Mount VMWare Disk Images Under Linux

Is it still possible to mount VMWare disk images under Linux?

I found the following two articles, both of them recommend to use kpartx -av diskimage-flat.vmdk. However both the articles are old and, when I try it on my Ubuntu Utopic 14.10, it no longer works any more.

$ sudo kpartx -av MyWin81.vmdk $ sudo ls /dev/mapper/loop* | wc -l ls: cannot access /dev/mapper/loop*: No such file or directory 0

Disclosure: My VMWare disk image IS a flat disk image. Furthermore (before you recommend loop mount), it is a multi-partition disk image, with first partition being Window8 and next two in Linux. It is the next two Linux partitions that I'm more interested to work on.

Can someone confirm please? Thanks.

Mount Flat VMWare Disk Images Under Linux

Mount a VMware virtual disk (.vmdk) file on a Linux box

UPDATE:

vmware-mount looks very promising, but I can't get it working yet:

$ vmware-mount -p Win81.vmdk VixDiskLib: Invalid configuration file parameter. Failed to read configuration file. Nr Start Size Type Id Sytem -- ---------- ---------- ---- -- ------------------------ 1 2048 78643200 BIOS 7 HPFS/NTFS 2 78645248 6039552 BIOS 83 Linux 3 84684800 41144320 BIOS 83 Linux % vmware-mount Win81.vmdk 1 /mnt/tmp1/ VixDiskLib: Invalid configuration file parameter. Failed to read configuration file. Failed to mount partition 1 of disk 'Win81.vmdk' on '/mnt/tmp1/': Insufficient permissions to perform this operation % vmware-mount -L VixDiskLib: Invalid configuration file parameter. Failed to read configuration file. No mounted disks. $ vmware-mount | head -3 VixDiskLib: Invalid configuration file parameter. Failed to read configuration file. VMware DiskMount Utility version 6.0.0, build-2496824 Usage: vmware-mount diskPath [partition num] mountPoint

NB, the 2nd and 3rd command is run directly as root, yet I get "Insufficient permissions to perform this operation"?

3 Answers

You can also use qemu:

For .vdi

sudo modprobe nbd sudo qemu-nbd -c /dev/nbd1 ./linux_box/VM/image.vdi

if they are not installe you can install them (on Ubuntu is this comand)

sudo apt install qemu-utils

and then mount it

mount /dev/nbd1p1 /mnt

For .vmdk

sudo modprobe nbd sudo qemu-nbd -r -c /dev/nbd1 ./linux_box/VM/image.vmdk

notice tha I use the option -r that's because VMDK version 3 must be read only to be able to be mounted by qemu

and then I mount it

mount /dev/nbd1p1 /mnt

I use nbd1 because nbd0 sometimes gives 'mount: special device /dev/nbd0p1 does not exist'

For .ova

tar -tf image.ova tar -xvf image.ova

The above will extract the .vmdk disk and then mount that.

My configuration:

Ubuntu: 16.04.3 LTS Kernel: 4.4.0-112-generic Package: qemu-utils version: 1:2.5+dfsg-5ubuntu10.22 Vmdk: 3 but should be any

In my machine the loop devices are in /dev. This article mentions /dev/wrapper and /dev, so it could be of help to you.

On the other hand, this other article uses the vmware-mount command to accomplish the same.

Note: My system is Slackware64-current (mostly), but with mainly gtk-based software.

Install affuse, then mount file with it:

affuse /path/file.vmdk /mnt/vmdk

Check sector size

fdisk -l /mnt/vmdk/file.vmdk.raw # example Disk file.vmdk.raw: 20 GiB, 21474836480 bytes, 41943040 sectors Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: dos Disk identifier: 0x000da525 Device Boot Start End Sectors Size Id Type /mnt/vmdk/file.vmdk.raw1 * 2048 41943039 41940992 20G 83 Linux

Multiply sectorsize and startsector. In example it would be 2048*512

echo 2048*512 | bc 1048576

Mount using that offset

mount -o ro,loop,offset=1048576 /mnt/vmdk/file.raw /mnt/vmdisk

Disk should now be mounted and readable on /mnt/vmdisk
