How to Desaturate a Color?

I might not be using the correct color terminology but I want to basically be able to scale colors similar to the picture attached. I have been searching for saturation to do this, as it appears the right version is just a must less saturated version of the left.

I was trying this (which I found) but it is not looking correct at all:

Public Shared Function GetDesaturatedColor(color As Color) As Color Const kValue As Double = 0.01R Dim greyLevel = (color.R * 0.299R) + _ (color.G * 0.587R) + _ (color.B * 0.144R) Dim r = greyLevel * kValue + (color.R) * (1 - kValue) Dim g = greyLevel * kValue + (color.G) * (1 - kValue) Dim b = greyLevel * kValue + (color.B) * (1 - kValue) ' ColorUtils.ToByte converts the double value ' to a byte safely Return color.FromArgb(255, _ ColorUtils.ToByte(r), _ ColorUtils.ToByte(g), _ ColorUtils.ToByte(b)) End Function

Does anyone know of some algorithm that can do this?

4 Answers

For those that want to avoid converting everything to HSL/HSV and back, this works reasonably well (if not correctly depending on what one thinks the "correct" desaturated image is):

f = 0.2; // desaturate by 20% L = 0.3*r + 0.6*g + 0.1*b; new_r = r + f * (L - r); new_g = g + f * (L - g); new_b = b + f * (L - b);

This is converting r,g,b to grayscale using the common assumption that green, red and blue correspond to the Luma of an image decreasing proportions respectively. So L is a grayscale image and then f is just linearly interpolating between the input RGB image and that grayscale image.

As @Brad mentioned in the comments to your post, your first step is to convert the colours from RGB to either HSL or HSV. From there, reducing the saturation is trivial - just subtract or divide the saturation by a value to reduce it.

After that, convert your HSL/HSV color back into RGB and it's ready for use.

How to change RGB color to HSV? has a good example of how to do this, as does Manipulating colors in .net.

It appears by experiment that just reducing saturation is not enough to get the result shown in the picture. I used the colors from OP's question in the code shown below. If you just reduce saturation, here is what you get:

If you also reduce alpha/opacity of the new color, you can achieve a better result:

I am assuming if you play with parameters, you should be able to get a perfect match. Try changing alpha for reducedSaturation2 (currently =40) and GetSaturation divider (currently =1.3)

Here is my code sample:

Public Function HSVToColor(ByVal H As Double, ByVal S As Double, ByVal V As Double) As Color Dim Hi As Integer = (H / 60) Mod 6 Dim f As Double = H / 60 Mod 1 Dim p As Integer = V * (1 - S) * 255 Dim q As Integer = V * (1 - f * S) * 255 Dim t As Integer = V * (1 - (1 - f) * S) * 255 Select Case Hi Case 0 : Return Color.FromArgb(V * 255, t, p) Case 1 : Return Color.FromArgb(q, V * 255, p) Case 2 : Return Color.FromArgb(p, V * 255, t) Case 3 : Return Color.FromArgb(p, V * 255, q) Case 4 : Return Color.FromArgb(t, p, V * 255) Case 5 : Return Color.FromArgb(V * 255, q, p) End Select End Function Private Sub Button1_Click(sender As System.Object, e As System.EventArgs) Handles Button1.Click Dim normalSaturation As Color = Color.FromArgb(255, 216, 53, 45) Me.CreateGraphics.FillRectangle(New SolidBrush(normalSaturation), 100, 0, 100, 100) Dim reducedSaturation As Color = HSVToColor(normalSaturation.GetHue, normalSaturation.GetSaturation / 1.3, normalSaturation.GetBrightness) Dim reducedSaturation2 As Color = Color.FromArgb(40, reducedSaturation) Me.CreateGraphics.FillRectangle(New SolidBrush(reducedSaturation2), 0, 0, 100, 100) End Sub

Here is my formula for changing the saturation of a given Color in C#. The result is equal to applying the CSS-effect filter: saturate(...), because this is the formula used by the W3C spec.

private static Color Saturate(Color c, double saturation) { // Values from: , type="saturate" var s = saturation; Func<double, int> clamp = i => Math.Min(255, Math.Max(0, Convert.ToInt32(i))); return Color.FromArgb(255, clamp((0.213 + 0.787 * s) * c.R + (0.715 - 0.715 * s) * c.G + (0.072 - 0.072 * s) * c.B), clamp((0.213 - 0.213 * s) * c.R + (0.715 + 0.285 * s) * c.G + (0.072 - 0.072 * s) * c.B), clamp((0.213 - 0.213 * s) * c.R + (0.715 - 0.715 * s) * c.G + (0.072 + 0.928 * s) * c.B)); }
