This is what I've got so far but it is not working:
class Node: rChild,lChild,data = None,None,None def __init__(self,key): self.rChild = None self.lChild = None self.data = key class Tree: root,size = None,0 def __init__(self): self.root = None self.size = 0 def insert(self,node,someNumber): if node is None: node = Node(someNumber) else: if node.data > someNumber: self.insert(node.rchild,someNumber) else: self.insert(node.rchild, someNumber) return def main(): t = Tree() t.root = Node(4) t.root.rchild = Node(5) print t.root.data #this works print t.root.rchild.data #this works too t = Tree() t.insert(t.root,4) t.insert(t.root,5) print t.root.data #this fails print t.root.rchild.data #this fails too if __name__ == '__main__': main() 18 Answers
Here is a quick example of a binary insert:
class Node: def __init__(self, val): self.l_child = None self.r_child = None self.data = val def binary_insert(root, node): if root is None: root = node else: if root.data > node.data: if root.l_child is None: root.l_child = node else: binary_insert(root.l_child, node) else: if root.r_child is None: root.r_child = node else: binary_insert(root.r_child, node) def in_order_print(root): if not root: return in_order_print(root.l_child) print root.data in_order_print(root.r_child) def pre_order_print(root): if not root: return print root.data pre_order_print(root.l_child) pre_order_print(root.r_child) r = Node(3) binary_insert(r, Node(7)) binary_insert(r, Node(1)) binary_insert(r, Node(5)) 3 / \ 1 7 / 5 print "in order:" in_order_print(r) print "pre order" pre_order_print(r) in order: 1 3 5 7 pre order 3 1 7 5 class Node: rChild,lChild,data = None,None,None This is wrong - it makes your variables class variables - that is, every instance of Node uses the same values (changing rChild of any node changes it for all nodes!). This is clearly not what you want; try
class Node: def __init__(self, key): self.rChild = None self.lChild = None self.data = key now each node has its own set of variables. The same applies to your definition of Tree,
class Tree: root,size = None,0 # <- lose this line! def __init__(self): self.root = None self.size = 0 Further, each class should be a "new-style" class derived from the "object" class and should chain back to object.__init__():
class Node(object): def __init__(self, data, rChild=None, lChild=None): super(Node,self).__init__() self.data = data self.rChild = rChild self.lChild = lChild class Tree(object): def __init__(self): super(Tree,self).__init__() self.root = None self.size = 0 Also, main() is indented too far - as shown, it is a method of Tree which is uncallable because it does not accept a self argument.
Also, you are modifying the object's data directly (t.root = Node(4)) which kind of destroys encapsulation (the whole point of having classes in the first place); you should be doing something more like
def main(): t = Tree() t.add(4) # <- let the tree create a data Node and insert it t.add(5) class Node: rChild,lChild,parent,data = None,None,None,0 def __init__(self,key): self.rChild = None self.lChild = None self.parent = None self.data = key class Tree: root,size = None,0 def __init__(self): self.root = None self.size = 0 def insert(self,someNumber): self.size = self.size+1 if self.root is None: self.root = Node(someNumber) else: self.insertWithNode(self.root, someNumber) def insertWithNode(self,node,someNumber): if node.lChild is None and node.rChild is None:#external node if someNumber > node.data: newNode = Node(someNumber) node.rChild = newNode newNode.parent = node else: newNode = Node(someNumber) node.lChild = newNode newNode.parent = node else: #not external if someNumber > node.data: if node.rChild is not None: self.insertWithNode(node.rChild, someNumber) else: #if empty node newNode = Node(someNumber) node.rChild = newNode newNode.parent = node else: if node.lChild is not None: self.insertWithNode(node.lChild, someNumber) else: newNode = Node(someNumber) node.lChild = newNode newNode.parent = node def printTree(self,someNode): if someNode is None: pass else: self.printTree(someNode.lChild) print someNode.data self.printTree(someNode.rChild) def main(): t = Tree() t.insert(5) t.insert(3) t.insert(7) t.insert(4) t.insert(2) t.insert(1) t.insert(6) t.printTree(t.root) if __name__ == '__main__': main() My solution.
class BST: def __init__(self, val=None): self.left = None self.right = None self.val = val def __str__(self): return "[%s, %s, %s]" % (self.left, str(self.val), self.right) def isEmpty(self): return self.left == self.right == self.val == None def insert(self, val): if self.isEmpty(): self.val = val elif val < self.val: if self.left is None: self.left = BST(val) else: self.left.insert(val) else: if self.right is None: self.right = BST(val) else: self.right.insert(val) a = BST(1) a.insert(2) a.insert(3) a.insert(0) print a The Op's Tree.insert method qualifies for the "Gross Misnomer of the Week" award -- it doesn't insert anything. It creates a node which is not attached to any other node (not that there are any nodes to attach it to) and then the created node is trashed when the method returns.
