I'd Like to make any image from my ImageView to be circular with a border.
I searched but couldn't find any useful information (anything that I tried didn't work).
How can I achieve this through XML: Create an ImageView with certain src and make it circular with a border?
30 Answers
This is the simplest way that I designed. Try this.
dependencies
implementation 'androidx.appcompat:appcompat:1.3.0-beta01'
implementation 'androidx.cardview:cardview:1.0.0'
<android.support.v7.widget.CardView android:layout_width="80dp" android:layout_height="80dp" android:elevation="12dp" android:id="@+id/view2" app:cardCornerRadius="40dp" android:layout_centerHorizontal="true" android:innerRadius="0dp" android:shape="ring" android:thicknessRatio="1.9"> <ImageView android:layout_height="80dp" android:layout_width="match_parent" android:id="@+id/imageView1" android:src="@drawable/YOUR_IMAGE" android:layout_alignParentTop="true" android:layout_centerHorizontal="true"> </ImageView> </android.support.v7.widget.CardView>If you are working on android versions above lollipop
<android.support.v7.widget.CardView android:layout_width="80dp" android:layout_height="80dp" android:elevation="12dp" android:id="@+id/view2" app:cardCornerRadius="40dp" android:layout_centerHorizontal="true"> <ImageView android:layout_height="80dp" android:layout_width="match_parent" android:id="@+id/imageView1" android:src="@drawable/YOUR_IMAGE" android:scaleType="centerCrop"/> </android.support.v7.widget.CardView>
Adding Border to round ImageView - LATEST VERSION
Wrap it with another CardView slightly bigger than the inner one and set its background color to add a border to your round image. You can increase the size of the outer CardView to increase the thickness of the border.
<androidx.cardview.widget.CardView android:layout_width="155dp" android:layout_height="155dp" app:cardCornerRadius="250dp" app:cardBackgroundColor="@color/white"> <androidx.cardview.widget.CardView android:layout_width="150dp" android:layout_height="150dp" app:cardCornerRadius="250dp" android:layout_gravity="center"> <ImageView android:layout_width="150dp" android:layout_height="150dp" android:src="@drawable/default_user" android:scaleType="centerCrop"/> </androidx.cardview.widget.CardView> </androidx.cardview.widget.CardView> You can make a simple circle with white border and transparent content with shape.
// res/drawable/circle.xml <shape xmlns:android="" android:innerRadius="0dp" android:shape="ring" android:thicknessRatio="1.9" android:useLevel="false" > <solid android:color="@android:color/transparent" /> <stroke android:width="10dp" android:color="@android:color/white" /> </shape> Then make a layerlist drawable and put it as background to your imageview.
// res/drawable/img.xml <?xml version="1.0" encoding="utf-8"?> <layer-list xmlns:android="" > <item android:drawable="@drawable/circle"/> <item android:drawable="@drawable/ic_launcher"/> </layer-list> and put it as background to your imageview.
<ImageView android:layout_width="wrap_content" android:layout_height="wrap_content" android:background="@drawable/img"/> You'll have something like that.
I hope this will help you.
1) CircleImageView
<de.hdodenhof.circleimageview.CircleImageView xmlns:app="" android:id="@+id/profile_image" android:layout_width="96dp" android:layout_height="96dp" android:src="@drawable/profile" app:civ_border_width="2dp" app:civ_border_color="#FF000000"/> Don't forget implementation: Gradle Scripts > build.gradle (Module: app) > dependencies
implementation 'de.hdodenhof:circleimageview:3.1.0' For complete description please check here : The Source here.
2) CircularImageView
<com.mikhaellopez.circularimageview.CircularImageView android:layout_width="250dp" android:layout_height="250dp" android:src="@drawable/image" app:civ_border_color="#3f51b5" app:civ_border_width="4dp" app:civ_shadow="true" app:civ_shadow_radius="10" app:civ_shadow_color="#3f51b5"/> Don't forget implementation: Gradle Scripts > build.gradle (Module: app) > dependencies
implementation 'com.mikhaellopez:circularimageview:4.3.0' For complete description please check here : The Source here.
9With the Material Components Library Just use the ShapeableImageView.
Somethig like:
<com.google.android.material.imageview.ShapeableImageView app:shapeAppearanceOverlay="@style/roundedImageViewRounded" app:strokeColor="@color/....." app:strokeWidth="1dp" ... /> with:
<style name="roundedImageViewRounded"> <item name="cornerFamily">rounded</item> <item name="cornerSize">50%</item> </style>
Note: it requires at least the version 1.2.0.
With jetpack compose you can apply the clip Modifier using a CircleShape:
Image( painter = painterResource(R.drawable.xxxx), contentDescription = "xxxx", contentScale = ContentScale.Crop, modifier = Modifier .size(100.dp) .clip(CircleShape) .border(2.dp, Color.Blue, CircleShape) )
With the help of glide library and RoundedBitmapDrawableFactory class it's easy to achieve. You may need to create circular placeholder image.
