i have 1 client (Windows OS) and 4 VPS (Linux OS) .
i want create Socks v5 proxy with ssh tunnel for connect client to VPS-4 .
client -> VPS-1 -> VPS-2 -> VPS-3 -> VPS-4 -> internet
in client with CMD i connect to VPS-1 with command :
ssh -L9999:localhost:9999 root@VPS-1-IPaddress inside VPS-1 ssh window : for connect VPS-1 to VPS-2 i use command
ssh -Dlocalhost:9999 root@VPS-2-IPaddress and inside VPS-2 ssh window : for connect VPS-2 to VPS-3 i use command
ssh -Dlocalhost:9999 root@VPS-3-IPaddress and inside VPS-3 ssh window : for connect VPS-3 to VPS-4 i use command
ssh -Dlocalhost:9999 root@VPS-4-IPaddress when i set "localhost" and port "9999" in browser proxy setting and open website whatismyipaddress i see VPS-2 IP address .
i must see VPS-4 IP address . i don't know what is problem .
anyone can advise me ?
1 Answer
Too much manual work.
When using a ~/.ssh/config file
HOST VPS-4-IPaddress user root ProxyJump VPS-3-IPaddress HOST VPS-3-IPaddress user root ProxyJump VPS-2-IPaddress HOST VPS-2-IPaddress user root ProxyJump VPS-1-IPaddress HOST VPS-1-IPaddress user root ProxyJump VPS-2-IPaddress It's also possible to chain the proxies in one line
HOST VPS-4-IPaddress user root ProxyJump VPS-1-IPaddress,VPS-2-IPaddress,VPS-3-IPaddress Then you can use
ssh -D9999 root@VPS-4-IPaddress Or without a .ssh/config file, directly on the command line (-J is equal to -o ProxyJump=)
ssh -D9999 VPS-4-IPaddress -J VPS-1-IPaddress,VPS-2-IPaddress,VPS-3-IPaddress The manual way
You need to build local forwards from one machine to the next one.
The socks proxy will only be defined on the last one.
Client:> ssh -L9999:localhost:9999 root@VPS-1-IPaddress
VPS-1:> ssh -L9999:localhost:9999 root@VPS-2-IPaddress
VPS-2:> ssh -L9999:localhost:9999 root@VPS-3-IPaddress
VPS-3:> ssh -D9999 root@VPS-4-IPaddress
But the tunnel is more or less the same like the automatic variant.