For the edification of @Hugh Bothwell:
>>> class Foo(object): ... bar = None ... >>> a = Foo() >>> b = Foo() >>> a.bar >>> a.bar = 42 >>> b.bar >>> b.bar = 666 >>> a.bar 42 >>> b.bar 666 >>> The accepted answer neglects to set a parent attribute for each node inserted, without which one cannot implement a successor method which finds the successor in an in-order tree walk in O(h) time, where h is the height of the tree (as opposed to the O(n) time needed for the walk).
Here is an implementation based on the pseudocode given in Cormen et al., Introduction to Algorithms, including assignment of a parent attribute and a successor method:
class Node(object): def __init__(self, key): self.key = key self.left = None self.right = None self.parent = None class Tree(object): def __init__(self, root=None): self.root = root def insert(self, z): y = None x = self.root while x is not None: y = x if z.key < x.key: x = x.left else: x = x.right z.parent = y if y is None: self.root = z # Tree was empty elif z.key < y.key: y.left = z else: y.right = z @staticmethod def minimum(x): while x.left is not None: x = x.left return x @staticmethod def successor(x): if x.right is not None: return Tree.minimum(x.right) y = x.parent while y is not None and x == y.right: x = y y = y.parent return y Here are some tests to show that the tree behaves as expected for the example given by DTing:
import pytest @pytest.fixture def tree(): t = Tree() t.insert(Node(3)) t.insert(Node(1)) t.insert(Node(7)) t.insert(Node(5)) return t def test_tree_insert(tree): assert tree.root.key == 3 assert tree.root.left.key == 1 assert tree.root.right.key == 7 assert tree.root.right.left.key == 5 def test_tree_successor(tree): assert Tree.successor(tree.root.left).key == 3 assert Tree.successor(tree.root.right.left).key == 7 if __name__ == "__main__": pytest.main([__file__]) Just something to help you to start on.
A (simple idea of) binary tree search would be quite likely be implement in python according the lines:
def search(node, key): if node is None: return None # key not found if key< node.key: return search(node.left, key) elif key> node.key: return search(node.right, key) else: return node.value # found key Now you just need to implement the scaffolding (tree creation and value inserts) and you are done.
1I find the solutions a bit clumsy on the insert part. You could return the root reference and simplify it a bit:
def binary_insert(root, node): if root is None: return node if root.data > node.data: root.l_child = binary_insert(root.l_child, node) else: root.r_child = binary_insert(root.r_child, node) return root its easy to implement a BST using two classes, 1. Node and 2. Tree Tree class will be just for user interface, and actual methods will be implemented in Node class.
class Node(): def __init__(self,val): self.value = val self.left = None self.right = None def _insert(self,data): if data == self.value: return False elif data < self.value: if self.left: return self.left._insert(data) else: self.left = Node(data) return True else: if self.right: return self.right._insert(data) else: self.right = Node(data) return True def _inorder(self): if self: if self.left: self.left._inorder() print(self.value) if self.right: self.right._inorder() class Tree(): def __init__(self): self.root = None def insert(self,data): if self.root: return self.root._insert(data) else: self.root = Node(data) return True def inorder(self): if self.root is not None: return self.root._inorder() else: return False if __name__=="__main__": a = Tree() a.insert(16) a.insert(8) a.insert(24) a.insert(6) a.insert(12) a.insert(19) a.insert(29) a.inorder() Inorder function for checking whether BST is properly implemented.