Glide V4:
Glide.with(context).load(url).apply(RequestOptions.circleCropTransform()).into(imageView); Glide V3:
Glide.with(context) .load(imgUrl) .asBitmap() .placeholder(R.drawable.placeholder) .error(R.drawable.placeholder) .into(new BitmapImageViewTarget(imgProfilePicture) { @Override protected void setResource(Bitmap resource) { RoundedBitmapDrawable drawable = RoundedBitmapDrawableFactory.create(context.getResources(), Bitmap.createScaledBitmap(resource, 50, 50, false)); drawable.setCircular(true); imgProfilePicture.setImageDrawable(drawable); } }); For Picasso RoundedTransformation, this is a really great solution that gives an additional option of rounding image at either top or bottom edge.
5The above methods don't seem to work if you're using the src attribute. What I did is to put two image views inside a frame layout one above another like this:
<FrameLayout android:id="@+id/frame" android:layout_width="40dp" android:layout_height="40dp"> <ImageView android:id="@+id/pic" android:layout_width="40dp" android:layout_height="40dp" android:src="@drawable/my_picture" /> <ImageView android:id="@+id/circle_crop" android:layout_width="40dp" android:layout_height="40dp" android:src="@drawable/circle_crop" /> </FrameLayout> Simply put a circular_crop.png in your drawable folder which is in the shape of your image dimensions (a square in my case) with a white background and a transparent circle in the center. You can use this image if you have want a square imageview.
Just download the picture above.
5The following is one of the simplest ways to do it, use the following code:
Dependencies
dependencies { ... compile 'de.hdodenhof:circleimageview:2.1.0' // use this or use the latest compile version. In case u get bug. } XML Code
<de.hdodenhof.circleimageview.CircleImageView xmlns:app="" android:id="@+id/profile_image" android:layout_width="96dp" // here u can adjust the width android:layout_height="96dp" // here u can adjust the height android:src="@drawable/profile" // here u can change the image app:civ_border_width="2dp" // here u can adjust the border of the circle. app:civ_border_color="#FF000000"/> // here u can adjust the border color Screenshot:
Source: Circular ImageView GitHub Repository
you don't need any third-party library.
you can use the ShapeableImageView in the material.
implementation 'com.google.android.material:material:1.2.0' style.xml
<style name="ShapeAppearanceOverlay.App.CornerSize"> <item name="cornerSize">50%</item> </style> in layout
<com.google.android.material.imageview.ShapeableImageView android:layout_width="100dp" android:layout_height="100dp" app:srcCompat="@drawable/ic_profile" app:shapeAppearanceOverlay="@style/ShapeAppearanceOverlay.App.CornerSize" /> you can see this
or this
2You can simply use CardView without any external Library
<androidx.cardview.widget.CardView android:id="@+id/roundCardView" android:layout_width="40dp" android:layout_height="40dp" android:layout_centerHorizontal="true" android:elevation="0dp" app:cardCornerRadius="20dp"> <ImageView android:layout_width="40dp" android:layout_height="40dp" android:src="@drawable/profile" /> </androidx.cardview.widget.CardView> This will do the trick:
rectangle.xml
<?xml version="1.0" encoding="UTF-8"?> <shape xmlns:android="" android:shape="rectangle"> <solid android:color="@android:color/transparent" /> <padding android:bottom="-14dp" android:left="-14dp" android:right="-14dp" android:top="-14dp" /> </shape> circle.xml
<shape xmlns:android="" android:innerRadius="0dp" android:shape="oval" android:useLevel="false" > <solid android:color="@android:color/transparent" /> <stroke android:width="15dp" android:color="@color/verification_contact_background" /> </shape> profile_image.xml ( The layerlist )
<?xml version="1.0" encoding="utf-8"?> <layer-list xmlns:android="" > <item android:drawable="@drawable/rectangle" /> <item android:drawable="@drawable/circle"/> </layer-list> Your layout
<ImageView android:id="@+id/profile_image" android:layout_width="match_parent" android:layout_height="match_parent" android:background="@drawable/default_org" android:src="@drawable/profile_image"/> Best Solution courtesy the width and height of the card view determine the size of the images it contains set up is as follows:
- Add Dependency to Gradle(Module)
- Add the xml code to activity.xml or fragment.xml file
implementation 'androidx.cardview:cardview:1.0.0' <androidx.cardview.widget.CardView android:layout_width="300dp" android:layout_height="270dp" android:layout_gravity="center" app:cardCornerRadius="150dp" app:cardBackgroundColor="@color/trans" > <ImageView android:id="@+id/resultImage" android:layout_width="match_parent" android:layout_height="match_parent" android:src="@drawable/congrats" android:layout_gravity="center"> </ImageView> </androidx.cardview.widget.CardView> You can simply use AndroidX ImageFilterView.
<androidx.constraintlayout.utils.widget.ImageFilterView android:layout_width="48dp" android:layout_height="48dp" android:layout_marginStart="@dimen/margin_medium" android:layout_marginBottom="@dimen/margin_medium" android:background="@color/white" android:padding="@dimen/margin_small" app:layout_constraintBottom_toBottomOf="parent" app:layout_constraintStart_toStartOf="parent" app:roundPercent="1" app:srcCompat="@drawable/ic_gallery" />
I use shape = "oval" instead of the "ring" below. It has worked for me. To keep the image within bounds, I use <padding> and set <adjustViewBounds> to true in my <ImageView>. I have tried with images of size between 50 x 50 px upto 200x200 px .
