I have a strange problem with my IPsec VPN: I have 2 matched [hardware and software - 2.4.4 release p3] pfSense boxes at different locations. Each pfSense is a Firewall + DHCP server + Gateway for the local LAN. I have setup an IPsec tunnel between the two gateways, but while I can access both gateways from a local host, I can't connect to any remote hosts.

Additionally the local gateway can't ping the remote gateway.

  • Local host pings local gateway
  • Local host pings remote gateway
  • Local host cannot ping remote host
  • Local gateway cannot ping remote gateway

Local subnet: 192.168.10.0/24

Remote subnet: 192.168.9.0/24

Sitting at either location, I can access both gateways, but nothing else on the remote side.

Both gateways have the P1 and P2 settings exactly the same [apart from switching local and remote networks / gateways on the respective boxes]

Here are the P1 settings:

  • Key Exchange Version: IKEv2
  • Internet Protocol: Both (Dual Stack)
  • Interface: WAN [which is on a static IP]
  • Remote Gateway: Static Ip of remote Gateway

P2 Settings:

  • Mode: Tunnel IPv4
  • Local Network: 192.168.10.0/24 [this gets changed to .9.0 on the other box]
  • NAT/BINAT translation: none
  • Remote Network: 192.168.9.0/24 [this gets changed to .10.0 on the other box]

I tried disabling the firewall completely to see if that was the issue, but it had no effect.

7

1 Answer

The issue is sorted,

I had setup the IPsec firewall rules to go though the gateway on which IPsec was configured.

Once I changed the gateway settings to Default, it worked [almost] perfectly.

Now I can access some remote hosts, but not all.