Another Python BST with sort key (defaulting to value)
LEFT = 0 RIGHT = 1 VALUE = 2 SORT_KEY = -1 class BinarySearchTree(object): def __init__(self, sort_key=None): self._root = [] self._sort_key = sort_key self._len = 0 def insert(self, val): if self._sort_key is None: sort_key = val // if no sort key, sort key is value else: sort_key = self._sort_key(val) node = self._root while node: if sort_key < node[_SORT_KEY]: node = node[LEFT] else: node = node[RIGHT] if sort_key is val: node[:] = [[], [], val] else: node[:] = [[], [], val, sort_key] self._len += 1 def minimum(self): return self._extreme_node(LEFT)[VALUE] def maximum(self): return self._extreme_node(RIGHT)[VALUE] def find(self, sort_key): return self._find(sort_key)[VALUE] def _extreme_node(self, side): if not self._root: raise IndexError('Empty') node = self._root while node[side]: node = node[side] return node def _find(self, sort_key): node = self._root while node: node_key = node[SORT_KEY] if sort_key < node_key: node = node[LEFT] elif sort_key > node_key: node = node[RIGHT] else: return node raise KeyError("%r not found" % sort_key) Here is a compact, object oriented, recursive implementation:
class BTreeNode(object): def __init__(self, data): self.data = data self.rChild = None self.lChild = None def __str__(self): return (self.lChild.__str__() + '<-' if self.lChild != None else '') + self.data.__str__() + ('->' + self.rChild.__str__() if self.rChild != None else '') def insert(self, btreeNode): if self.data > btreeNode.data: #insert left if self.lChild == None: self.lChild = btreeNode else: self.lChild.insert(btreeNode) else: #insert right if self.rChild == None: self.rChild = btreeNode else: self.rChild.insert(btreeNode) def main(): btreeRoot = BTreeNode(5) print 'inserted %s:' %5, btreeRoot btreeRoot.insert(BTreeNode(7)) print 'inserted %s:' %7, btreeRoot btreeRoot.insert(BTreeNode(3)) print 'inserted %s:' %3, btreeRoot btreeRoot.insert(BTreeNode(1)) print 'inserted %s:' %1, btreeRoot btreeRoot.insert(BTreeNode(2)) print 'inserted %s:' %2, btreeRoot btreeRoot.insert(BTreeNode(4)) print 'inserted %s:' %4, btreeRoot btreeRoot.insert(BTreeNode(6)) print 'inserted %s:' %6, btreeRoot The output of the above main() is:
inserted 5: 5 inserted 7: 5->7 inserted 3: 3<-5->7 inserted 1: 1<-3<-5->7 inserted 2: 1->2<-3<-5->7 inserted 4: 1->2<-3->4<-5->7 inserted 6: 1->2<-3->4<-5->6<-7 Here is a working solution.
class BST: def __init__(self,data): self.root = data self.left = None self.right = None def insert(self,data): if self.root == None: self.root = BST(data) elif data > self.root: if self.right == None: self.right = BST(data) else: self.right.insert(data) elif data < self.root: if self.left == None: self.left = BST(data) else: self.left.insert(data) def inordertraversal(self): if self.left != None: self.left.inordertraversal() print (self.root), if self.right != None: self.right.inordertraversal() t = BST(4) t.insert(1) t.insert(7) t.insert(3) t.insert(6) t.insert(2) t.insert(5) t.inordertraversal() A simple, recursive method with only 1 function and using an array of values:
class TreeNode(object): def __init__(self, value: int, left=None, right=None): super().__init__() self.value = value self.left = left self.right = right def __str__(self): return str(self.value) def create_node(values, lower, upper) -> TreeNode: if lower > upper: return None index = (lower + upper) // 2 value = values[index] node = TreeNode(value=value) node.left = create_node(values, lower, index - 1) node.right = create_node(values, index + 1, upper) return node def print_bst(node: TreeNode): if node: # Simple pre-order traversal when printing the tree print("node: {}".format(node)) print_bst(node.left) print_bst(node.right) if __name__ == '__main__': vals = [0, 1, 2, 3, 4, 5, 6] bst = create_node(vals, lower=0, upper=len(vals) - 1) print_bst(bst) As you can see, we really only need 1 method, which is recursive: create_node. We pass in the full values array in each create_node method call, however, we update the lower and upper index values every time that we make the recursive call.
Then, using the lower and upper index values, we calculate the index value of the current node and capture it in value. This value is the value for the current node, which we use to create a node.
From there, we set the values of left and right by recursively calling the function, until we reach the end state of the recursion call when lower is greater than upper.
Important: we update the value of upper when creating the left side of the tree. Conversely, we update the value of lower when creating the right side of the tree.
Hopefully this helps!
1The following code is basic on @DTing‘s answer and what I learn from class, which uses a while loop to insert (indicated in the code).
class Node: def __init__(self, val): self.l_child = None self.r_child = None self.data = val def binary_insert(root, node): y = None x = root z = node #while loop here while x is not None: y = x if z.data < x.data: x = x.l_child else: x = x.r_child z.parent = y if y == None: root = z elif z.data < y.data: y.l_child = z else: y.r_child = z def in_order_print(root): if not root: return in_order_print(root.l_child) print(root.data) in_order_print(root.r_child) r = Node(3) binary_insert(r, Node(7)) binary_insert(r, Node(1)) binary_insert(r, Node(5)) in_order_print(r) The problem, or at least one problem with your code is here:-
def insert(self,node,someNumber): if node is None: node = Node(someNumber) else: if node.data > someNumber: self.insert(node.rchild,someNumber) else: self.insert(node.rchild, someNumber) return You see the statement "if node.data > someNumber:" and the associated "else:" statement both have the same code after them. i.e you do the same thing whether the if statement is true or false.