Update 2021: Using Glide v4 CircleCrop see
implementation 'com.github.bumptech.glide:glide:4.11.0' annotationProcessor 'com.github.bumptech.glide:compiler:4.11.0' XML
<ImageView android:id="@+id/vinyl" android:layout_width="match_parent" android:layout_height="match_parent" tools:ignore="ContentDescription" /> In Code
Glide.with(this) .load("") .transform(CircleCrop()) .into(rootView.findViewById<ImageView>(R.id.vinyl))
Posting this answer for future reference. You can use ShapeableImageView available in com.google.android.material:material.
<com.google.android.material.imageview.ShapeableImageView android:id="@+id/img_launcher_icon" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_centerHorizontal="true" android:layout_margin="5dp" android:adjustViewBounds="true" android:background="@android:color/transparent" android:elevation="5dp" android:maxWidth="50dp" android:maxHeight="50dp" android:scaleType="fitXY" android:src="@mipmap/ic_launcher" app:shapeAppearance="?attr/actionButtonStyle" app:shapeAppearanceOverlay="@style/imageViewRounded" app:strokeColor="@android:color/white" /> Add imageViewRounded style in your styles.xml
<style name="imageViewRounded"> <item name="cornerFamily">rounded</item> <item name="cornerSize">51%</item> </style> You can add material design dependency if not added.
implementation 'com.google.android.material:material:1.4.0' Design looks like
@Jyotman Singh, answer is very good (for solid backgrounds), so I would like to enhance it by sharing vector drawable that can be re-colored for your needs, also it is convenient since vector one-piece shape is well scalable.
This is the rectangle-circle shape (@drawable/shape_round_profile_pic):
<?xml version="1.0" encoding="utf-8"?> <vector xmlns:android="" android:viewportWidth="284" android:viewportHeight="284" android:width="284dp" android:height="284dp"> <path android:pathData="M0 142L0 0l142 0 142 0 0 142 0 142 -142 0 -142 0zm165 137.34231c26.06742 -4.1212 52.67405 -17.543 72.66855 -36.65787 11.82805 -11.30768 20.55487 -22.85153 27.7633 -36.72531C290.23789 158.21592 285.62874 101.14121 253.48951 58.078079 217.58149 9.9651706 154.68849 -10.125717 98.348685 8.5190299 48.695824 24.95084 12.527764 67.047123 3.437787 118.98655 1.4806194 130.16966 1.511302 152.96723 3.4990422 164.5 12.168375 214.79902 47.646316 256.70775 96 273.76783c21.72002 7.66322 44.26673 9.48476 69 5.57448z" android:fillColor="#ffffff" /> // you can change frame color </vector> Usage is the same:
<FrameLayout android:layout_width="70dp" android:layout_height="70dp"> <ImageView android:layout_width="match_parent" android:layout_height="match_parent" android:background="@drawable/YOUR_PICTURE" /> <ImageView android:layout_width="match_parent" android:layout_height="match_parent" android:background="@drawable/shape_round_profile_pic"/> </FrameLayout> Just use these lines of code and you are done :
<de.hdodenhof.circleimageview.CircleImageView xmlns:app="" android:clickable="true" app:civ_border_width="3dp" app:civ_border_color="#FFFFFFFF" android:id="@+id/profile" android:layout_width="200dp" android:layout_height="200dp" android:layout_below="@+id/header_cover_image" android:layout_centerHorizontal="true" android:layout_marginTop="-130dp" android:elevation="5dp" android:padding="20dp" android:scaleType="centerCrop" android:src="@drawable/profilemain" />
Don't forget to import :
import de.hdodenhof.circleimageview.CircleImageView; Add this library in build.gradle :
compile 'de.hdodenhof:circleimageview:2.1.0' If you use Material Design in your app then use this
<com.google.android.material.card.MaterialCardView android:layout_width="75dp" android:layout_height="75dp" app:cardCornerRadius="50dp" app:strokeWidth="1dp" app:strokeColor="@color/black"> <ImageView android:layout_width="fill_parent" android:layout_height="fill_parent" android:id="@+id/circular_image" android:scaleType="fitCenter" android:src="@drawable/your_img" /> </com.google.android.material.card.MaterialCardView> I did it like that, I used my background color in my vector image
ic_bg_picture.xml
<vector xmlns:android="" android:width="100dp" android:height="100dp" android:viewportWidth="100" android:viewportHeight="100"> <path android:pathData="M100.6,95.5c0,-0.4 -0.1,-0.7 0,-1.1c-0.2,-0.7 -0.2,-1.4 -0.1,-2.1c0,-0.1 0,-0.2 0,-0.3c-0.1,-0.6 -0.1,-1.2 0,-1.8c-1,-1.3 -0.3,-2.9 -0.3,-4.3c-0.1,-28.7 -0.1,-57.3 -0.1,-86C68,-0.1 35.9,-0.1 3.8,-0.2C0.7,-0.2 0,0.5 0,3.6c0.1,32.1 0.1,64.2 0.1,96.2c31,0 62,-0.1 92.9,0.1c3.6,0 6.3,-0.2 7.5,-3.2C100.5,96.4 100.5,95.9 100.6,95.5zM46.3,95.2C26.4,94 2,74.4 3.8,46.8C5.1,27.2 24.4,2.7 52.6,4.6c20.2,1.4 43,21.3 41.5,45.1C96.1,72.4 73,96.8 46.3,95.2z" android:fillColor="#6200EE"/> </vector> in my case I created a vector and changed the android:fillColor="#6200EE"
by the color of my background
<ImageView android:id="@+id/iv_profile_image" android:layout_width="100dp" android:layout_height="100dp" android:contentDescription="@string/app_name" app:srcCompat="@color/colorPrimaryDark" /> <ImageView android:id="@+id/container_profile_image" android:layout_width="100dp" android:layout_height="100dp" android:contentDescription="@string/app_name" app:srcCompat="@drawable/ic_bg_picture"/>
Try this.
