I have been looking at CROSS / OUTER APPLY with a colleague and we're struggling to find real life examples of where to use them.
I've spent quite a lot of time looking at When should I use Cross Apply over Inner Join? and googling but the main (only) example seems pretty bizarre (using the rowcount from a table to determine how many rows to select from another table).
I thought this scenario may benefit from OUTER APPLY:
Contacts Table (contains 1 record for each contact) Communication Entries Table (can contain n phone, fax, email fro each contact)
But using subqueries, common table expressions, OUTER JOIN with RANK() and OUTER APPLY all seem to perform equally. I'm guessing this means the scenario isn't applicable to APPLY.
Please share some real life examples and help explain the feature!
54 Answers
Some uses for APPLY are...
1) Top N per group queries (can be more efficient for some cardinalities)
SELECT pr.name, pa.name FROM sys.procedures pr OUTER APPLY (SELECT TOP 2 * FROM sys.parameters pa WHERE pa.object_id = pr.object_id ORDER BY pr.name) pa ORDER BY pr.name, pa.name 2) Calling a Table Valued Function for each row in the outer query
SELECT * FROM sys.dm_exec_query_stats AS qs CROSS APPLY sys.dm_exec_query_plan(qs.plan_handle) SELECT number, doubled_number, doubled_number_plus_one FROM master..spt_values CROSS APPLY (SELECT 2 * CAST(number AS BIGINT)) CA1(doubled_number) CROSS APPLY (SELECT doubled_number + 1) CA2(doubled_number_plus_one) 4) Unpivoting more than one group of columns
Assumes 1NF violating table structure....
CREATE TABLE T ( Id INT PRIMARY KEY, Foo1 INT, Foo2 INT, Foo3 INT, Bar1 INT, Bar2 INT, Bar3 INT ); Example using 2008+ VALUES syntax.
SELECT Id, Foo, Bar FROM T CROSS APPLY (VALUES(Foo1, Bar1), (Foo2, Bar2), (Foo3, Bar3)) V(Foo, Bar); In 2005 UNION ALL can be used instead.
SELECT Id, Foo, Bar FROM T CROSS APPLY (SELECT Foo1, Bar1 UNION ALL SELECT Foo2, Bar2 UNION ALL SELECT Foo3, Bar3) V(Foo, Bar); There are various situations where you cannot avoid CROSS APPLY or OUTER APPLY.
Consider you have two tables.
MASTER TABLE
x------x--------------------x | Id | Name | x------x--------------------x | 1 | A | | 2 | B | | 3 | C | x------x--------------------x DETAILS TABLE
x------x--------------------x-------x | Id | PERIOD | QTY | x------x--------------------x-------x | 1 | 2014-01-13 | 10 | | 1 | 2014-01-11 | 15 | | 1 | 2014-01-12 | 20 | | 2 | 2014-01-06 | 30 | | 2 | 2014-01-08 | 40 | x------x--------------------x-------x CROSS APPLY
There are many situation where we need to replace INNER JOIN with CROSS APPLY.
1. If we want to join 2 tables on TOP n results with INNER JOIN functionality
Consider if we need to select Id and Name from Master and last two dates for each Id from Details table.
SELECT M.ID,M.NAME,D.PERIOD,D.QTY FROM MASTER M INNER JOIN ( SELECT TOP 2 ID, PERIOD,QTY FROM DETAILS D ORDER BY CAST(PERIOD AS DATE)DESC )D ON M.ID=D.ID The above query generates the following result.
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-12 | 20 | x------x---------x--------------x-------x See, it generated results for last two dates with last two date's Id and then joined these records only in outer query on Id, which is wrong. To accomplish this, we need to use CROSS APPLY.
SELECT M.ID,M.NAME,D.PERIOD,D.QTY FROM MASTER M CROSS APPLY ( SELECT TOP 2 ID, PERIOD,QTY FROM DETAILS D WHERE M.ID=D.ID ORDER BY CAST(PERIOD AS DATE)DESC )D and forms he following result.
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-12 | 20 | | 2 | B | 2014-01-08 | 40 | | 2 | B | 2014-01-06 | 30 | x------x---------x--------------x-------x Here is the working. The query inside CROSS APPLY can reference the outer table, where INNER JOIN cannot do this(throws compile error). When finding the last two dates, joining is done inside CROSS APPLY ie, WHERE M.ID=D.ID.
2. When we need INNER JOIN functionality using functions.
CROSS APPLY can be used as a replacement with INNER JOIN when we need to get result from Master table and a function.
SELECT M.ID,M.NAME,C.PERIOD,C.QTY FROM MASTER M CROSS APPLY dbo.FnGetQty(M.ID) C And here is the function
CREATE FUNCTION FnGetQty ( @Id INT ) RETURNS TABLE AS RETURN ( SELECT ID,PERIOD,QTY FROM DETAILS WHERE ID=@Id ) which generated the following result
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-11 | 15 | | 1 | A | 2014-01-12 | 20 | | 2 | B | 2014-01-06 | 30 | | 2 | B | 2014-01-08 | 40 | x------x---------x--------------x-------x OUTER APPLY
1. If we want to join 2 tables on TOP n results with LEFT JOIN functionality
Consider if we need to select Id and Name from Master and last two dates for each Id from Details table.
SELECT M.ID,M.NAME,D.PERIOD,D.QTY FROM MASTER M LEFT JOIN ( SELECT TOP 2 ID, PERIOD,QTY FROM DETAILS D ORDER BY CAST(PERIOD AS DATE)DESC )D ON M.ID=D.ID which forms the following result
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-12 | 20 | | 2 | B | NULL | NULL | | 3 | C | NULL | NULL | x------x---------x--------------x-------x This will bring wrong results ie, it will bring only latest two dates data from Details table irrespective of Id even though we join with Id. So the proper solution is using OUTER APPLY.
SELECT M.ID,M.NAME,D.PERIOD,D.QTY FROM MASTER M OUTER APPLY ( SELECT TOP 2 ID, PERIOD,QTY FROM DETAILS D WHERE M.ID=D.ID ORDER BY CAST(PERIOD AS DATE)DESC )D which forms the following desired result
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-12 | 20 | | 2 | B | 2014-01-08 | 40 | | 2 | B | 2014-01-06 | 30 | | 3 | C | NULL | NULL | x------x---------x--------------x-------x 2. When we need LEFT JOIN functionality using functions.
OUTER APPLY can be used as a replacement with LEFT JOIN when we need to get result from Master table and a function.
SELECT M.ID,M.NAME,C.PERIOD,C.QTY FROM MASTER M OUTER APPLY dbo.FnGetQty(M.ID) C And the function goes here.
CREATE FUNCTION FnGetQty ( @Id INT ) RETURNS TABLE AS RETURN ( SELECT ID,PERIOD,QTY FROM DETAILS WHERE ID=@Id ) which generated the following result
x------x---------x--------------x-------x | Id | Name | PERIOD | QTY | x------x---------x--------------x-------x | 1 | A | 2014-01-13 | 10 | | 1 | A | 2014-01-11 | 15 | | 1 | A | 2014-01-12 | 20 | | 2 | B | 2014-01-06 | 30 | | 2 | B | 2014-01-08 | 40 | | 3 | C | NULL | NULL | x------x---------x--------------x-------x Common feature of
CROSS APPLYandOUTER APPLY
CROSS APPLY or OUTER APPLY can be used to retain NULL values when unpivoting, which are interchangeable.
Consider you have the below table
x------x-------------x--------------x | Id | FROMDATE | TODATE | x------x-------------x--------------x | 1 | 2014-01-11 | 2014-01-13 | | 1 | 2014-02-23 | 2014-02-27 | | 2 | 2014-05-06 | 2014-05-30 | | 3 | NULL | NULL | x------x-------------x--------------x When you use UNPIVOT to bring FROMDATE AND TODATE to one column, it will eliminate NULL values by default.
SELECT ID,DATES FROM MYTABLE UNPIVOT (DATES FOR COLS IN (FROMDATE,TODATE)) P which generates the below result. Note that we have missed the record of Id number 3
x------x-------------x | Id | DATES | x------x-------------x | 1 | 2014-01-11 | | 1 | 2014-01-13 | | 1 | 2014-02-23 | | 1 | 2014-02-27 | | 2 | 2014-05-06 | | 2 | 2014-05-30 | x------x-------------x In such cases a CROSS APPLY or OUTER APPLY will be useful
SELECT DISTINCT ID,DATES FROM MYTABLE OUTER APPLY(VALUES (FROMDATE),(TODATE)) COLUMNNAMES(DATES) which forms the following result and retains Id where its value is 3
x------x-------------x | Id | DATES | x------x-------------x | 1 | 2014-01-11 | | 1 | 2014-01-13 | | 1 | 2014-02-23 | | 1 | 2014-02-27 | | 2 | 2014-05-06 | | 2 | 2014-05-30 | | 3 | NULL | x------x-------------x One real life example would be if you had a scheduler and wanted to see what the most recent log entry was for each scheduled task.
select t.taskName, lg.logResult, lg.lastUpdateDate from task t cross apply (select top 1 taskID, logResult, lastUpdateDate from taskLog l where l.taskID = t.taskID order by lastUpdateDate desc) lg To answer the point above knock up an example:
create table #task (taskID int identity primary key not null, taskName varchar(50) not null) create table #log (taskID int not null, reportDate datetime not null, result varchar(50) not null, primary key(reportDate, taskId)) insert #task select 'Task 1' insert #task select 'Task 2' insert #task select 'Task 3' insert #task select 'Task 4' insert #task select 'Task 5' insert #task select 'Task 6' insert #log select taskID, 39951 + number, 'Result text...' from #task cross join ( select top 1000 row_number() over (order by a.id) as number from syscolumns a cross join syscolumns b cross join syscolumns c) n And now run the two queries with a execution plan.
select t.taskID, t.taskName, lg.reportDate, lg.result from #task t left join (select taskID, reportDate, result, rank() over (partition by taskID order by reportDate desc) rnk from #log) lg on lg.taskID = t.taskID and lg.rnk = 1 select t.taskID, t.taskName, lg.reportDate, lg.result from #task t outer apply ( select top 1 l.* from #log l where l.taskID = t.taskID order by reportDate desc) lg You can see that the outer apply query is more efficient. (Couldn't attach the plan as I'm a new user... Doh.)
