Error when trying to produce a Graph in Plotly Dash

When trying to produce a figure with the following code

@app.callback( [ Output("selected-plot", "figure") ], [ Input("submit-selected-plotting", "n_clicks"), State("table", "data") ], ) def plot(button_clicked, data) fig = go.Scatter(x=data["index"], y=data["result"], mode='lines', name='result') return fig

and

 dbc.Col( [ dcc.Graph(id='selected-plot') ], width=6, )

I get a strange error with the app expecting a different object:

dash._grouping.SchemaTypeValidationError: Schema: [<Output selected-plots.figure>] Path: () Expected type: (<class 'tuple'>, <class 'list'>) Received value of type <class 'plotly.graph_objs._scatter.Scatter'>: Scatter({...})

I have tried everything but I can't seem to go around this error. Thanks for any suggestions in advance!

1 Answer

The error is due to the fact that the app expects a figure object, you can fix it by updating the callback as follows:

@app.callback( [ Output("selected-plot", "figure") ], [ Input("submit-selected-plotting", "n_clicks"), State("table", "data") ], ) def plot(button_clicked, data) trace = go.Scatter( x=data["index"], y=data["result"], mode='lines', name='result' ) return [go.Figure(data=trace)]
