I have a bios update for my motherboard on the Gigabyte website and flashed it using qflash (because I had problems with my old bios).

After the update reached 100% my pc turned off automatically, which is normal. However, it did not turn back on automatically.

After 10 minutes I pressed the power button and the fan started spinning, with the led on in the motherboard; but after a couple seconds my computer turned itself back off.

How can I force my motherboard to boot in b_bios, which is the backup bios, by shorting the pins on the bios chip? Is his the best solution, or is there another way to recover my PC?

For reference, my motherboard is a Gigabyte B150M D3H DDR4 REV 1.

0

1 Answer

You said that you had problems with your old BIOS, but then you flashed a new BIOS. It sounds like you have a corrupted BIOS, and that is why you are asking to boot back into the backup BIOS.

Anyway, here is how you boot back into the backup BIOS:

Method 1

  1. Shut off your computer
  2. Hold the power button until your computer starts and shuts down again
  3. Press the power button again, your backup BIOS should kick in now and should re-flash the backup BIOS if there's anything wrong with the new one.

Method 2

  1. Shut off your computer
  2. Hold the power AND the reset button for about 10 sec, than release.
  3. It should boot into the backup BIOS now.

Method 3
Only use this if nothing else works.

  1. Short out pins 1 and 6 on the main BIOS chip by attaching a jumper to both the pins (pin #1 should be marked with a red dot or whatever)
  2. Tell a friend to press the power on button while you do this because right now you are holding the jumper on the pins
  3. Remove the jumper you're holding between pins 1 and 6 as soon as you hear a beep.
  4. Backup BIOS should boot now.
