How to set Rx queue = N in linux / in Qemu / KVM?

I have configured 8 multiple queues on my CentOS VM box (running on KVM).

<interface type='direct' trustGuestRxFilters='yes'> <source dev='ens113f0' mode='passthrough'/> <model type='virtio'/> <driver name='vhost' queues='8'/> </interface>

I can find 8 queues are created on VM using ethtool.

[centos@vm ~]$ ethtool -l eth1 Channel parameters for eth1: Pre-set maximums: RX: 0 TX: 0 Other: 0 Combined: 8 Current hardware settings: RX: 0 TX: 0 Other: 0 Combined: 4

Now, I wanted to restrict 1 RX queue and 2 TX queues for my DPDK application. I am trying to set the same using ethtool but it is throwing below error:

[centos@vm ~]$ sudo ethtool -L eth1 rx 1 tx 2 Cannot set device channel parameters: Invalid argument

I can set combined queues = 2 but not specific RX / TX queues.

[centos@vm ~]$ sudo ethtool -L eth1 combined 2 [centos@vm ~]$ ethtool -l eth1 Channel parameters for eth1: Pre-set maximums: RX: 0 TX: 0 Other: 0 Combined: 8 Current hardware settings: RX: 0 TX: 0 Other: 0 Combined: 2

Any reason / justification of it??

Is there any other way I can set RX queues and TX queues in linux?

Is there any way I can specify RX & TX queues size in libvirt XML / Qemu command? I googled it before posting this question but couldn't find anything.

Thank you.

1 Answer

DPDK RX-TX configuration is controlled by using rte_eth_dev_configure. Hence it only makes sense to bind the NIC to igb_uio, uio_pci_generic or vfio-pci and execute the configure API with apt number of RX and TX queue. Setting from ethtool is incorrect for DPDK port.