public class RoundedImageView extends android.support.v7.widget.AppCompatImageView { private int borderWidth = 4; private int viewWidth; private int viewHeight; private Bitmap image; private Paint paint; private Paint paintBorder; private BitmapShader shader; public RoundedImageView(Context context) { super(context); setup(); } public RoundedImageView(Context context, AttributeSet attrs) { super(context, attrs); setup(); } public RoundedImageView(Context context, AttributeSet attrs, int defStyle) { super(context, attrs, defStyle); setup(); } private void setup() { paint = new Paint(); paint.setAntiAlias(true); paintBorder = new Paint(); setBorderColor(Color.WHITE); paintBorder.setAntiAlias(true); this.setLayerType(LAYER_TYPE_SOFTWARE, paintBorder); paintBorder.setShadowLayer(4.0f, 0.0f, 2.0f, Color.WHITE); } public void setBorderWidth(int borderWidth) { this.borderWidth = borderWidth; this.invalidate(); } public void setBorderColor(int borderColor) { if (paintBorder != null) paintBorder.setColor(borderColor); this.invalidate(); } private void loadBitmap() { BitmapDrawable bitmapDrawable = (BitmapDrawable) this.getDrawable(); if (bitmapDrawable != null) image = bitmapDrawable.getBitmap(); } @SuppressLint("DrawAllocation") @Override public void onDraw(Canvas canvas) { loadBitmap(); if (image != null) { shader = new BitmapShader(Bitmap.createScaledBitmap(image, canvas.getWidth(), canvas.getHeight(), false), Shader.TileMode.CLAMP, Shader.TileMode.CLAMP); paint.setShader(shader); int circleCenter = viewWidth / 2; canvas.drawCircle(circleCenter + borderWidth, circleCenter + borderWidth, circleCenter + borderWidth - 4.0f, paintBorder); canvas.drawCircle(circleCenter + borderWidth, circleCenter + borderWidth, circleCenter - 4.0f, paint); } } @Override protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) { int width = measureWidth(widthMeasureSpec); int height = measureHeight(heightMeasureSpec, widthMeasureSpec); viewWidth = width - (borderWidth * 2); viewHeight = height - (borderWidth * 2); setMeasuredDimension(width, height); } private int measureWidth(int measureSpec) { int result = 0; int specMode = MeasureSpec.getMode(measureSpec); int specSize = MeasureSpec.getSize(measureSpec); if (specMode == MeasureSpec.EXACTLY) { result = specSize; } else { // Measure the text result = viewWidth; } return result; } private int measureHeight(int measureSpecHeight, int measureSpecWidth) { int result = 0; int specMode = MeasureSpec.getMode(measureSpecHeight); int specSize = MeasureSpec.getSize(measureSpecHeight); if (specMode == MeasureSpec.EXACTLY) { result = specSize; } else { result = viewHeight; } return (result + 2); } } and use this ImageView in layout like:
<com.app.Demo.RoundedImageView android:id="@+id/iv_profileImage" android:layout_width="70dp" android:layout_height="70dp" android:layout_centerHorizontal="true" /> This Class is Custom Circular Imageview with shadow, Stroke,saturation and using this Custom Circular ImageView you can make your image in Circular Shape with Radius. Guys for Circular Shadow ImageView No need Github this class is enough.
