I'm using LEMP stack and Node JS on my debian server. Nginx works on port 80 and Node JS on 8080. I created new subdomain: cdn.domain.com for nodejs app. Currently I can access to Node JS application only like cdn.domain.com:8080/. What I want to do is to configure Nginx so that, when I enter to cdn.domain.com I can get app working on port 80. I think it can be done using nginx upstream. But I can't figure out how.

1

7 Answers

As simple as like this,

make sure to change example.com to your domain (or IP), and 8080 to your Node.js application port:

server { listen 80; server_name example.com; location / { proxy_set_header X-Forwarded-For $remote_addr; proxy_set_header Host $http_host; proxy_pass ""; } }

Source:

5

NGINX supports WebSockets by allowing a tunnel to be setup between a client and a backend server. In order for NGINX to send the Upgrade request from the client to the backend server, Upgrade and Connection headers must be set explicitly. For example:

# WebSocket proxying map $http_upgrade $connection_upgrade { default upgrade; '' close; } server { listen 80; # The host name to respond to server_name cdn.domain.com; location / { # Backend nodejs server proxy_pass proxy_http_version 1.1; proxy_set_header Upgrade $http_upgrade; proxy_set_header Connection $connection_upgrade; } }

Source:

1

you can do this very easy by using following in sudo vi /etc/nginx/sites-available/default

server { listen 80 default_server; listen [::]:80 default_server; server_name _ your_domain; location /health { access_log off; return 200 "healthy\n"; } location / { proxy_pass proxy_http_version 1.1; proxy_set_header Upgrade $http_upgrade; proxy_set_header Connection 'upgrade'; proxy_set_header Host $host; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_cache_bypass $http_upgrade; } }

Simple is:

server { listen 80; server_name p3000; location / { proxy_pass include /etc/nginx/proxy_params; } }
1

This is how you can achieve this.

upstream { nodeapp 127.0.0.1:8080; } server { listen 80; # The host name to respond to server_name cdn.domain.com; location /(.*) { proxy_pass proxy_set_header X-Real-IP $remote_addr; proxy_set_header X-Forwarded-For $remote_addr; proxy_set_header Host $host; proxy_set_header X-Real-Port $server_port; proxy_set_header X-Real-Scheme $scheme; } }

You can also use this configuration to load balance amongst multiple Node processes like so:

upstream { nodeapp 127.0.0.1:8081; nodeapp 127.0.0.1:8082; nodeapp 127.0.0.1:8083; }

Where you are running your node server on ports 8081, 8082 and 8083 in separate processes. Nginx will easily load balance your traffic amongst these server processes.

2

You can define an upstream and use it in proxy_pass

server { listen 8082; location ~ /(.*) { proxy_pass test_server; proxy_set_header Host $host; proxy_set_header X-Real-IP $remote_addr; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_set_header X-Forwarded-Proto $scheme; proxy_redirect off; } } upstream test_server { server test-server:8989 }
1

This worked for me:

server { listen 80; server_name example.com location / { proxy_pass proxy_set_header Host $host; proxy_set_header X-Real-IP $remote_addr; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; } }

If it does not work for you look at the logs at sudo tail -f /var/log/nginx/error.log
