Kubernetes: how to set VolumeMount user group and file permissions

I'm running a Kubernetes cluster on AWS using kops. I've mounted an EBS volume onto a container and it is visible from my application but it's read only because my application does not run as root. How can I mount a PersistentVolumeClaim as a user other than root? The VolumeMount does not seem to have any options to control the user, group or file permissions of the mounted path.

Here is my Deployment yaml file:

apiVersion: extensions/v1beta1 kind: Deployment metadata: name: notebook-1 spec: replicas: 1 template: metadata: labels: app: notebook-1 spec: volumes: - name: notebook-1 persistentVolumeClaim: claimName: notebook-1 containers: - name: notebook-1 image: jupyter/base-notebook ports: - containerPort: 8888 volumeMounts: - mountPath: "/home/jovyan/work" name: notebook-1

10 Answers

The Pod Security Context supports setting an fsGroup, which allows you to set the group ID that owns the volume, and thus who can write to it. The example in the docs:

apiVersion: v1 kind: Pod metadata: name: hello-world spec: containers: # specification of the pod's containers # ... securityContext: fsGroup: 1234

More info on this is here

I ended up with an initContainer with the same volumeMount as the main container to set proper permissions, in my case, for a custom Grafana image.

This is necessary when a container in a pod is running as a user other than root and needs write permissions on a mounted volume.

initContainers: - name: take-data-dir-ownership image: alpine:3 # Give `grafana` user (id 472) permissions a mounted volume # command: - chown - -R - 472:472 - /var/lib/grafana volumeMounts: - name: data mountPath: /var/lib/grafana

Update: Note that it might suffice to run chown without the -R (recursive) flag, since the permissions will generally be persisted across pod restarts. This will be desirable if there are large amounts of files in the volume, as it will take time to process all of them (depending on the resources limits that are set for the initContainer).

This came as one of the challenges for the Kubernetes Deployments/StatefulSets, when you have to run process inside a container as non-root user. But, when you mount a volume to a pod, it always gets mounted with the permission of root:root.

So, the non-root user must have access to the folder where it wants to read and write data.

Please follow the below steps for the same.

1. Create user group and assign group ID in Dockerfile.
2. Create user with user ID and add to the group in Dockerfile.
3. change ownership recursively for the folders the user process wants to read/write.

4. Add the below lines in Deployment/StatefulSet in pod spec context.

   spec: securityContext: runAsUser: 1099 runAsGroup: 1099 fsGroup: 1099

runAsUser

Specifies that for any Containers in the Pod, all processes run with user ID 1099.

runAsGroup

Specifies the primary group ID of 1099 for all processes within any containers of the Pod.

If this field is omitted, the primary group ID of the containers will be root(0).

Any files created will also be owned by user 1099 and group 1099 when runAsGroup is specified.

fsGroup

Specifies the owner of any volume attached will be owner by group ID 1099.

Any files created under it will be having permission of nonrootgroup:nonrootgroup.

For k8s version 1.10+, runAsGroup has been added, it's similar to fsGroup but works differently.

Implementation can be tracked here:

Please refer to this issue:

If it is an emptydir, the securityContext in the spec can be used:

spec: securityContext: runAsUser: 1000 fsGroup: 1000 containers: ...

If the volume is a hostpath, an initContainer can be used to chown paths in the volume:

initContainers: - name: example-c image: busybox:latest command: ["sh","-c","mkdir -p /vol-path && chown -R 1000:1000 /vol-path"] resources: limits: cpu: "1" memory: 1Gi volumeMounts: - name: vol-example mountPath: /vol-path

• In minikube, it worked after running initContainers as a root user , by setting runAsUser: 0

 initContainers: - name: change-ownership-container image: busybox command: ["/bin/chown","-R","1000:1000", "/home/jovyan/work"] securityContext: runAsUser: 0 privileged: true volumeMounts: - name: notebook-data mountPath: /home/jovyan/work

