i am experimenting linux qos with htb and u32
i trying to create a rule with multiple qdiscs
please see below script and tell me where i am doing wrong ?
i am expecting 192.168.1.111 to have only 1 mbit download yet dude gets almost 100 mbit
tc qdisc del dev eth1 root tc qdisc add dev eth1 root handle 1: htb default 1 tc class add dev eth1 parent 1:0 classid 1:1 htb rate 100mbit tc class add dev eth1 parent 1:1 classid 1:2 htb rate 20mbit tc class add dev eth1 parent 1:1 classid 1:3 htb rate 10mbit tc qdisc add dev eth1 parent 1:2 handle 2: htb tc qdisc add dev eth1 parent 1:3 handle 3: htb tc class add dev eth1 parent 3: classid 3:1 htb rate 2mbit tc class add dev eth1 parent 3:1 classid 3:2 htb rate 1mbit tc filter add dev eth1 protocol ip parent 3: prio 1 u32 match ip dst 192.168.1.111/32 flowid 3:2 1 Answer
tc filter add dev eth1 protocol ip parent 3: prio 1 u32 match ip dst 192.168.1.111/32 flowid 3:2 was not enough it needed parent side filter as well
tc filter add dev eth1 protocol ip parent 1: prio 1 u32 match ip dst 192.168.1.111/32 flowid 1:3 it is now working as expected
