How to fix ingress 404 default backend

I started to use Kubernetes few month ago and I actually migrate my microServices to my rancher cluster (RKE). Everything works good, my deployments are good and services too. I would like use ingress.

Everything looks good, services are find by ingress and pods are find by services. However when I try to go to the website, I have a 404 error page from ingress controller.

You can see my configuration for juste two paths : one nginx and on grafana. Someone knows how can i fix it and use ingress to do my reverse proxy ?

Thank you so much for your help.

I trie to use rewrite-target without result and add-base-url is deprecated.

apiVersion: extensions/v1beta1 kind: Ingress metadata: annotations: user-cg5r7 '{"bXktaW5ncmVzcy9kZWZhdWx0L3d3dy5zY29sLWVhLm92aC8vbmdpbngvNDI=":""}' '[{"addresses":["51.68.226.21"],"port":80,"protocol":"HTTP","serviceName":"default:nginx-services","ingressName":"default:my-ingress","hostname":"","path":"/nginx","allNodes":true}]' creationTimestamp: "2019-08-31T10:54:25Z" generation: 2 labels: or antoine name: my-ingress namespace: default resourceVersion: "106239" selfLink: /apis/extensions/v1beta1/namespaces/default/ingresses/my-ingress uid: b27b7b20-cbdd-11e9-b16b-fa163ea73397 spec: rules: - host: http: paths: - backend: serviceName: nginx-sample servicePort: 80 path: /nginx - backend: serviceName: prometheus-grafana servicePort: http path : /grafana ------------------------ apiVersion: v1 kind: Service metadata: annotations: '["deployment:default:nginx-sample"]' "true" "true" creationTimestamp: "2019-08-31T10:03:47Z" labels: norman name: nginx-sample namespace: default ownerReferences: - apiVersion: apps/v1beta2 controller: true kind: deployment name: nginx-sample uid: 57af9603-cb2a-11e9-b16b-fa163ea73397 resourceVersion: "102071" selfLink: /api/v1/namespaces/default/services/nginx-sample uid: 9fffe98c-cbd6-11e9-b16b-fa163ea73397 spec: clusterIP: 10.43.183.187 ports: - name: 80tcp02 port: 80 protocol: TCP targetPort: 80 selector: deployment-default-nginx-sample sessionAffinity: None type: ClusterIP ---------------------------- apiVersion: v1 kind: Service metadata: creationTimestamp: "2019-08-30T13:44:00Z" labels: app: prometheus-grafana chart: grafana-0.0.31 heritage: Tiller prometheus release: prometheus name: prometheus-grafana namespace: default resourceVersion: "2536" selfLink: /api/v1/namespaces/default/services/prometheus-grafana uid: 38ebd878-cb2c-11e9-b16b-fa163ea73397 spec: clusterIP: 10.43.142.143 ports: - name: http port: 80 protocol: TCP targetPort: 3000 selector: app: prometheus-grafana sessionAffinity: None type: ClusterIP

3 Answers

If you are using nginx as deployment proxy in the kubernetes and facing the issue then the below configuration can resolve the redirection issue.

Either you can include the below variables in the grafan.ini file or can expose as env variables as shown below,

GF_SERVER_DOMAIN=abc.google.com GF_SERVER_ROOT_URL=%(protocol)s://%(domain)s:/grafana

So the Grafana deployment will look like the below one.

 apiVersion: apps/v1 kind: Deployment metadata: name: grafana namespace: monitoring spec: replicas: 1 selector: matchLabels: app: grafana spec: containers: - name: grafana image: grafana/grafana:latest env: - name: GF_SERVER_DOMAIN value: "abc.google.com" - name: GF_SERVER_ROOT_URL value: "%(protocol)s://%(domain)s:/grafana" ports: - name: grafana containerPort: 3000 resources: limits: memory: "2Gi" cpu: "1000m" requests: memory: "1Gi" cpu: "500m" volumeMounts: - mountPath: /var/lib/grafana name: grafana-storage-volume - mountPath: /etc/grafana/provisioning/datasources name: grafana-datasources readOnly: false

And you have to update the nginx server location block as below,

 location /grafana { proxy_pass rewrite ^/grafana/(.*) /$1 break; proxy_set_header Host $host; }

Actually, Nginx Ingress Controller handles all requests that could not reach target location and sending them to default backend, resulting each request in default backend - 404 page.

Since you've decided to achieve path based routing scenario, rewrite rule can do the trick via annotation:

apiVersion: extensions/v1beta1 kind: Ingress metadata: annotations: /$2 labels: or antoine name: my-ingress namespace: default spec: rules: - host: http: paths: - backend: serviceName: nginx-sample servicePort: 80 path: /nginx(/|$)(.*) - backend: serviceName: prometheus-grafana servicePort: http path : /grafana(/|$)(.*)

Once you apply above Ingress manifest, the path based routing can be afforded in the following rewrite examples:

->

->

I wouldn't recommend to share any user sensitive data across published manifests or any other data objects, like public endpoint in your case.

I believe you should use HTTPS annotation in your yaml
