I'm on my personal project to create a esp8266 module that can read several sensor from a vehicle and it can sends data over mqtt. so I have written the code where I try to reading the speed sensor its getting wdt reset and the esp8266 resetting again
so heres my code
void setup() { //Initialize serial and wait for port to open: Serial.begin(9600); while (!Serial) { ; // wait for serial port to connect. Needed for native USB port only } lcd.init(); lcd.backlight(); pinMode(speedSensor,INPUT_PULLUP); // attempt to connect to WiFi network: Serial.print("Attempting to connect to WPA SSID: "); Serial.println(ssid); while (WiFi.begin(ssid, pass) != WL_CONNECTED) { lcd.setCursor(0,0); lcd.print("Connecting to"); lcd.setCursor(0,1); lcd.print("the network"); Serial.print("."); delay(5000); } lcd.clear(); Serial.println("You're connected to the network"); Serial.println(); lcd.setCursor(0,0); lcd.print("Connected to"); lcd.setCursor(0,1); lcd.print("the network"); delay(2000); lcd.clear(); // attempt to connect to the MQTT broker: Serial.print("Attempting to connect to the MQTT broker: "); Serial.println(broker); if (!mqttClient.connect(broker, port)) { Serial.print("MQTT connection failed! Error code = "); Serial.println(mqttClient.connectError()); while (1); } Serial.println("You're connected to the MQTT broker!"); Serial.println(); // subscribe to the topic and set callback function mqttClient.onMessage(SwitchMotor); mqttClient.subscribe(topicSwitchMotor); lcd.setCursor(0,0); lcd.print("Connected to"); lcd.setCursor(0,1); lcd.print("the MQTT broker"); delay(2000); lcd.clear(); lcd.setCursor(0,0); lcd.print(" Fuel :"); lcd.setCursor(0,1); lcd.print(" RPM :"); SPI.begin(); rfid.PCD_Init(); Serial.println("I am waiting for card..."); pinMode(pinRelay, OUTPUT); digitalWrite(pinRelay, HIGH); } void loop() { mqttClient.poll(); // check for incoming messages FuelSensor(); // Fuel Sensor SpeedMotor(); // Speed Sensor StartMotor(); // Start Motor with RFID } void SpeedMotor(){ start_time=millis(); end_time=start_time+1000; while(millis()<end_time){ yield(); if(digitalRead(speedSensor)){ steps=steps+1; while(digitalRead(speedSensor)); } } // calculate the speed temp=steps-steps_old; steps_old=steps; rps=(temp/20); rpm=(rps*60); lcd.setCursor(9,1); lcd.print(rpm); lcd.print(" "); // publish the message mqttClient.beginMessage(topicSpeedRpm); mqttClient.print(rpm); mqttClient.endMessage(); mqttClient.beginMessage(topicSpeedRps); mqttClient.print(rps); mqttClient.endMessage(); } and this is the output from serial monitor
Attempting to connect to WPA SSID: cieciecie ...You're connected to the network Attempting to connect to the MQTT broker: xx.xxx.xxx.xx You're connected to the MQTT broker! I am waiting for card... --------------- CUT HERE FOR EXCEPTION DECODER --------------- Soft WDT reset >>>stack>>> ctx: cont sp: 3ffffde0 end: 3fffffc0 offset: 01a0 3fffff80: 3fffdad0 3ffee7bc 3ffee7c0 40201143 3fffff90: 3fffdad0 00000000 3ffeeaa8 402016e9 3fffffa0: 3fffdad0 00000000 3ffeeaa8 40205d5c 3fffffb0: feefeffe feefeffe 3ffe8600 40100e61 <<<stack<<< --------------- CUT HERE FOR EXCEPTION DECODER --------------- ⸮⸮Attempting to connect to WPA SSID: cieciecie ...You're connected to the network Attempting to connect to the MQTT broker: xx.xxx.xxx.xx You're connected to the MQTT broker! I am waiting for card... --------------- CUT HERE FOR EXCEPTION DECODER --------------- Soft WDT reset it'll soft wdt reset all over again and again
I'd already try Stack ESP execption decoder and it given this results ESP Exception decoder results
at the results its mentioning line 152 at speedMotor() function
void SpeedMotor(){ start_time=millis(); end_time=start_time+1000; while(millis()<end_time){ yield(); // already use yield(); on while() loop if(digitalRead(speedSensor)){ // line 152 steps=steps+1; while(digitalRead(speedSensor)); } } // calculate the speed temp=steps-steps_old; steps_old=steps; rps=(temp/20); rpm=(rps*60); lcd.setCursor(9,1); lcd.print(rpm); lcd.print(" "); // publish the message mqttClient.beginMessage(topicSpeedRpm); mqttClient.print(rpm); mqttClient.endMessage(); mqttClient.beginMessage(topicSpeedRps); mqttClient.print(rps); mqttClient.endMessage(); } and i already try too from arduino forum it says try using yield(); in the while() loop but its still given the soft wdt rest
i would like to have clear answer how to use the yield(); function properly so theres no more soft wdt resetting again
1 Answer
As per the comments the issue was in this section of code:
while(millis()<end_time){ yield(); // already use yield(); on while() loop if(digitalRead(speedSensor)){ // line 152 steps=steps+1; while(digitalRead(speedSensor)); } } The problem is that if digitalRead(speedSensor) returns true then a loop runs until digitalRead(speedSensor) returns false; this may run long enough to trigger the watchdog.
while(digitalRead(speedSensor)); One way of fixing this is to yield within the loop i.e.:
while(digitalRead(speedSensor)) { yield(); }
