I've built an image slider (based on the terrific bxSlider) which will preload images just-in-time before they slide into view. It's working pretty well already, but I don't think my solution is valid HTML.

My technique is as follows: I generate the slider markup with the first slide image being inserted as usual (with an <img src="foo.jpg">) and subsequent images being referenced in a data attribute like <img>. A Javascript then juggles the data-orig -> src change when necessary, triggering the preloading.

In other words, I have:

<div> <div><img src="time.jpg" /></div> <div><img src="data:" /></div> <div><img src="data:" /></div> <div><img src="data:" /></div> </div>

To avoid empty src="" attributes (which are harmful to performance in some browsers), I've inserted src="data:" to effectively insert a blank image as a placeholder.


3

7 Answers

I looked into it and the smallest possible transparent GIF image, encoded as a data-uri, was this:


which is what I'm using now.

1

If you need a transparent image 1x1 pixel, just set this data uri as src default attribute (keep the /// parts, it encodes byte 255, not a comment).


This is instead a base64 encoding for an image 1x1 white.


Otherwise you could set data:null and save ~60 extra bytes for each image.

4

Valid and highly compressible. Essentially free if there's another inline svg in the page.

1

The smallest I've ever seen


update: This seems broken and doesn't work anymore as reported by @bryc, please use the other answers.

6

is smaller :D

4

1px by 1px JPEG image

1

Fabrizio's "white gif" isn't actually perfectly white : it is rgb(254, 255, 255).

I use the following one (which happens to be smaller), found on this page.
