Nginx proxy_pass to https

we have: Ubuntu 16.04
nginx 1.10.3

i am new to nginx and need help on proxy_pass to https.
We have clients in internet they call a url for example.

i want to pass this traffic to my server with the ip address 192.168.0.10. On this server i have ssl enabled listen port 9443.

We want use nginx as reverse_proxy. My nginx config looks like.

server { listen 443; servername testapp.mobios.example.com; location / { proxy_pass } }

If the clients try to contact the ssl server with they get nothing.

What i need is just pass https to https. Is SNI a problem here?

Any idea? Please help ayyoladi

3 Answers

Not directly same but similar question brought me here.

Load balancing to HTTPS:

Client <- HTTPS -> (decrypt) Load balancer (encrypt) <- HTTPS -> Server

Generally thisisayush answer () is very good and it partially solves my problem but adding load balancing makes it a bit more difficult to google.

When you make upstream list you must remember about adding a 443 port.

NOT WORKING:

upstream myapp2 { server 10.0.1.1; }

WORKING:

upstream myapp2 { server 10.0.1.1:443; }

Even if you use in location https protocol (which I expected to point by default to 443):

location / { proxy_pass }

Full example:

http { upstream myapp2 { server 10.0.1.1:443; } server { listen 443; ssl_certificate /etc/nginx/cert.crt; ssl_certificate_key /etc/nginx/cert.key; ssl on; location / { proxy_pass } } }

Answer is based on documentation which I eventually found with help of thisisayush comment:

server { listen 80; server_name website.domain.com; return 301 } server { listen 443 ssl; listen [::]:443 ssl; server_name website.domain.com; #Size archive client_max_body_size 50M; ssl_certificate /etc/letsencrypt/live/mydomain/fullchain.pem; ssl_certificate_key /etc/letsencrypt/live/mydomain/privkey.pem; ssl_trusted_certificate /etc/letsencrypt/live/mydomain/chain.pem; location / { proxy_set_header X-Forwarded-For $remote_addr; proxy_set_header Host $http_host; 1 ===> proxy_pass [ OR ] 2 ===> proxy_pass } }

I did this once for my client. What you do is enable and install SSL in Nginx rather than to the server being proxied.
