I have a simple FIFO code in SystemVerilog. I get several vlog-2110 illegal reference to net error messages. My error messages are followed by my code.
Error messages:
vlog -work work -sv -stats=none C:/Users/Single_FIFO.sv Model Technology ModelSim DE vlog 10.4 Compiler 2014.12 Dec 3 2014 -- Compiling module fifo_core_and_cntl
Error: C:/Users/Single_FIFO.sv(24): (vlog-2110) Illegal reference to net "occucy".
Error: C:/Users/Single_FIFO.sv(26): (vlog-2110) Illegal reference to net "empty".
Error: C:/Users/Single_FIFO.sv(28): (vlog-2110) Illegal reference to net "empty".
Error: C:/Users/Single_FIFO.sv(30): (vlog-2110) Illegal reference to net "full".
Error: C:/Users/Single_FIFO.sv(32): (vlog-2110) Illegal reference to net "full". ...... ......
My simple FIFO code: the small offending portion of it, is shown below.
module fifo_core_and_cntl (data_in, data_put, data_get, clk, reset_n, data_out, occucy, empty, full); input [7:0]data_in; input data_put, data_get, clk, reset_n; output [7:0]data_out; output empty, full; output [4:0]occucy; logic [4:0]current_readptr, current_writeptr, next_readptr, next_writeptr; logic [15:0][7:0]data_fifo; // This is data Fifo: 2D packed array of vectors: sixteen 8 bit vectors. always_ff @ (posedge clk, negedge reset_n) // For the Current counter updates. if (!reset_n) begin current_writeptr <= 0; current_readptr <= 0; end else begin current_writeptr <= next_writeptr; current_readptr <= next_readptr; end end always_comb begin // Combo logic for fifo status outputs and also for internal fifo rd/wr pointer updates. occucy = current_writeptr - current_readptr; // fifo occupancy indication if (current_writeptr == current_readptr) empty = 1'b1; else empty = 1'b0; end endmodule 2 Answers
empty and full are declared as output, which means their implied type is wire. You can only drive wires with a continuous assign:
assign empty = some_value; If you want to assign these signals from an always block, you should explicitly declare them as logic (or reg if you're using Verilog):
output logic empty, full; You cannot make procedure assignments to wires, which is the signal kind for your outputs by default. Since you are already using SystemVerilog, you should update your port declaration list to make it much simpler
module fifo_core_and_cntl ( input wire [7:0] data_in, input wire data_put, data_get, clk, reset_n, output logic [7:0]data_out, output logic empty, full, output logic [4:0]occupy );
