How to fix "503 Service Temporarily Unavailable"

FYI:

1. I run Kubernetes on docker desktop for mac
2. The website based on Nginx image

I run 2 simple website deployments on Kubetesetes and use the NodePort service. Then I want to make routing to the website using ingress. When I open the browser and access the website, I get an error 503 like images below. So, how do I fix this error?

### Service apiVersion: v1 kind: Service metadata: name: app-svc labels: app: app1 spec: type: NodePort ports: - port: 80 selector: app: app1 --- apiVersion: v1 kind: Service metadata: name: app2-svc labels: app: app2 spec: type: NodePort ports: - port: 80 selector: app: app2 ### Ingress-Rules apiVersion: extensions/v1beta1 kind: Ingress metadata: name: app-ingress annotations: / spec: rules: - http: paths: - path: /app1 backend: serviceName: app-svc servicePort: 30092 - path: /app2 backend: serviceName: app2-svc servicePort: 30936

enter image description here

5 Answers

Yes, i end up with same error. once i changed the service type to "ClusterIP", it worked fine for me.

Found this page after searching for a solution to nginx continually returning 503 responses despite the service names all being configured correctly. The issue for me was that I had configured the kubernetes service in a specific namespace, but did not update the ingress component to be in the same namespace. Despite being such a simple solution it was not at all obvious!

I advise you to use service type ClusterIP Take look on this useful article: services-kubernetes.

If you use Ingress you have to know that Ingress isn’t a type of Service, but rather an object that acts as a reverse proxy and single entry-point to your cluster that routes the request to different services. The most basic Ingress is the NGINX Ingress Controller, where the NGINX takes on the role of reverse proxy, while also functioning as SSL. On below drawing you can see workflow between specific components of environment objects.

Ingress is exposed to the outside of the cluster via ClusterIP and Kubernetes proxy, NodePort, or LoadBalancer, and routes incoming traffic according to the configured rules.

Example of service definition:

--- apiVersion: v1 kind: Service metadata: name: app-svc labels: app: app1 spec: type: ClusterIP ports: - port: 80 selector: app: app1 --- apiVersion: v1 kind: Service metadata: name: app2-svc labels: app: app2 spec: type: ClusterIP ports: - port: 80 selector: app: app2

Let me know if it helps.

First, You need to change the service type of your app-service to ClusterIP, because the Ingress object is going to access these Pods(services) from inside the cluster. (ClusterIP service is used when you want to allow accessing a pod inside a cluster).

Second, Make sure the services are running by running kubectl get services and check the running services names against the names in backend section in Ingress routing rules

Little late to this journey but here is my comment on the issue. I was having the same issue and having the same environment. (Docker Desktop-based Kubernetes with WSL2)

a couple of items probably can help.

1. add the host entry in the rules section. and the value will be kubernetes.docker.internal like below

rules: - host: kubernetes.docker.internal http: paths: - path....

2. check the endpoints using kubectl get services to confirm that the same port is in your ingress rule definition for each of those backend services.

backend: service: name: my-apple-service port: number: 30101

kubectl get services

NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE my-apple-service ClusterIP 10.106.121.95 <none> 30101/TCP 9h my-banada-service ClusterIP 10.99.192.112 <none> 30101/TCP 9h
