Fastest way to get square root in float value

I am trying to find a fastest way to make square root of any float number in C++. I am using this type of function in a huge particles movement calculation like calculation distance between two particle, we need a square root etc. So If any suggestion it will be very helpful. I have tried and below is my code

#include <math.h> #include <iostream> #include <chrono> using namespace std; using namespace std::chrono; #define CHECK_RANGE 100 inline float msqrt(float a) { int i; for (i = 0;i * i <= a;i++); float lb = i - 1; //lower bound if (lb * lb == a) return lb; float ub = lb + 1; // upper bound float pub = ub; // previous upper bound for (int j = 0;j <= 20;j++) { float ub2 = ub * ub; if (ub2 > a) { pub = ub; ub = (lb + ub) / 2; // mid value of lower and upper bound } else { lb = ub; ub = pub; } } return ub; } void check_msqrt() { for (size_t i = 0; i < CHECK_RANGE; i++) { msqrt(i); } } void check_sqrt() { for (size_t i = 0; i < CHECK_RANGE; i++) { sqrt(i); } } int main() { auto start1 = high_resolution_clock::now(); check_msqrt(); auto stop1 = high_resolution_clock::now(); auto duration1 = duration_cast<microseconds>(stop1 - start1); cout << "Time for check_msqrt = " << duration1.count() << " micro secs\n"; auto start2 = high_resolution_clock::now(); check_sqrt(); auto stop2 = high_resolution_clock::now(); auto duration2 = duration_cast<microseconds>(stop2 - start2); cout << "Time for check_sqrt = " << duration2.count() << " micro secs"; //cout << msqrt(3); return 0; }

output of above code showing the implemented method 4 times more slow than sqrt of math.h file. I need faster than math.h version.

3 Answers

In short, I do not think it is possible to implement something generally faster than the standard library version of sqrt.

Performance is a very important parameter when implementing standard library functions and it is fair to assume that such a commonly used function as sqrt is optimized as much as possible.

Beating the standard library function would require a special case, such as:

• Availability of a suitable assembler instruction - or other specialized hardware support - on the particular system for which the standard library has not been specialized.
• Knowledge of the needed range or precision. The standard library function must handle all cases specified by the standard. If the application only needs a subset of that or maybe only requires an approximate result then perhaps an optimization is possible.
• Making a mathematical reduction of the calculations or combine some calculation steps in a smart way so an efficient implementation can be made for that combination.

Here's another alternative to binary search. It may not be as fast as std::sqrt, haven't tested it. But it will definitely be faster than your binary search.

auto Sqrt(float x) { using F = decltype(x); if (x == 0 || x == INFINITY || isnan(x)) return x; if (x < 0) return F{NAN}; int e; x = std::frexp(x, &e); if (e % 2 != 0) { ++e; x /= 2; } auto y = (F{-160}/567*x + F{2'848}/2'835)*x + F{155}/567; y = (y + x/y)/2; y = (y + x/y)/2; return std::ldexp(y, e/2); }

After getting +/-0, nan, inf, and negatives out of the way, it works by decomposing the float into a mantissa in the range of [¹/₄, 1) times 2^e where e is an even integer. The answer is then sqrt(mantissa)* 2^e/₂.

Finding the sqrt of the mantissa can be guessed at with a least squares quadratic curve fit in the range [¹/₄, 1]. Then that good guess is refined by two iterations of Newton–Raphson. This will get you within 1 ulp of the correctly rounded result. A good std::sqrt will typically get that last bit correct.

I have also tried with the algorithm mention in , but not found desired result, please check

#include <math.h> #include <iostream> #include <chrono> #include <bit> #include <limits> #include <cstdint> using namespace std; using namespace std::chrono; #define CHECK_RANGE 10000 inline float msqrt(float a) { int i; for (i = 0;i * i <= a;i++); float lb = i - 1; //lower bound if (lb * lb == a) return lb; float ub = lb + 1; // upper bound float pub = ub; // previous upper bound for (int j = 0;j <= 20;j++) { float ub2 = ub * ub; if (ub2 > a) { pub = ub; ub = (lb + ub) / 2; // mid value of lower and upper bound } else { lb = ub; ub = pub; } } return ub; } /* mentioned here -> */ inline float Q_sqrt(float number) { union Conv { float f; uint32_t i; }; Conv conv; conv.f= number; conv.i = 0x5f3759df - (conv.i >> 1); conv.f *= 1.5F - (number * 0.5F * conv.f * conv.f); return 1/conv.f; } void check_Qsqrt() { for (size_t i = 0; i < CHECK_RANGE; i++) { Q_sqrt(i); } } void check_msqrt() { for (size_t i = 0; i < CHECK_RANGE; i++) { msqrt(i); } } void check_sqrt() { for (size_t i = 0; i < CHECK_RANGE; i++) { sqrt(i); } } int main() { auto start1 = high_resolution_clock::now(); check_msqrt(); auto stop1 = high_resolution_clock::now(); auto duration1 = duration_cast<microseconds>(stop1 - start1); cout << "Time for check_msqrt = " << duration1.count() << " micro secs\n"; auto start2 = high_resolution_clock::now(); check_sqrt(); auto stop2 = high_resolution_clock::now(); auto duration2 = duration_cast<microseconds>(stop2 - start2); cout << "Time for check_sqrt = " << duration2.count() << " micro secs\n"; auto start3 = high_resolution_clock::now(); check_Qsqrt(); auto stop3 = high_resolution_clock::now(); auto duration3 = duration_cast<microseconds>(stop3 - start3); cout << "Time for check_Qsqrt = " << duration3.count() << " micro secs\n"; //cout << Q_sqrt(3); //cout << sqrt(3); //cout << msqrt(3); return 0; }
