Kubernetes Pod Warning: 1 node(s) had volume node affinity conflict

I try to set up Kubernetes cluster. I have Persistent Volume, Persistent Volume Claim and Storage class all set-up and running but when I wan to create pod from deployment, pod is created but it hangs in Pending state. After describe I get only this warning "1 node(s) had volume node affinity conflict." Can somebody tell me what I am missing in my volume configuration?

apiVersion: v1 kind: PersistentVolume metadata: creationTimestamp: null labels: io.kompose.service: mariadb-pv0 name: mariadb-pv0 spec: volumeMode: Filesystem storageClassName: local-storage local: path: "/home/gtcontainer/applications/data/db/mariadb" accessModes: - ReadWriteOnce capacity: storage: 2Gi claimRef: namespace: default name: mariadb-claim0 nodeAffinity: required: nodeSelectorTerms: - matchExpressions: - key: operator: In values: - master status: {}

12 Answers

The error "volume node affinity conflict" happens when the persistent volume claims that the pod is using are scheduled on different zones, rather than on one zone, and so the actual pod was not able to be scheduled because it cannot connect to the volume from another zone. To check this, you can see the details of all the Persistent Volumes. To check that, first get your PVCs:

$ kubectl get pvc -n <namespace>

Then get the details of the Persistent Volumes (not Volume claims)

$ kubectl get pv

Find the PVs, that correspond to your PVCs and describe them

$ kubectl describe pv <pv1> <pv2>

You can check the Source.VolumeID for each of the PV, most likely they will be different availability zone, and so your pod gives the affinity error. To fix this, create a storageclass for a single zone and use that storageclass in your PVC.

kind: StorageClass apiVersion: metadata: name: region1storageclass provisioner: parameters: type: gp2 encrypted: "true" # if encryption required volumeBindingMode: WaitForFirstConsumer allowedTopologies: - matchLabelExpressions: - key: values: - eu-west-2b # this is the availability zone, will depend on your cloud provider # multi-az can be added, but that defeats the purpose in our scenario

There a few things that can cause this error:

1. Node isn’t labeled properly. I had this issue on AWS when my worker node didn’t have appropriate labels(master had them though) like that:

   After patching the node with the labels, the “1 node(s) had volume node affinity conflict” error was gone, so PV, PVC with a pod were deployed successfully. The value of these labels is cloud provider specific. Basically, it is the job of the cloud provider(with —cloud-provider option defined in cube-controller, API-server, kubelet) to set those labels. If appropriate labels aren’t set, then check that your CloudProvider integration is correct. I used kubeadm, so it is cumbersome to set up but with other tools, kops, for instance, it is working right away.

2. Based on your PV definition and the usage of nodeAffinity field, you are trying to use a local volume, (read here local volume description link, official docs), then make sure that you set "NodeAffinity field" like that(it worked in my case on AWS):

   nodeAffinity:

    required: nodeSelectorTerms: - matchExpressions: - key: operator: In values: - my-node # it must be the name of your node(kubectl get nodes)

So that after creating the resource and running describe on it it will show up there like that:

 Required Terms: Term 0: in [your node name]

3. StorageClass definition(named local-storage, which is not posted here) must be created with volumeBindingMode set to WaitForFirstConsumer for local storage to work properly. Refer to the example here storage class local description, official doc to understand the reason behind that.

0. If you didn't find the solution in other answers...

In our case the error happened on a AWS EKS cluster freshly provisioned with Pulumi (see full source here). The error drove me nuts, since I didn't change anything, just created a PersistentVolumeClaim as described in the Buildpacks Tekton docs:

apiVersion: v1 kind: PersistentVolumeClaim metadata: name: buildpacks-source-pvc spec: accessModes: - ReadWriteOnce resources: requests: storage: 500Mi

I didn't change anything else from the default EKS configuration and also didn't add/change any PersistentVolume or StorageClass (in fact I didn't even know how to do that). As the default EKS setup seems to rely on 2 nodes, I got the error:

0/2 nodes are available: 2 node(s) had volume node affinity conflict.

Reading through Sownak Roy's answer I got a first glue what to do - but didn't know how to do it. So for the folks interested here are all my steps to resolve the error:

1. Check EKS nodes failure-domain.beta.kubernetes.io labels

As described in the section Statefull applications in this post two nodes are provisioned on other AWS availability zones as the persistent volume (PV), which is created by applying our PersistendVolumeClaim described above.

To check that, you need to look into/describe your nodes with kubectl get nodes:

$ kubectl get nodes NAME STATUS ROLES AGE VERSION ip-172-31-10-186.eu-central-1.compute.internal Ready <none> 2d16h v1.21.5-eks-bc4871b ip-172-31-20-83.eu-central-1.compute.internal Ready <none> 2d16h v1.21.5-eks-bc4871b

and then have a look at the Label section using kubectl describe node <node-name>:

$ kubectl describe node ip-172-77-88-99.eu-central-1.compute.internal Name: ip-172-77-88-99.eu-central-1.compute.internal Roles: <none> Labels: Annotations: 0 ...

