I am currently writing my thesis in greek and whenever I try to reference a figure I get the following in my text:
[;;]
This is the code I wrote:
\begin{figure}[h] \label{ fig:image1} \includegraphics[width=1\textwidth]{image1} \caption{Απεικόνιση τρόπου κληρονομικότητας} \end{figure} And I call the ref by writing: {\ref{fig:{image1}}.
How do I fix this?
1 Answer
There is a simple rule in latex \caption should always come before \label [1]. So the code you write becomes:
\begin{figure}[h] \includegraphics[width=1\textwidth]{image1} \caption{Απεικόνιση τρόπου κληρονομικότητας} \label{fig:image1} \end{figure} Also, you were referring to the image incorrectly. and you can refer it using \ref{fig:image1} to get the correct reference.
This will work well, as the key you use for \label is the key you use for \ref.
