How to setup and save vlans on ethernet

I am trying to setup vlans on my eth0 network card. The following are the steps that I've taken:

1. Install vlan with sudo apt-get install vlan

2. Edit /etc/network/interfaces in vi by adding:

   auto eth0.100 iface eth0.100 inet dhcp

3. Restarted networking and/or restarted Ubuntu

4. Ran ifconfig

I don't see the eth0.100 listed, I'm not sure what I am doing wrong.

I can add vlans using vconfig but they don't stay after a reboot.

2 Answers

First you must install vlan

sudo apt-get install vlan

load kernel module

sudo modprobe 8021q

Create a new interface that is a member of a specific VLAN, VLAN id 100

We use the physical interface eth0 in this example. This command will add an additional interface next to the interfaces which have been configured already

sudo vconfig add eth0 100

Assign an address to the new interface:

sudo ip addr add 10.0.0.1/24 dev eth0.100

To make this setup permanent. Add the module to the kernel on boot

sudo bash -c 'echo "8021q" >> /etc/modules'

Create the interface and make it available when the system boots. Add the following lines to /etc/network/interfaces

auto eth0.100 iface eth0.100 inet dhcp vlan-raw-device eth0

The modern way to create a VLAN interface is using ip link from iproute2. Assuming you want to run the VLAN over interface eno1:

sudo ip link add link eno1 name vlan100 type vlan id 100

Now optionally give it an address:

sudo ip address add 10.0.0.100/24 dev vlan100

And bring it up:

sudo ip link set vlan100 up

To make this permanent, define the vlan interface in /etc/netplan/*. This will look like:

network: version: 2 ethernets: eno1: ... eno1 config ... vlans: vlan100: id: 100 link: eno1 addresses: [10.0.0.100/24]

Detailed documentation is in the netplan reference.