In my case the node ip-172-77-88-99.eu-central-1.compute.internal has defined as eu-central-1 and the az with to eu-central-1b.

And the other node defines az eu-central-1a:

$ kubectl describe nodes ip-172-31-10-186.eu-central-1.compute.internal Name: ip-172-31-10-186.eu-central-1.compute.internal Roles: <none> Labels: Annotations: 0 ...

2. Check PersistentVolume's topology.kubernetes.io field

Now we should check the PersistentVolume automatically provisioned after we manually applied our PersistentVolumeClaim. Use kubectl get pv:

$ kubectl get pv NAME CAPACITY ACCESS MODES RECLAIM POLICY STATUS CLAIM STORAGECLASS REASON AGE pvc-93650993-6154-4bd0-bd1c-6260e7df49d3 1Gi RWO Delete Bound default/buildpacks-source-pvc gp2 21d

followed by kubectl describe pv <pv-name>

$ kubectl describe pv pvc-93650993-6154-4bd0-bd1c-6260e7df49d3 Name: pvc-93650993-6154-4bd0-bd1c-6260e7df49d3 Labels: Annotations: aws-ebs-dynamic-provisioner ...

The PersistentVolume was configured with the label in az eu-central-1c, which makes our Pods complain about not finding their volume - since they are in a completely different az!

3. Add allowedTopologies to StorageClass

As stated in the Kubernetes docs one solution to the problem is to add a allowedTopologies configuration to the StorageClass. If you already provisioned a EKS cluster like me, you need to retrieve your already defined StorageClass with

kubectl get storageclasses gp2 -o yaml

Save it to a file called storage-class.yml and add a allowedTopologies section that matches your node's failure-domain.beta.kubernetes.io labels like this:

allowedTopologies: - matchLabelExpressions: - key: values: - eu-central-1a - eu-central-1b

The allowedTopologies configuration defines that the of the PersistentVolume must be either in eu-central-1a or eu-central-1b - not eu-central-1c!

The full storage-class.yml looks like this:

apiVersion: kind: StorageClass metadata: name: gp2 parameters: fsType: ext4 type: gp2 provisioner: reclaimPolicy: Delete volumeBindingMode: WaitForFirstConsumer allowedTopologies: - matchLabelExpressions: - key: values: - eu-central-1a - eu-central-1b

Apply the enhanced StorageClass configuration to your EKS cluster with

kubectl apply -f storage-class.yml

4. Delete PersistentVolumeClaim, add storageClassName: gp2 to it and re-apply it

In order to get things working again, we need to delete the PersistentVolumeClaim first.

To map the PersistentVolumeClaim to our previously define StorageClass we need to add storageClassName: gp2 to the PersistendVolumeClaim definition in our pvc.yml:

apiVersion: v1 kind: PersistentVolumeClaim metadata: name: buildpacks-source-pvc spec: accessModes: - ReadWriteOnce resources: requests: storage: 500Mi storageClassName: gp2

Finally re-apply the PersistentVolumeClaim with kubectl apply -f pvc.yml. This should resolve the error.

The "1 node(s) had volume node affinity conflict" error is created by the scheduler because it can't schedule your pod to a node that conforms with the persistenvolume.spec.nodeAffinity field in your PersistentVolume (PV).

In other words, you say in your PV that a pod using this PV must be scheduled to a node with a label of = master, but this isn't possible for some reason.

There may be various reason that your pod can't be scheduled to such a node:

• The pod has node affinities, pod affinities, etc. that conflict with the target node
• The target node is tainted
• The target node has reached its "max pods per node" limit
• There exists no node with the given label

The place to start looking for the cause is the definition of the node and the pod.

Great answer by Sownak Roy. I've had the same case of a PV being created in a different zone compared to the node that was supposed to use it. The solution I applied was based on Sownak's answer only in my case it was enough to specify the storage class without the "allowedTopologies" list, like this:

apiVersion: kind: StorageClass metadata: name: cloud-ssd provisioner: parameters: type: gp2 volumeBindingMode: WaitForFirstConsumer

In my case, the root cause was that the persistent volume are in us-west-2c and the new worker nodes are relaunched to be in us-west-2a and us-west-2b. The solution is to either have more worker nodes so they are in more zones, or remove / widen node affinity for the application so that more worker nodes qualifies to be bounded to the persistent volume.

Different case from GCP GKE. Assume that you are using regional cluster and you created two PVC. Both were created in different zones (you didn't notice).

In next step you are trying to run the pod which will have mounted both PVC to the same pod. You have to schedule that pod to specific node in specific zone but because your volumes are on different zones the k8s won't be able to schedule that and you will receive the following problem.

