hlc3 is a predefined series float in Pine Script for the timeframe of the current chart. How do I get the a hlc3 series float of lower timeframe within the current chart?

Say am on a daily chart, my pinescript (V5) code will give me the series float for predefined variable hlc3. I want to to get the hourly series hlc3

//(high + low + close)/3 Low1HLC1 = request.security_lower_tf(syminfo.tickerid, timeframe = "1", expression = (high + low + close) / 3) esa1 = ta.ema(Low1HLC1, n1)

I get the error: Error at 119:15 Cannot call 'ta.ema' with argument 'source'='Low1HLC1'. An argument of 'float[]' type was used but a 'series float' is expected.

I want to get a series float of lower timeframe hlc3

1 Answer

With the lower time frame data you have to do some extra steps to be able to use it. You'll need to put the data into a new float array and then you can access it. Here's an example on a 5 minute chart requesting the data from a 1 minute chart

indicator("My script") hlc = request.security_lower_tf(syminfo.tickerid, '1', hlc3) float[] newArray = array.new<float>(5) if hlc.size() > 0 for i = 0 to hlc.size() - 1 newArray.shift() newArray.push(hlc.get(i)) if barstate.islast label.new(bar_index,high,str.tostring(newArray.get(0), format.mintick) + ' ' + str.tostring(hlc.get(0), format.mintick)) ma = newArray.avg() plot(ma)

So here I have the same data in both arrays. I left the debug label on so you can see. Then just quickly turned that into a moving average, which looks like what you are trying to do.
