In the output of SysInternals Handle.exe what does RWD stand for?

I'm using handle.exe from SysInternals to grab information about open handles. Running just handle.exe -p cmd to get the handles for cmd.exe, I get the following output. Other output is similar, just much longer.

cmd.exe pid: 22916 NT AUTHORITY\SYSTEM 3C: File (RW-) C:\Windows 7C: File (RW-) C:\Program Files (x86)\ManageEngine\AssetExplorer\bin ------------------------------------------------------------------------------ cmd.exe pid: 22264 RADHSV\nsshinabarger 3C: File (RW-) C:\Users\nsshinabarger\Downloads\Handle 12C: File (R-D) C:\Windows\System32\en-US\cmd.exe.mui

I assume the R and W stand for read and write, but I can't seem to find documentation on what the D stands for. Could someone tell me what it stands for, or point me towards documentation?

Thank you!

2 Answers

Disclaimer: This answer explains with some in-depth of Windows kernel stuff.

Gist:

SharedAccess parameter from NtCreateFile().

| Name | ShareAccess | Value | |:----:|:-----------------:|:--------:| | R | FILE_SHARE_READ | 1 | | W | FILE_SHARE_WRITE | 2 | | D | FILE_SHARE_DELETE | 4 |

How it works

• The handle program gets the process ID from the process name. Then it passes the process ID/client ID to the Process Explorer's kernel mode driver aka. PROCEXP152.sys file. If the driver is not present it creates one.

• In kernel mode, 0x8335004C IOCTL query iterates all the associated objects/handles with that process and determines the object type with ZwQueryObject() and ObReferenceObjectByHandle().

• When a 'file' handle is received, with 0x83350048 IOCTL query, ZwOpenProcess() and ObReferenceObjectByHandle() creates a FILE_OBJECT structure.

• Then the kernel mode driver creates a bit-field by checking the shared access booleans, like this:

if (FileObject->SharedRead) Mode |= 1; if (FileObject->SharedWrite) Mode |= 2; if (FileObject->SharedDelete) Mode |= 4;

And the user mode program receives that 'Mode' and converts them into characters, like this:

FirstBit = '-'; SecondBit = '-'; if (Mode & 4) FirstBit = 'D'; ThirdBit = '-'; if (Mode & 2) ThirdBit = 'W'; if (Mode & 1) SecondBit = 'R';

This is the sharing mode of the file handle – see dwShareMode under CreateFile() in the Win32 API documentation.

Sharing mode is practically the opposite of "mandatory locks", the program specifies when opening a file whether other programs should be allowed to simultaneously open it. (I believe it dates back to MS-DOS era "LAN Manager" networking. See also SMB protocol documentation.)

The letters stand for read/write/delete.
