px; background: linear-gradient( rgba(255, 255, 255, 0.001), white); pointer-events: none; }
<script src=""></script> <div> <div> </div> </div>

For whatever it's worth now: here is yet another solution:

  • create two divs within a display: inline-block
  • in the first div, put a table with only the header (header table tabhead)
  • in the 2nd div, put a table with header and data (data table / full table tabfull)
  • use JavaScript, use setTimeout(() => {/*...*/}) to execute code after render / after filling the table with results from fetch
  • measure the width of each th in the data table (using clientWidth)
  • apply the same width to the counterpart in the header table
  • set visibility of the header of the data table to hidden and set the margin top to -1 * height of data table thead pixels

With a few tweaks, this is the method to use (for brevity / simplicity, I used d3js, the same operations can be done using plain DOM):

setTimeout(() => { // pass one cycle d3.select('#tabfull') .style('margin-top', (-1 * d3.select('#tabscroll').select('thead').node().getBoundingClientRect().height) + 'px') .select('thead') .style('visibility', 'hidden'); let widths=[]; // really rely on COMPUTED values d3.select('#tabfull').select('thead').selectAll('th') .each((n, i, nd) => widths.push(nd[i].clientWidth)); d3.select('#tabhead').select('thead').selectAll('th') .each((n, i, nd) => d3.select(nd[i]) .style('padding-right', 0) .style('padding-left', 0) .style('width', widths[i]+'px')); })

Waiting on render cycle has the advantage of using the browser layout engine thoughout the process - for any type of header; it's not bound to special condition or cell content lengths being somehow similar. It also adjusts correctly for visible scrollbars (like on Windows)

I've put up a codepen with a full example here:
