I'm doing a Python project in which I'd like to use the Viterbi Algorithm. Does anyone know of a complete Python implementation of the Viterbi algorithm? The correctness of the one on Wikipedia seems to be in question on the talk page. Does anyone have a pointer?

0

6 Answers

Here's mine. Its paraphrased directly from the psuedocode implemenation from wikipedia. It uses numpy for conveince of their ndarray but is otherwise a pure python3 implementation.

import numpy as np def viterbi(y, A, B, Pi=None): """ Return the MAP estimate of state trajectory of Hidden Markov Model. Parameters ---------- y : array (T,) Observation state sequence. int dtype. A : array (K, K) State transition matrix. See HiddenMarkovModel.state_transition for details. B : array (K, M) Emission matrix. See HiddenMarkovModel.emission for details. Pi: optional, (K,) Initial state probabilities: Pi[i] is the probability x[0] == i. If None, uniform initial distribution is assumed (Pi[:] == 1/K). Returns ------- x : array (T,) Maximum a posteriori probability estimate of hidden state trajectory, conditioned on observation sequence y under the model parameters A, B, Pi. T1: array (K, T) the probability of the most likely path so far T2: array (K, T) the x_j-1 of the most likely path so far """ # Cardinality of the state space K = A.shape[0] # Initialize the priors with default (uniform dist) if not given by caller Pi = Pi if Pi is not None else np.full(K, 1 / K) T = len(y) T1 = np.empty((K, T), 'd') T2 = np.empty((K, T), 'B') # Initilaize the tracking tables from first observation T1[:, 0] = Pi * B[:, y[0]] T2[:, 0] = 0 # Iterate throught the observations updating the tracking tables for i in range(1, T): T1[:, i] = np.max(T1[:, i - 1] * A.T * B[np.newaxis, :, y[i]].T, 1) T2[:, i] = np.argmax(T1[:, i - 1] * A.T, 1) # Build the output, optimal model trajectory x = np.empty(T, 'B') x[-1] = np.argmax(T1[:, T - 1]) for i in reversed(range(1, T)): x[i - 1] = T2[x[i], i] return x, T1, T2
2

I found the following code in the example repository of Artificial Intelligence: A Modern Approach. Is something like this what you're looking for?

def viterbi_segment(text, P): """Find the best segmentation of the string of characters, given the UnigramTextModel P.""" # best[i] = best probability for text[0:i] # words[i] = best word ending at position i n = len(text) words = [''] + list(text) best = [1.0] + [0.0] * n ## Fill in the vectors best, words via dynamic programming for i in range(n+1): for j in range(0, i): w = text[j:i] if P[w] * best[i - len(w)] >= best[i]: best[i] = P[w] * best[i - len(w)] words[i] = w ## Now recover the sequence of best words sequence = []; i = len(words)-1 while i > 0: sequence[0:0] = [words[i]] i = i - len(words[i]) ## Return sequence of best words and overall probability return sequence, best[-1]
0

Hmm I can post mine. Its not pretty though, please let me know if you need clarification. I wrote this relatively recently for specifically part of speech tagging.

class Trellis: trell = [] def __init__(self, hmm, words): self.trell = [] temp = {} for label in hmm.labels: temp[label] = [0,None] for word in words: self.trell.append([word,copy.deepcopy(temp)]) self.fill_in(hmm) def fill_in(self,hmm): for i in range(len(self.trell)): for token in self.trell[i][1]: word = self.trell[i][0] if i == 0: self.trell[i][1][token][0] = hmm.e(token,word) else: max = None guess = None c = None for k in self.trell[i-1][1]: c = self.trell[i-1][1][k][0] + hmm.t(k,token) if max == None or c > max: max = c guess = k max += hmm.e(token,word) self.trell[i][1][token][0] = max self.trell[i][1][token][1] = guess def return_max(self): tokens = [] token = None for i in range(len(self.trell)-1,-1,-1): if token == None: max = None guess = None for k in self.trell[i][1]: if max == None or self.trell[i][1][k][0] > max: max = self.trell[i][1][k][0] token = self.trell[i][1][k][1] guess = k tokens.append(guess) else: tokens.append(token) token = self.trell[i][1][token][1] tokens.reverse() return tokens
4

I have just corrected the pseudo implementation of Viterbi in Wikipedia. From the initial (incorrect) version, it took me a while to figure out where I was going wrong but I finally managed it, thanks partly to Kevin Murphy's implementation of the viterbi_path.m in the MatLab HMM toolbox.

In the context of an HMM object with variables as shown:

hmm = HMM() hmm.priors = np.array([0.5, 0.5]) # pi = prior probs hmm.transition = np.array([[0.75, 0.25], # A = transition probs. / 2 states [0.32, 0.68]]) hmm.emission = np.array([[0.8, 0.1, 0.1], # B = emission (observation) probs. / 3 obs modes [0.1, 0.2, 0.7]])

The Python function to run Viterbi (best-path) algorithm is below:

def viterbi (self,observations): """Return the best path, given an HMM model and a sequence of observations""" # A - initialise stuff nSamples = len(observations[0]) nStates = self.transition.shape[0] # number of states c = np.zeros(nSamples) #scale factors (necessary to prevent underflow) viterbi = np.zeros((nStates,nSamples)) # initialise viterbi table psi = np.zeros((nStates,nSamples)) # initialise the best path table best_path = np.zeros(nSamples); # this will be your output # B- appoint initial values for viterbi and best path (bp) tables - Eq (32a-32b) viterbi[:,0] = self.priors.T * self.emission[:,observations(0)] c[0] = 1.0/np.sum(viterbi[:,0]) viterbi[:,0] = c[0] * viterbi[:,0] # apply the scaling factor psi[0] = 0; # C- Do the iterations for viterbi and psi for time>0 until T for t in range(1,nSamples): # loop through time for s in range (0,nStates): # loop through the states @(t-1) trans_p = viterbi[:,t-1] * self.transition[:,s] psi[s,t], viterbi[s,t] = max(enumerate(trans_p), key=operator.itemgetter(1)) viterbi[s,t] = viterbi[s,t]*self.emission[s,observations(t)] c[t] = 1.0/np.sum(viterbi[:,t]) # scaling factor viterbi[:,t] = c[t] * viterbi[:,t] # D - Back-tracking best_path[nSamples-1] = viterbi[:,nSamples-1].argmax() # last state for t in range(nSamples-1,0,-1): # states of (last-1)th to 0th time step best_path[t-1] = psi[best_path[t],t] return best_path
3

This is an old question, but none of the other answers were quite what I needed because my application doesn't have specific observed states.

Taking after @Rhubarb, I've also re-implemented Kevin Murphey's Matlab implementation (see viterbi_path.m), but I've kept it closer to the original. I've included a simple test case as well.

import numpy as np def viterbi_path(prior, transmat, obslik, scaled=True, ret_loglik=False): '''Finds the most-probable (Viterbi) path through the HMM state trellis Notation: Z[t] := Observation at time t Q[t] := Hidden state at time t Inputs: prior: np.array(num_hid) prior[i] := Pr(Q[0] == i) transmat: np.ndarray((num_hid,num_hid)) transmat[i,j] := Pr(Q[t+1] == j | Q[t] == i) obslik: np.ndarray((num_hid,num_obs)) obslik[i,t] := Pr(Z[t] | Q[t] == i) scaled: bool whether or not to normalize the probability trellis along the way doing so prevents underflow by repeated multiplications of probabilities ret_loglik: bool whether or not to return the log-likelihood of the best path Outputs: path: np.array(num_obs) path[t] := Q[t] ''' num_hid = obslik.shape[0] # number of hidden states num_obs = obslik.shape[1] # number of observations (not observation *states*) # trellis_prob[i,t] := Pr((best sequence of length t-1 goes to state i), Z[1:(t+1)]) trellis_prob = np.zeros((num_hid,num_obs)) # trellis_state[i,t] := best predecessor state given that we ended up in state i at t trellis_state = np.zeros((num_hid,num_obs), dtype=int) # int because its elements will be used as indicies path = np.zeros(num_obs, dtype=int) # int because its elements will be used as indicies trellis_prob[:,0] = prior * obslik[:,0] # element-wise mult if scaled: scale = np.ones(num_obs) # only instantiated if necessary to save memory scale[0] = 1.0 / np.sum(trellis_prob[:,0]) trellis_prob[:,0] *= scale[0] trellis_state[:,0] = 0 # arbitrary value since t == 0 has no predecessor for t in xrange(1, num_obs): for j in xrange(num_hid): trans_probs = trellis_prob[:,t-1] * transmat[:,j] # element-wise mult trellis_state[j,t] = trans_probs.argmax() trellis_prob[j,t] = trans_probs[trellis_state[j,t]] # max of trans_probs trellis_prob[j,t] *= obslik[j,t] if scaled: scale[t] = 1.0 / np.sum(trellis_prob[:,t]) trellis_prob[:,t] *= scale[t] path[-1] = trellis_prob[:,-1].argmax() for t in range(num_obs-2, -1, -1): path[t] = trellis_state[(path[t+1]), t+1] if not ret_loglik: return path else: if scaled: loglik = -np.sum(np.log(scale)) else: p = trellis_prob[path[-1],-1] loglik = np.log(p) return path, loglik if __name__=='__main__': # Assume there are 3 observation states, 2 hidden states, and 5 observations priors = np.array([0.5, 0.5]) transmat = np.array([ [0.75, 0.25], [0.32, 0.68]]) emmat = np.array([ [0.8, 0.1, 0.1], [0.1, 0.2, 0.7]]) observations = np.array([0, 1, 2, 1, 0], dtype=int) obslik = np.array([emmat[:,z] for z in observations]).T print viterbi_path(priors, transmat, obslik) #=> [0 1 1 1 0] print viterbi_path(priors, transmat, obslik, scaled=False) #=> [0 1 1 1 0] print viterbi_path(priors, transmat, obslik, ret_loglik=True) #=> (array([0, 1, 1, 1, 0]), -7.776472586614755) print viterbi_path(priors, transmat, obslik, scaled=False, ret_loglik=True) #=> (array([0, 1, 1, 1, 0]), -8.0120386579275227)

Note that this implementation does not use emission probabilities directly but uses a variable obslik. Generally, emissions[i,j] := Pr(observed_state == j | hidden_state == i) for a particular observed state i, making emissions.shape == (num_hidden_states, num_obs_states).

However, given a sequence observations[t] := observation at time t, all the Viterbi Algorithm requires is the likelihood of that observation for each hidden state. Hence, obslik[i,t] := Pr(observations[t] | hidden_state == i). The actual value the of the observed state isn't necessary.

0

I have modified @Rhubarb's answer for the condition where the marginal probabilities are already known (e.g by computing the Forward Backward algorithm).

def viterbi (transition_probabilities, conditional_probabilities): # Initialise everything num_samples = conditional_probabilities.shape[1] num_states = transition_probabilities.shape[0] # number of states c = np.zeros(num_samples) #scale factors (necessary to prevent underflow) viterbi = np.zeros((num_states,num_samples)) # initialise viterbi table best_path_table = np.zeros((num_states,num_samples)) # initialise the best path table best_path = np.zeros(num_samples).astype(np.int32) # this will be your output # B- appoint initial values for viterbi and best path (bp) tables - Eq (32a-32b) viterbi[:,0] = conditional_probabilities[:,0] c[0] = 1.0/np.sum(viterbi[:,0]) viterbi[:,0] = c[0] * viterbi[:,0] # apply the scaling factor # C- Do the iterations for viterbi and psi for time>0 until T for t in range(1, num_samples): # loop through time for s in range (0,num_states): # loop through the states @(t-1) trans_p = viterbi[:, t-1] * transition_probabilities[:,s] # transition probs of each state transitioning best_path_table[s,t], viterbi[s,t] = max(enumerate(trans_p), key=operator.itemgetter(1)) viterbi[s,t] = viterbi[s,t] * conditional_probabilities[s][t] c[t] = 1.0/np.sum(viterbi[:,t]) # scaling factor viterbi[:,t] = c[t] * viterbi[:,t] ## D - Back-tracking best_path[num_samples-1] = viterbi[:,num_samples-1].argmax() # last state for t in range(num_samples-1,0,-1): # states of (last-1)th to 0th time step best_path[t-1] = best_path_table[best_path[t],t] return best_path
