I have been trying to plot a time series graph from a CSV file. I have managed to read the file and converted the data from string to date using strptime and stored in a list. When I tried plotting a test plot in matplotlib with the list containing the date information it plotted the date as a series of dots; that is, for a date 2012-may-31 19:00 hours, I got a plot with a dot at 2012, 05, 19, 31, 00 on y axis for the value of x=1 and so on. I understand that this is not the correct way of passing date information for plotting. Can someone tell me how to pass this information correctly.
1 Answer
Convert your x-axis data from text to datetime.datetime, use datetime.strptime:
>>> from datetime import datetime >>> datetime.strptime("2012-may-31 19:00", "%Y-%b-%d %H:%M") datetime.datetime(2012, 5, 31, 19, 0) This is an example of how to plot data once you have an array of datetimes:
import matplotlib.pyplot as plt import datetime import numpy as np x = np.array([datetime.datetime(2013, 9, 28, i, 0) for i in range(24)]) y = np.random.randint(100, size=x.shape) plt.plot(x,y) plt.show()
