- Format A There is 1 sign bit. There are k = 5 exponent bits. The exponent bias is 15. There are n = 3 fraction bits.
Those are the special ieee parameters
Binary number 1 00111 010
After all the math I get -5/1024
However, my buddy got -704
Who is right?
1 Answer
As the calculation below shows, it appears that you are correct, and the correct answer is -5/1024:
Input: 1 00111 010 Mantissa: 1.010 base 2 Exponent: 111 base 2 = 7 base 10; 7 − 15 = -8 De-normalize: 1.010 base 2 × 2^-8 = .00000001010 The following table shows how you can convert the denormalized number into a base 10 decimal:
Exponent | 2^-8 | 2^-9 | 2^-10 | 2^-11 | Decimal | 0.00390625 | 0.001953125 | 0.0009765625 | 0.00048828125 | Bit | 1 | 0 | 1 | 0 | Value | 0.00390625 | 0 | 0.0009765625 | 0 | Total = 0.00390625 + 0.0009765625 = 0.0048828125 This value must then be negated because the sign bit is set. So the final result is -0.0048828125. This equals -5/1024 which you originally got.
Here is a link to a great site which shows how to do the conversion step by step.