So the whole Yaml file looks like this

apiVersion: apps/v1 kind: StatefulSet metadata: name: jupyter labels: release: jupyter spec: replicas: updateStrategy: type: RollingUpdate serviceName: jupyter-headless podManagementPolicy: Parallel selector: matchLabels: release: jupyter template: metadata: labels: release: jupyter annotations: spec: restartPolicy: Always terminationGracePeriodSeconds: 30 securityContext: runAsUser: 1000 fsGroup: 1000 containers: - name: jupyter image: "jupyter/base-notebook:ubuntu-20.04" imagePullPolicy: IfNotPresent ports: - name: http containerPort: 8888 protocol: TCP - name: blockmanager containerPort: 7777 protocol: TCP - name: driver containerPort: 2222 protocol: TCP volumeMounts: - name: notebook-data mountPath: /home/jovyan/work resources: limits: cpu: 200m memory: 300Mi requests: cpu: 100m memory: 200Mi initContainers: - name: change-ownership-container image: busybox command: ["/bin/chown","-R","1000:1000", "/home/jovyan/work"] securityContext: runAsUser: 0 privileged: true volumeMounts: - name: notebook-data mountPath: /home/jovyan/work volumes: - name: notebook-data persistentVolumeClaim: claimName: jupyter-pvc

In my case, I used scratch as the base image and set the user to 65543. And I needed the write permission to a dir. I did this by using emptyDir volume,

spec: containers: ... volumeMounts: - mountPath: /tmp name: tmp # readOnly: true volumes: - name: tmp emptyDir: {}

To change the file system permission run the initcontainer before actual container start

here example for elastic search pod

initContainers: - command: - sh - -c - chown -R 1000:1000 /usr/share/elasticsearch/data - sysctl -w vm.max_map_count=262144 - chgrp 1000 /usr/share/elasticsearch/data image: busybox:1.29.2 imagePullPolicy: IfNotPresent name: set-dir-owner resources: {} terminationMessagePath: /dev/termination-log terminationMessagePolicy: File volumeMounts: #Volume mount path - mountPath: /usr/share/elasticsearch/data name: elasticsearch-data

To change user group in container

spec: containers: securityContext: privileged: true runAsUser: 1000

Over a few iterations later, I ended up using

{{- $root := . }} ... initContainers: - name: volume-mount-hack image: busybox command: ["sh", "-c", "find /data -user root -exec chown 33:33 {} \\;"] volumeMounts: {{- range $key,$val := .Values.persistence.mounts }} - name: data mountPath: /data/{{ $key }} subPath: {{ $root.Values.projectKey }}/{{ $key }} {{- end }}

It's much cleaner and configurable as opposed to other solutions. Moreover, it is way faster - the find command only changes permissions on files/directories that actually belong to the root user.

When you are mounting volumes with a large number of files, this can have a significant impact on your container boot/load times (seconds or even minutes!).

Try comparing the execution time of

chown www-data:www-data ./ -R

and

find /data -user root -exec chown 33:33 {} \\;

you may be surprised!

For people using configmap as file inside pod

I am loading data from a configmap as file inside the pod's container here are my manifests:

#./script-cm.yaml apiVersion: v1 kind: ConfigMap metadata: name: script-cm labels: app: script data: data-script: | #!/bin/bash set -e echo "some script commands"

#./deployment.yaml apiVersion: apps/v1 kind: Deployment metadata: name: script namespace: default labels: app: script spec: selector: matchLabels: app: script replicas: 1 template: metadata: labels: app: script spec: restartPolicy: Always containers: - name: script-container image: ubuntu:20.04 resources: {} volumeMounts: - name: influxdb-provisioning mountPath: /docker-entrypoint-initdb.d/data.sh subPath: data.sh volumes: - name: script-bind configMap: name: script-cm items: - key: data-script path: data.sh mode: 0777

As you can see I am following k8s docs to bind a config map into the pod, mode: 0777 allowed me to give execution permissions on that specific file, you can also run the following command to get a better idea using kubectl explain:

kubectl explain deployment.spec.template.spec.volumes.configMap.items.mode

Make sure to put the right permissions instead of 0777 since it's not recommended especially on sensitive data!