Adding CircularImageView to your layout
CircularImageView c=new CircularImageView(this,screen width,screen height,Bitmap myimage); yourLayout.addView(c);** public class CircularImageView extends android.support.v7.widget.AppCompatImageView { private final Context context; private final int width, height; private final Paint paint; private final Paint paintBorder,imagePaint; private final Bitmap bitmap2; private final Paint paint3; private Bitmap bitmap; private BitmapShader shader; private float radius = 4.0f; float x = 0.0f; float y = 8.0f; private float stroke; private float strokeWidth = 0.0f; private Bitmap bitmap3; private int corner_radius=50; public CircularImageView(Context context, int width, int height, Bitmap bitmap) { super(context); this.context = context; this.width = width; this.height = height; //here "bitmap" is the square shape(width* width) scaled bitmap .. this.bitmap = bitmap; paint = new Paint(Paint.ANTI_ALIAS_FLAG); paint.setAntiAlias(true); paint.setFilterBitmap(true); paint.setDither(true); paint3=new Paint(); paint3.setStyle(Paint.Style.STROKE); paint3.setColor(Color.WHITE); paint3.setAntiAlias(true); paintBorder = new Paint(); imagePaint= new Paint(); paintBorder.setColor(Color.WHITE); paintBorder.setAntiAlias(true); this.setLayerType(LAYER_TYPE_SOFTWARE, paintBorder); this.bitmap2 = Bitmap.createScaledBitmap(bitmap, (bitmap.getWidth() - 40), (bitmap.getHeight() - 40), true); imagePaint.setAntiAlias(true); invalidate(); } @Override protected void onDraw(Canvas canvas) { super.onDraw(canvas); Shader b; if (bitmap3 != null) b = new BitmapShader(bitmap3, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP); else b = new BitmapShader(bitmap2, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP); imagePaint.setShader(b); canvas.drawBitmap(maskedBitmap(), 20, 20, null); } private Bitmap maskedBitmap() { Bitmap l1 = Bitmap.createBitmap(width,width, Bitmap.Config.ARGB_8888); Canvas canvas = new Canvas(l1); paintBorder.setShadowLayer(radius, x, y, Color.parseColor("#454645")); paint.setXfermode(new PorterDuffXfermode(PorterDuff.Mode.SRC_IN)); final RectF rect = new RectF(); rect.set(20, 20, bitmap2.getWidth(), bitmap2.getHeight()); canvas.drawRoundRect(rect, corner_radius, corner_radius, paintBorder); canvas.drawRoundRect(rect, corner_radius, corner_radius, imagePaint); if (strokeWidth!=0.0f) { paint3.setStrokeWidth(strokeWidth); canvas.drawRoundRect(rect, corner_radius, corner_radius, paint3); } paint.setXfermode(null); return l1; } // use seekbar here, here you have to pass "0 -- 250" here corner radius will change public void setCornerRadius(int corner_radius) { this.corner_radius = corner_radius; invalidate(); } -------->use seekbar here, here you have to pass "0 -- 10.0f" here shadow radius will change public void setShadow(float radius) { this.radius = radius; invalidate(); } // use seekbar here, here you have to pass "0 -- 10.0f" here stroke size will change public void setStroke(float stroke) { this.strokeWidth = stroke; invalidate(); } private Bitmap updateSat(Bitmap src, float settingSat) { int w = src.getWidth(); int h = src.getHeight(); Bitmap bitmapResult = Bitmap.createBitmap(w, h, Bitmap.Config.ARGB_8888); Canvas canvasResult = new Canvas(bitmapResult); Paint paint = new Paint(); ColorMatrix colorMatrix = new ColorMatrix(); colorMatrix.setSaturation(settingSat); ColorMatrixColorFilter filter = new ColorMatrixColorFilter(colorMatrix); paint.setColorFilter(filter); canvasResult.drawBitmap(src, 0, 0, paint); return bitmapResult; } // use seekbar here, here you have to pass "0 -- 2.0f" here saturation will change public void setSaturation(float sat) { System.out.println("qqqqqqqqqq "+sat); bitmap3=updateSat(bitmap2, sat); invalidate(); } } // Seekbar to change radius radius_seekbar.setOnSeekBarChangeListener(new SeekBar.OnSeekBarChangeListener() { @Override public void onProgressChanged(SeekBar seekBar, int progress, boolean fromUser) { text_radius.setText(""+progress); circularImageView.setCornerRadius(progress); } @Override public void onStartTrackingTouch(SeekBar seekBar) { } @Override public void onStopTrackingTouch(SeekBar seekBar) { } }); // Seekbar to change shadow shadow_seekbar.setOnSeekBarChangeListener(new SeekBar.OnSeekBarChangeListener() { @Override public void onProgressChanged(SeekBar seekBar, int progress, boolean fromUser) { float f= 4+progress/10.0f; text_shadow.setText(""+progress); circularImageView.setShadow(f); } @Override public void onStartTrackingTouch(SeekBar seekBar) { } @Override public void onStopTrackingTouch(SeekBar seekBar) { } }); // Seekbar to change saturation saturation_seekbar.setOnSeekBarChangeListener(new SeekBar.OnSeekBarChangeListener() { @Override public void onProgressChanged(SeekBar seekBar, int progress, boolean fromUser) { int progressSat = saturation_seekbar.getProgress(); float sat = (float) ((progressSat*4 / 100.0f)-1.0f); circularImageView.setSaturation(sat); text_saturation.setText(""+progressSat); } @Override public void onStartTrackingTouch(SeekBar seekBar) { } @Override public void onStopTrackingTouch(SeekBar seekBar) { } }); // Seekbar to change stroke stroke_seekbar.setOnSeekBarChangeListener(new SeekBar.OnSeekBarChangeListener() { @Override public void onProgressChanged(SeekBar seekBar, int progress, boolean fromUser) { if (progress==0) { float f=(progress*10.0f/100.0f); circularImageView.setStroke(f); } else { float f=(progress*10.0f/100.0f); circularImageView.setStroke(f); } text_stroke.setText(""+progress); } @Override public void onStartTrackingTouch(SeekBar seekBar) { } @Override public void onStopTrackingTouch(SeekBar seekBar) { } }); //radius seekbar in xml file <SeekBar android:layout_width="match_parent" android:layout_gravity="center" android:progress="50" android:max="250" android:id="@+id/radius_seekbar" android:layout_height="wrap_content" /> //saturation seekbar in xml file <SeekBar android:layout_width="match_parent" android:layout_gravity="center" android:progress="50" android:max="100" android:id="@+id/saturation_seekbar" android:layout_height="wrap_content" /> //shadow seekbar in xml file <SeekBar android:layout_width="match_parent" android:layout_gravity="center" android:progress="0" android:max="100" android:id="@+id/shadow_seekbar" android:layout_height="wrap_content" /> //stroke seekbar in xml file <SeekBar android:layout_width="match_parent" android:layout_gravity="center" android:progress="0" android:max="100" android:id="@+id/stroke _seekbar" android:layout_height="wrap_content" /> Actually, you can use what Google provides via the support library RoundedBitmapDrawableFactory class (here and here), instead of using a third party library :
Gradle:
implementation 'androidx.appcompat:appcompat:1.0.0-beta01' MainActivity.kt
class MainActivity : AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContentView(R.layout.activity_main) val originalDrawable = ContextCompat.getDrawable(this, R.drawable.avatar_1)!! val bitmap = convertDrawableToBitmap(originalDrawable) val drawable = RoundedBitmapDrawableFactory.create(resources, bitmap) drawable.setAntiAlias(true) drawable.cornerRadius = Math.max(bitmap.width, bitmap.height) / 2.0f avatarImageView.setImageDrawable(drawable) } companion object { @JvmStatic fun convertDrawableToBitmap(drawable: Drawable): Bitmap { if (drawable is BitmapDrawable) return drawable.bitmap // We ask for the bounds if they have been set as they would be most // correct, then we check we are > 0 val bounds = drawable.bounds val width = if (!bounds.isEmpty) bounds.width() else drawable.intrinsicWidth val height = if (!bounds.isEmpty) bounds.height() else drawable.intrinsicHeight // Now we check we are > 0 val bitmap = Bitmap.createBitmap(if (width <= 0) 1 else width, if (height <= 0) 1 else height, Bitmap.Config.ARGB_8888) val canvas = Canvas(bitmap) drawable.setBounds(0, 0, canvas.width, canvas.height) drawable.draw(canvas) return bitmap } } } res/layout/activity_main.xml
<FrameLayout xmlns:android="" xmlns:app="" xmlns:tools="" android:layout_width="match_parent" android:layout_height="match_parent" tools:context=".MainActivity"> <androidx.appcompat.widget.AppCompatImageView android:id="@+id/avatarImageView" android:layout_width="100dp" android:layout_height="100dp" android:layout_gravity="center"/> </FrameLayout> res/drawable/avatar_1.xml
<vector xmlns:android="" android:width="128dp" android:height="128dp" android:viewportHeight="128.0" android:viewportWidth="128.0"> <path android:fillColor="#FF8A80" android:pathData="M0 0h128v128h-128z"/> <path android:fillColor="#FFE0B2" android:pathData="M36.3 94.8c6.4 7.3 16.2 12.1 27.3 12.4 10.7,-.3 20.3,-4.7 26.7,-11.6l.2.1c-17,-13.3,-12.9,-23.4,-8.5,-28.6 1.3,-1.2 2.8,-2.5 4.4,-3.9l13.1,-11c1.5,-1.2 2.6,-3 2.9,-5.1.6,-4.4,-2.5,-8.4,-6.9,-9.1,-1.5,-.2,-3 0,-4.3.6,-.3,-1.3,-.4,-2.7,-1.6,-3.5,-1.4,-.9,-2.8,-1.7,-4.2,-2.5,-7.1,-3.9,-14.9,-6.6,-23,-7.9,-5.4,-.9,-11,-1.2,-16.1.7,-3.3 1.2,-6.1 3.2,-8.7 5.6,-1.3 1.2,-2.5 2.4,-3.7 3.7l-1.8 1.9c-.3.3,-.5.6,-.8.8,-.1.1,-.2 0,-.4.2.1.2.1.5.1.6,-1,-.3,-2.1,-.4,-3.2,-.2,-4.4.6,-7.5 4.7,-6.9 9.1.3 2.1 1.3 3.8 2.8 5.1l11 9.3c1.8 1.5 3.3 3.8 4.6 5.7 1.5 2.3 2.8 4.9 3.5 7.6 1.7 6.8,-.8 13.4,-5.4 18.4,-.5.6,-1.1 1,-1.4 1.7,-.2.6,-.4 1.3,-.6 2,-.4 1.5,-.5 3.1,-.3 4.6.4 3.1 1.8 6.1 4.1 8.2 3.3 3 8 4 12.4 4.5 5.2.6 10.5.7 15.7.2 4.5,-.4 9.1,-1.2 13,-3.4 5.6,-3.1 9.6,-8.9 10.5,-15.2m-14.4,-49.8c.9 0 1.6.7 1.6 1.6 0 .9,-.7 1.6,-1.6 1.6,-.9 0,-1.6,-.7,-1.6,-1.6,-.1,-.9.7,-1.6 1.6,-1.6zm-25.7 0c.9 0 1.6.7 1.6 1.6 0 .9,-.7 1.6,-1.6 1.6,-.9 0,-1.6,-.7,-1.6,-1.6,-.1,-.9.7,-1.6 1.6,-1.6z"/> <path android:fillColor="#E0F7FA" android:pathData="M105.3 106.1c-.9,-1.3,-1.3,-1.9,-1.3,-1.9l-.2,-.3c-.6,-.9,-1.2,-1.7,-1.9,-2.4,-3.2,-3.5,-7.3,-5.4,-11.4,-5.7 0 0 .1 0 .1.1l-.2,-.1c-6.4 6.9,-16 11.3,-26.7 11.6,-11.2,-.3,-21.1,-5.1,-27.5,-12.6,-.1.2,-.2.4,-.2.5,-3.1.9,-6 2.7,-8.4 5.4l-.2.2s-.5.6,-1.5 1.7c-.9 1.1,-2.2 2.6,-3.7 4.5,-3.1 3.9,-7.2 9.5,-11.7 16.6,-.9 1.4,-1.7 2.8,-2.6 4.3h109.6c-3.4,-7.1,-6.5,-12.8,-8.9,-16.9,-1.5,-2.2,-2.6,-3.8,-3.3,-5z"/> <path android:fillColor="#444" android:pathData="M76.3,47.5 m-2.0, 0 a 2.0,2.0 0 1,1 4.0,0 a2.0,2.0 0 1,1 -4.0,0"/> <path android:fillColor="#444" android:pathData="M50.7,47.6 m-2.0, 0 a 2.0,2.0 0 1,1 4.0,0 a2.0,2.0 0 1,1 -4.0,0"/> <path android:fillColor="#444" android:pathData="M48.1 27.4c4.5 5.9 15.5 12.1 42.4 8.4,-2.2,-6.9,-6.8,-12.6,-12.6,-16.4 17.2 1.5 14.1,-9.4 14.1,-9.4,-1.4 5.5,-11.1 4.4,-11.1 4.4h-18.8c-1.7,-.1,-3.4 0,-5.2.3,-12.8 1.8,-22.6 11.1,-25.7 22.9 10.6,-1.9 15.3,-7.6 16.9,-10.2z"/> </vector> The result:
And, suppose you want to add a border on top of it, you can use this for example:
stroke_drawable.xml
<shape xmlns:android="" android:shape="oval"> <stroke android:width="4dp" android:color="@android:color/black"/> </shape> And add android:foreground="@drawable/stroke_drawable" to the ImageView in the layout XML file, and you get this :
I'm not sure how to add shadow (that will work on older Android versions), though. Using FloatingActionButton (from the "com.google.android.material:material" dependency), I failed to make the bitmap fill the FAB itself. Using it instead could be even better if it worked.
EDIT: if you wish to add shadow of elevation (available from API 21), you can change a bit what I wrote:
Inside the layout XML file:
<androidx.appcompat.widget.AppCompatImageView android:padding="4dp" android:id="@+id/avatarImageView" android:layout_width="100dp" android:layout_height="100dp" android:elevation="8dp" android:layout_gravity="center" android:background="@drawable/stroke_drawable" tools:srcCompat="@drawable/avatar_1"/> CircularShadowViewOutlineProvider.kt
@TargetApi(Build.VERSION_CODES.LOLLIPOP) class CircularShadowViewOutlineProvider : ViewOutlineProvider() { override fun getOutline(view: View, outline: Outline) { val size = Math.max(view.width, view.height) outline.setRoundRect(0, 0, size, size, size / 2f) } } In code:
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) avatarImageView.outlineProvider = CircularShadowViewOutlineProvider() Result:
I have a simple solution. Create a new Image asset by right clicking your package name and selecting New->Image asset. Enter name (any name) and path (location of image in your system). Then click Next and Finish. If you enter name of image as 'img', a round image with the name 'img_round' is created automatically in mipmap folder.
Then, do this :
<ImageView android:layout_width="100dp" android:layout_height="100dp" android:src="@mipmap/img_round"/> Your preview may still show a rectangular image. But if you run the app on your device, it will be round.
Create a CustomImageview then simply override its onDraw() method follows:
@Override protected void onDraw(Canvas canvas) { float radius = this.getHeight()/2; Path path = new Path(); RectF rect = new RectF(0, 0, this.getWidth(), this.getHeight()); path.addRoundRect(rect, radius, radius, Path.Direction.CW); canvas.clipPath(path); super.onDraw(canvas); } In case you want the code for the custom widget as well:-
CircularImageView.java
import android.content.Context; import android.content.res.TypedArray; import android.graphics.Canvas; import android.graphics.Path; import android.graphics.RectF; import android.graphics.drawable.Drawable; import android.util.AttributeSet; import android.widget.ImageView; import androidx.annotation.Nullable; public class CircularImageView extends ImageView { private Drawable image; public CircularImageView(Context context) { super(context); init(null, 0); } public CircularImageView(Context context, @Nullable AttributeSet attrs) { super(context, attrs); init(attrs, 0); } public CircularImageView(Context context, @Nullable AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr); init(attrs, defStyleAttr); } @Override protected void onDraw(Canvas canvas) { float radius = this.getHeight()/2; Path path = new Path(); RectF rect = new RectF(0, 0, this.getWidth(), this.getHeight()); path.addRoundRect(rect, radius, radius, Path.Direction.CW); canvas.clipPath(path); super.onDraw(canvas); } private void init(AttributeSet attrs, int defStyle) { TypedArray a = Utils.CONTEXT.getTheme().obtainStyledAttributes(attrs, R.styleable.CircularImageView, 0, 0); try { image = a.getDrawable(R.styleable.CircularImageView_src); } finally { a.recycle(); } this.setImageDrawable(image); } } Also, add the following code to your res/attrs.xml to create the required attribute:-