I'd suggest you probably intended to do different things here, perhaps one of these should say self.insert(node.lchild, someNumber) ?
Another Python BST solution
class Node(object): def __init__(self, value): self.left_node = None self.right_node = None self.value = value def __str__(self): return "[%s, %s, %s]" % (self.left_node, self.value, self.right_node) def insertValue(self, new_value): """ 1. if current Node doesnt have value then assign to self 2. new_value lower than current Node's value then go left 2. new_value greater than current Node's value then go right :return: """ if self.value: if new_value < self.value: # add to left if self.left_node is None: # reached start add value to start self.left_node = Node(new_value) else: self.left_node.insertValue(new_value) # search elif new_value > self.value: # add to right if self.right_node is None: # reached end add value to end self.right_node = Node(new_value) else: self.right_node.insertValue(new_value) # search else: self.value = new_value def findValue(self, value_to_find): """ 1. value_to_find is equal to current Node's value then found 2. if value_to_find is lower than Node's value then go to left 3. if value_to_find is greater than Node's value then go to right """ if value_to_find == self.value: return "Found" elif value_to_find < self.value and self.left_node: return self.left_node.findValue(value_to_find) elif value_to_find > self.value and self.right_node: return self.right_node.findValue(value_to_find) return "Not Found" def printTree(self): """ Nodes will be in sequence 1. Print LHS items 2. Print value of node 3. Print RHS items """ if self.left_node: self.left_node.printTree() print(self.value), if self.right_node: self.right_node.printTree() def isEmpty(self): return self.left_node == self.right_node == self.value == None def main(): root_node = Node(12) root_node.insertValue(6) root_node.insertValue(3) root_node.insertValue(7) # should return 3 6 7 12 root_node.printTree() # should return found root_node.findValue(7) # should return found root_node.findValue(3) # should return Not found root_node.findValue(24) if __name__ == '__main__': main() def BinaryST(list1,key): start = 0 end = len(list1) print("Length of List: ",end) for i in range(end): for j in range(0, end-i-1): if(list1[j] > list1[j+1]): temp = list1[j] list1[j] = list1[j+1] list1[j+1] = temp print("Order List: ",list1) mid = int((start+end)/2) print("Mid Index: ",mid) if(key == list1[mid]): print(key," is on ",mid," Index") elif(key > list1[mid]): for rindex in range(mid+1,end): if(key == list1[rindex]): print(key," is on ",rindex," Index") break elif(rindex == end-1): print("Given key: ",key," is not in List") break else: continue elif(key < list1[mid]): for lindex in range(0,mid): if(key == list1[lindex]): print(key," is on ",lindex," Index") break elif(lindex == mid-1): print("Given key: ",key," is not in List") break else: continue size = int(input("Enter Size of List: ")) list1 = [] for e in range(size): ele = int(input("Enter Element in List: ")) list1.append(ele) key = int(input("\nEnter Key for Search: ")) print("\nUnorder List: ",list1) BinaryST(list1,key) class TreeNode: def __init__(self, value): self.value = value self.left = None self.right = None class BinaryTree: def __init__(self, root=None): self.root = root def add_node(self, node, value): """ Node points to the left of value if node > value; right otherwise, BST cannot have duplicate values """ if node is not None: if value < node.value: if node.left is None: node.left = TreeNode(value) else: self.add_node(node.left, value) else: if node.right is None: node.right = TreeNode(value) else: self.add_node(node.right, value) else: self.root = TreeNode(value) def search(self, value): """ Value will be to the left of node if node > value; right otherwise. """ node = self.root while node is not None: if node.value == value: return True # node.value if node.value > value: node = node.left else: node = node.right return False def traverse_inorder(self, node): """ Traverse the left subtree of a node as much as possible, then traverse the right subtree, followed by the parent/root node. """ if node is not None: self.traverse_inorder(node.left) print(node.value) self.traverse_inorder(node.right) def main(): binary_tree = BinaryTree() binary_tree.add_node(binary_tree.root, 200) binary_tree.add_node(binary_tree.root, 300) binary_tree.add_node(binary_tree.root, 100) binary_tree.add_node(binary_tree.root, 30) binary_tree.traverse_inorder(binary_tree.root) print(binary_tree.search(200)) if __name__ == '__main__': main()
