Specify view for zoomable heatmap in D3

I am doing a heatmap with zoom and pan functionalities, and realized that the data points is showing up on the left side of the y-axis when zooming and panning, after I increased the space to the left of the heatmap, in order to make space for the y-axis (See picture). How can I avoid this? A code sample is provided in below.

var zoom = d3.behavior.zoom() .scaleExtent([dotWidth, dotHeight]) .x(xScale) .on("zoom", zoomHandler); var svg = d3.select("body") .append("svg") .attr("width", width + margin.left + margin.right) .attr("height", height + margin.top + margin.bottom) .call(zoom) .append("g") .attr("transform", "translate(" + margin.left + "," + margin.top + ")"); function zoomHandler() { var t = zoom.translate(), tx = t[0], ty = t[1]; tx = Math.min(tx, 0); // tx < 0 tx = Math.max(tx, -1000); // zoom.translate([tx, ty]); svg.select(".x.axis").call(xAxis); svg.selectAll("ellipse") .attr("cx", function(d) { return xScale(d.day); }) .attr("cy", function(d) { return yScale(d.hour); }) .attr("rx", function(d) { return (dotWidth * d3.event.scale); }); } svg.selectAll("ellipse") .data(dataset) .enter() .append("ellipse") .attr("cx", function(d) { return xScale(d.day); }) .attr("cy", function(d) { return yScale(d.hour); }) .attr("rx", dotWidth) .attr("ry", dotHeight) .attr("fill", function(d) { return "rgba(100, 200, 200, " + colorScale(d.tOutC) + ")"; });

2 Answers

Zoom and pan image using manual scaling for CanvasRenderingContext2D.drawImage with d3. Preserves aspect ratio of the image

or this one

I figured out that the solution was to create a clipping path. I used the clipping method from this example: . Basically I added the following code:

svg.append("clipPath") .attr("id", "clip") .append("rect") .attr("class", "mesh") .attr("width", width) .attr("height", height); svg.append("g") .attr("clip-path", "url(#clip)") .selectAll(".hexagon") .data(hexbin(points)) .enter().append("path") .attr("class", "hexagon") .attr("d", hexbin.hexagon()) .attr("transform", function(d) { return "translate(" + d.x + "," + d.y + ")"; }) .style("fill", function(d) { return color(d.length); });

The code works fine with zooming features as well. Just call the zoom function when creating the your svg canvas. Like this:

// SVG canvas var svg = d3.select("#chart") .append("svg") .attr("width", width + margin.left + margin.right) .attr("height", height + margin.top + margin.bottom) .call(zoom) .append("g") .attr("transform", "translate(" + margin.left + "," + margin.top + ")");
