How to annotate a point outside the plot itself?

I have a plot like this and want to add text above the line with text 'TODAY'.

I was trying with annotations

annots.append(dict(x='2020-03-29',y=len(df)+1,text='<b>Today<b>', showarrow=False, font=dict(color='black')))

But the output is as such and I want it above the plot and not changing the structure of the plot!

1 Answer

You can do so in three steps:

1. adjust margins to make room for the text using fig.update_layout(margin=dict())
2. add line using fig.add_shape()
3. add text outside plot using add_annotation(yref='paper', y=1.06) where for example y > 1 places the annotation above the plot itself.

See code snippet for details

Plot:

Complete code:

# imports from plotly.offline import download_plotlyjs, init_notebook_mode, plot, iplot from IPython.core.display import display, HTML import plotly.figure_factory as ff import plotly.graph_objs as go # setup display(HTML("<style>.container { width:50% !important; } .widget-select > select {background-color: gainsboro;}</style>")) init_notebook_mode(connected=True) #%qtconsole --style vim # dates StartA = '2009-01-01' StartB = '2009-03-05' StartC = '2009-02-20' FinishA='2009-02-28' FinishB='2009-04-15' FinishC='2009-05-30' LabelDateA='2009-01-25' LabelDateB='2009-03-20' LabelDateC='2009-04-01' # sample data df = [dict(Task="Task A", Start=StartA, Finish=FinishA), dict(Task="Task B", Start=StartB, Finish=FinishB), dict(Task="Task C", Start=StartC, Finish=FinishC)] # figure fig = ff.create_gantt(df) # add annotations annots = [dict(x=LabelDateA,y=0,text="Task label A", showarrow=False, font=dict(color='white')), dict(x=LabelDateB,y=1,text="Task label B", showarrow=False, font=dict(color='White')), dict(x=LabelDateC,y=2,text="Task label C", showarrow=False, font=dict(color='White'))] # plot figure fig['layout']['annotations'] = annots # Step 1 - adjust margins to make room for the text fig.update_layout(margin=dict(t=150)) # Step 2 - add line fig.add_shape(type='line', x0=LabelDateB, y0=0, x1=LabelDateB, y1=1, line=dict(color='black', dash='dot'), xref='x', yref='paper' ) # Step 3 - add text with xref set to x # and yref set to 'paper' which will let you set # text outside the plot itself by specifying y > 1 fig.add_annotation(dict(font=dict(color="black",size=12), #x=x_loc, x=LabelDateB, y=1.06, showarrow=False, text='<b>Today</b>', textangle=0, xref="x", yref="paper" )) fig.update_layout( title_text="Academic year 2019/2020" ) fig.show()
