I'm using angular6 with Angular material design templates. currently, my result is as follows,
Currently, I have sticky header and footer but the scrolling dataset is not user-friendly. issue-data-html is my HTML file,
<div> <div> <div fxLayout="row" fxLayoutAlign="start baseline" fxLayoutGap="8px" fxLayoutGap.gt-xs="24px"> <div fxLayout="column" fxLayoutAlign="start baseline" fxLayoutGap="24px" fxFlex="grow" fxLayout.gt-xs="row"> <div> <h3> Issue Statuses </h3> </div> <div></div> <!--Search--> <mat-form-field floatPlaceholder="never" fxFlex> <mat-icon matPrefix>search</mat-icon> <input matInput #filter placeholder="Search…" (keyup)="applyFilter($event.target.value)"> </mat-form-field> </div> <div fxFlex="none"> <button mat-mini-fab *ngIf="showAddIssueDataIcon" (click)="addIssueData(null)" matTooltip="Add Issue Data"> <mat-icon>add</mat-icon> </button> </div> <button type="button" mat-icon-button [matMenuTriggerFor]="columnFilter"> <mat-icon matTooltip="Configure Table">settings</mat-icon> </button> <mat-menu #columnFilter="matMenu" yPosition="below" xPosition="before"> <button *ngFor="let column of displayedColumns" (click)="toggleColumnVisibility(column, $event)"> <mat-checkbox [(ngModel)]="column.visible" (change)="columnFilterCheckboxClick($event)" #checkbox (click)="$event.stopPropagation()"> {{ column.name }} </mat-checkbox> </button> </mat-menu> <ng-content select=".actions"></ng-content> </div> <!--table--> <table mat-table [dataSource]="dataSource" matSort> <!-- issueStatus Column --> <ng-container matColumnDef="issueStatus"> <th mat-sort-header="name" mat-header-cell *matHeaderCellDef>ISSUE STATUS</th> <td mat-cell *matCellDef="let element"> {{element.name}} </td> </ng-container> <!-- showInBacklog Column --> <ng-container matColumnDef="showInBacklog"> <th mat-sort-header="backlog" mat-header-cell *matHeaderCellDef>SHOW IN BACKLOG</th> <td mat-cell *matCellDef="let element"> {{element.backlog}} </td> </ng-container> <!-- Status Column --> <ng-container matColumnDef="status"> <th mat-sort-header="status" mat-header-cell *matHeaderCellDef>STATUS</th> <td mat-cell *matCellDef="let element"> {{element.status}} </td> </ng-container> <!-- Actions Column --> <ng-container matColumnDef="action"> <th mat-header-cell *matHeaderCellDef>ACTIONS</th> <td mat-cell *matCellDef="let element; let i = index"> <button mat-icon-button *ngIf="showAddIssueDataIcon" (click)="editIssueData(element)"> <mat-icon matTooltip="Edit Issue Data">edit</mat-icon> </button> <!-- --> <a *ngIf="showEditIssue"> <i [matMenuTriggerFor]="selectMenu" matTooltip="More actions">more_vert</i></a> <mat-menu #selectMenu="matMenu"> <button mat-menu-item *ngIf="element.status === 'INACTIVE'" (click)="onClickEditStatus(element , true,i)">Make Active</button> <button mat-menu-item *ngIf="element.status === 'ACTIVE'" (click)="onClickEditStatus(element , false,i)">Make Inactive</button> <button mat-menu-item (click)="deleteIssueData(element,i)">Delete</button> </mat-menu> </td> </ng-container> <tr mat-header-row *matHeaderRowDef="visibleColumns"></tr> <tr mat-row *matRowDef="let row; columns: visibleColumns;" [ngClass]="{ hovered: row.hovered, highlighted: row.highlighted }" (click)="row.highlighted = !row.highlighted" (mouseover)="row.hovered = true" (mouseout)="row.hovered = false"></tr> </table> <mat-paginator [pageSize]="savedPageSize" (page)="columnFilterCheckboxClick($event)" [pageSizeOptions]="[5, 10, 20, 100]" showFirstLastButtons></mat-paginator> </div> </div> My css file is as follows,
.issueDataCard{ margin: 20px; } /* Structure */ table { width: 100%; } .mat-sort-header-container { align-items: center; } .mat-form-field { font-size: 14px; width: 98%; margin: 10px; } @import "var"; .app-list-name { color: $color; border-right: 1px solid $theme-divider; font-size: 20px; line-height: 0px; font-weight: 500; padding-right: $spacing; padding-left: $spacing; @include media-xs { border-right: none; } } .iconStyle{ color:#281c7b; cursor: pointer; } .slideToggleStyle{ display: flex; flex-direction: column; align-items: flex-end; } .divMarginStyle{ margin-bottom: 20px; margin-right: 20px; } .dataStyle{ text-align: center; } .dateStyle{ color:#5D6C7F; font-size: 10px; } .actions{ padding-right: 30px; } .action-cell{ text-align: right; } .mat-cell{ align-items: center; } .mat-elevation-z8 { display: flex; flex-direction: column; max-height: 500px; width: 100%; margin-bottom: 1.5%; overflow: auto; } I have no idea how to change these CSS classes according to my need, Any help will be greatly accepted.