<declare-styleable name="CircularImageView"> <attr name="src" format="reference" /> </declare-styleable> if you want to set edit icon on to circle imageview than put this below code. <FrameLayout android:layout_width="@dimen/_100sdp" android:layout_height="@dimen/_100sdp" android:layout_gravity="center" android:layout_marginTop="10dp"> <de.hdodenhof.circleimageview.CircleImageView android:id="@+id/profilePic" android:layout_width="@dimen/_100sdp" android:layout_height="@dimen/_100sdp" android:layout_gravity="bottom|center_horizontal" android:src="@drawable/ic_upload" /> <de.hdodenhof.circleimageview.CircleImageView android:id="@+id/iv_camera" android:layout_width="@dimen/_30sdp" android:layout_height="@dimen/_30sdp" android:layout_gravity="top|right" android:src="@drawable/edit"/> </FrameLayout> if you'd rather cut the image to display in circular, here you go
public static Bitmap getCircularBitmap(Bitmap bitmap) { Bitmap output; if (bitmap.getWidth() > bitmap.getHeight()) { output = Bitmap.createBitmap(bitmap.getHeight(), bitmap.getHeight(), Bitmap.Config.ARGB_8888); } else { output = Bitmap.createBitmap(bitmap.getWidth(), bitmap.getWidth(), Bitmap.Config.ARGB_8888); } Canvas canvas = new Canvas(output); final int color = 0xff424242; final Paint paint = new Paint(); final Rect rect = new Rect(0, 0, bitmap.getWidth(), bitmap.getHeight()); float r = 0; if (bitmap.getWidth() > bitmap.getHeight()) { r = bitmap.getHeight() / 2; } else { r = bitmap.getWidth() / 2; } paint.setAntiAlias(true); canvas.drawARGB(0, 0, 0, 0); paint.setColor(color); canvas.drawCircle(r, r, r, paint); paint.setXfermode(new PorterDuffXfermode(PorterDuff.Mode.SRC_IN)); canvas.drawBitmap(bitmap, rect, rect, paint); return output; } Another idea is to use clipToOutline property of an ImageView.
Here is an example layout:
<androidx.constraintlayout.widget.ConstraintLayout android:layout_width="match_parent" android:layout_height="match_parent"> <!-- Simple view to draw borders for an image, borders will be rounded because of the oval-shaped background. --> <View android:id="@+id/v_border" android:layout_width="50dp" android:layout_height="50dp" android:background="@drawable/shape_border" app:layout_constraintStart_toStartOf="parent" app:layout_constraintTop_toTopOf="parent" /> <!-- Image itself: fits the border view, a margin serves as a border width; the key point here - is a background shape which will clip the view to its forms. --> <ImageView android:id="@+id/iv_image" android:layout_width="0dp" android:layout_height="0dp" android:layout_margin="4dp" android:background="@drawable/shape_oval" android:src="@mipmap/ic_launcher" app:layout_constraintBottom_toBottomOf="@+id/v_border" app:layout_constraintEnd_toEndOf="@+id/v_border" app:layout_constraintStart_toStartOf="@+id/v_border" app:layout_constraintTop_toTopOf="@+id/v_border" /> </androidx.constraintlayout.widget.ConstraintLayout> And here are our shape_border drawable:
<?xml version="1.0" encoding="utf-8"?> <shape xmlns:android="" android:shape="oval"> <solid android:color="#FF00FF" /> </shape> And shape_oval drawable:
<?xml version="1.0" encoding="utf-8"?> <shape xmlns:android="" android:shape="oval" /> The only thing you should do in the code - is to enable clipToOutline property:
binding.ivImage.clipToOutline = true And of course you can avoid even this line of the code with some BindingAdapter.
This is a relatively old question, but you can just make a circle border in the drawable folder (let's assume the xml file will be called circle_border)
<?xml version="1.0" encoding="utf-8"?> <shape xmlns="" android:shape="oval"> <solid android:color="@android:color/transparent" /> <!-- If you want a padding --> <padding android:top="4dp" android:left="4dp" android:right="4dp" android:bottom="4dp" /> <!-- If you want the circle border to have a color --> <strong android:width="1dp" android:color="#FFFFFF" /> </shape> Then you can use it as the background of the ImageView
<ImageView android:background="@drawable/circle_border" <!-- other attributes here --> /> just use this simple code: First add dependency :
implementation 'de.hdodenhof:circleimageview:2.2.0' then add in xml layout the following code:-
<de.hdodenhof.circleimageview.CircleImageView xmlns:app="" android:id="@+id/Imgshaligram" android:layout_width="96dp" android:layout_height="96dp" android:src="@drawable/shaligram" app:civ_border_color="#d1b1b1" android:foregroundGravity="center"/> also, these two libraries can help you.
implement below code:
implementation 'com.makeramen:roundedimageview:2.3.0' Simple Usage:
<com.makeramen.roundedimageview.RoundedImageView xmlns:app="" android:id="@+id/imageView1" android:src="@drawable/photo1" android:scaleType="fitCenter" app:riv_corner_radius="30dip" app:riv_border_width="2dip" app:riv_border_color="#333333" app:riv_mutate_background="true" app:riv_tile_mode="repeat" app:riv_oval="true" /> Simple Usage:
implement below code:
implementation 'com.github.chirag-kachhadiya:RoundedImageView:1.0' <com.infinityandroid.roundedimageview.RoundedImageView android:layout_width="150dp" android:layout_height="wrap_content" android:layout_margin="10dp" android:adjustViewBounds="true" android:src="@drawable/the_hundred" app:corner_radius="10" />