For example - two simple PVC(s) on the regional cluster (nodes in different zones):

kind: PersistentVolumeClaim apiVersion: v1 metadata: name: disk-a spec: accessModes: - ReadWriteOnce resources: requests: storage: 10Gi --- kind: PersistentVolumeClaim apiVersion: v1 metadata: name: disk-b spec: accessModes: - ReadWriteOnce resources: requests: storage: 10Gi

Next simple pod:

apiVersion: v1 kind: Pod metadata: name: debug spec: containers: - name: debug image: pnowy/docker-tools:latest command: [ "sleep" ] args: [ "infinity" ] volumeMounts: - name: disk-a mountPath: /disk-a - name: disk-b mountPath: /disk-b volumes: - name: disk-a persistentVolumeClaim: claimName: disk-a - name: disk-b persistentVolumeClaim: claimName: disk-b

Finally as a result it could happen that k8s won't be able schedule to pod because the volumes are on different zones.

1. Make sure the kubernetes node had the required label. You can verify the node labels using:

kubectl get nodes --show-labels

One of the kubernetes nodes should show you the name/ label of the persistent volume and your pod should be scheduled on the same node.

2. Make sure the requested size in PersistentVolumeClaim is matching with the size of the PersistentVolume. If the size does not match, either correct the resources.requests.storage in PersistentVolumeClaim or delete the old PersistentVolume and create a new one with the correct size.

Verification steps:

1. Describe your persistent volume:

kubectl describe pv postgres-br-proxy-pv-0

Output:

... Node Affinity: Required Terms: Term 0: postgres-br-proxy in [postgres-br-proxy-pv-0] ...

2. Show node labels:

kubectl get nodes --show-labels

Output:

NAME STATUS ROLES AGE VERSION LABELS node3 Ready <none> 19d v1.17.6 postgres-br-proxy=postgres-br-proxy-pv-0

If you are not getting the persistent volume label on the node that your pod is using then the pod won't get scheduled.

After some headache inducing investigation there are a few things that are needed to be checked:

Azure:

• Does your cluster have more that one zone selected? (zone 1, 2, 3)
• Does your default storage class have the correct storage provider? (ZRS Zone-Redundant-Storage)

If not:

• change the storage class to use te correct provider
• create backup of PV data
• stop the deployment that is using the PVC (set replicas to 0)
• delete the PVC and confirm that the associated PV is deleted.
• re-apply the PVC config yaml (without reference to the old storageclass name)
• start the deployment that is using the PVC (set replicas to 1)
• manually import backupdata

Example storageclass for AKS:

allowVolumeExpansion: true apiVersion: kind: StorageClass metadata: name: zone-redundant-storage parameters: skuname: StandardSSD_ZRS provisioner: disk.csi.azure.com reclaimPolicy: Delete volumeBindingMode: WaitForFirstConsumer

GKE:

• Does your cluster have more than one zone selected? (Zone A, B, C)
• Does your default storage class have replication-type parameter? (replication-type: regional-pd)

If not:

• change the storage class to use te correct parameters
• create backup of PV data
• stop the deployment that is using the PVC (set replicas to 0)
• delete the PVC and confirm that the associated PV is deleted.
• re-apply the PVC config yaml (without reference to the old storageclass name)
• start the deployment that is using the PVC (set replicas to 1)
• manually import backupdata

Example storageclass for GKE:

kind: StorageClass apiVersion: metadata: name: standard-regional-pd-storage provisioner: pd.csi.storage.gke.io parameters: type: pd-standard replication-type: regional-pd volumeBindingMode: WaitForFirstConsumer

After that PV's will have redundancy across the selected zones allowing a pod to access PV from other nodes in different zones.

almost same problem described here...

"If you're using local volumes, and the node crashes, your pod cannot be rescheduled to a different node. It must be scheduled to the same node. That is the caveat of using local storage, your Pod becomes bound forever to one specific node."

One cause from this is when you have a definition like below (Kafka Zookeeper in this example) which is using multiple pvcs for one container. If they land on different nodes, you will get something like the following: ..volume node affinity conflict. The solution here is to use one pvc definition and use subPath on the volumeMount.

Problem

 ... volumeMounts: - mountPath: /data name: kafka-zoo-data - mountPath: /datalog name: kafka-zoo-datalog restartPolicy: Always volumes: - name: kafka-zoo-data persistentVolumeClaim: claimName: "zookeeper-data" - name: kafka-zoo-datalog persistentVolumeClaim: claimName: "zookeeper-datalog"

Resolved

 ... volumeMounts: - mountPath: /data subPath: data name: kafka-zoo-data - mountPath: /datalog subPath: datalog name: kafka-zoo-data restartPolicy: Always volumes: - name: kafka-zoo-data persistentVolumeClaim: claimName: "zookeeper-data"

Most likely you just reduced number of nodes in your kubernetes cluster and some "regions" are not available anymore...

Something worth mentioning... if your pod will be in different zone than persistent volume then:

• your disc access times will drop significantly (your local persistent storage is not local anymore - even with Amazon's / Google's fiber hyper fast links it's still traffic across data centers)
• you will be paying for "cross regional network" (on your AWS bill it is something that goes into "EC2-other" and only after drilling down Aws Bill you can spot that)