3 Answers
Or you can just use sticky to the tr mat-header-row. For example:
<tr mat-header-row *matHeaderRowDef="columnsToDisplay; sticky:true"></tr> Finally hours of coding and changing CSS I found an answer to my question and I thought to post here because this will be helpful for someone in the future.
If I look at the above question I have used pure <table></table> tag for creating the table and for rows and columns I have used <th></th> and <td></td> tags. In Angular Material, there are specific tags for creating a table and assign rows and columns and furthermore to add sticky header and footer. If we won't use those tags there can be some misalignments. So finally I changed my code as below,
issue-data-component.html file is as follows,
<div> <div (click)="columnFilterCheckboxClick($event)"> <div> <div fxLayout="row" fxLayoutAlign="start baseline" fxLayoutGap="8px" fxLayoutGap.gt-xs="24px"> <div fxLayout="column" fxLayoutAlign="start baseline" fxLayoutGap="24px" fxFlex="grow" fxLayout.gt-xs="row"> <div> <h3> Issue Statuses</h3> </div> <div></div> <mat-form-field floatPlaceholder="never" fxFlex> <mat-icon matPrefix>search</mat-icon> <input matInput #filter placeholder="Search…" (keyup)="applyFilter($event.target.value)"> </mat-form-field> </div> <div> <button mat-fab (click)="addIssueData(null)" matTooltip="Add Issue Data" *ngIf="showAddIssueDataIcon"> <mat-icon>add</mat-icon> </button> </div> <button type="button" mat-icon-button [matMenuTriggerFor]="columnFilter"> <mat-icon matTooltip="Configure Table">settings</mat-icon> </button> <ng-content select=".actions"></ng-content> </div> <mat-menu #columnFilter="matMenu" yPosition="below" xPosition="before"> <button *ngFor="let column of displayedColumns" (click)="toggleColumnVisibility(column, $event)"> <mat-checkbox [(ngModel)]="column.visible" (change)="columnFilterCheckboxClick($event)" #checkbox (click)="$event.stopPropagation();"> {{ column.name }} </mat-checkbox> </button> </mat-menu> <ng-content></ng-content> </div> <mat-divider></mat-divider> <mat-table #table [dataSource]="dataSource" matSort> <!-- issueStatus Column --> <ng-container matColumnDef="issueStatus"> <mat-header-cell *matHeaderCellDef mat-sort-header="name"> STATUS </mat-header-cell> <mat-cell *matCellDef="let element"> {{element.name}} </mat-cell> </ng-container> <!-- showInBacklog Column --> <ng-container matColumnDef="showInBacklog"> <mat-header-cell *matHeaderCellDef mat-sort-header="backlog">ISSUE STATUS </mat-header-cell> <mat-cell *matCellDef="let element"> {{element.backlog}} </mat-cell> </ng-container> <!-- Status Column --> <ng-container matColumnDef="status"> <mat-header-cell *matHeaderCellDef mat-sort-header="status"> SHOW IN BACKLOG </mat-header-cell> <mat-cell *matCellDef="let element"> {{element.status}}</mat-cell> </ng-container> <!-- Actions Column --> <ng-container matColumnDef="action"> <mat-header-cell *matHeaderCellDef>ACTION </mat-header-cell> <mat-cell *matCellDef="let element; let i = index"> <button mat-icon-button *ngIf="showAddIssueDataIcon" (click)="editIssueData(element)"> <mat-icon matTooltip="Edit Issue Data">edit</mat-icon> </button> <!-- --> <a *ngIf="showEditIssue"> <i [matMenuTriggerFor]="selectMenu" matTooltip="More actions">more_vert</i></a> <mat-menu #selectMenu="matMenu"> <button mat-menu-item *ngIf="element.status === 'INACTIVE'" (click)="onClickEditStatus(element , true,i)">Make Active</button> <button mat-menu-item *ngIf="element.status === 'ACTIVE'" (click)="onClickEditStatus(element , false,i)">Make Inactive</button> <button mat-menu-item (click)="deleteIssueData(element,i)">Delete</button> </mat-menu> </mat-cell> </ng-container> <mat-header-row *matHeaderRowDef="visibleColumns"></mat-header-row> <mat-row *matRowDef="let row; columns: visibleColumns;"></mat-row> </mat-table> <mat-paginator [pageSize]="savedPageSize" (page)="columnFilterCheckboxClick($event)" [pageSizeOptions]="[5, 10, 20, 100]" showFirstLastButtons></mat-paginator> </div> </div> And I have added following CSS fields additionally to my CSS file,
.mat-elevation-z8 { display: flex; flex-direction: column; max-height: 500px; width: 95%; margin: 3% 3% 3% 3%; overflow: auto; } .tableStyle{ max-height: 500px; overflow: auto; } mat-header-cell, mat-header-row{ position: sticky; top:0; background: white; } Now the sticky header and footer workes fine and the alignments are well aligned,
I think this will work if not please generate stackblitz of your code
table { width: 100%; }
