Dropping nan values from an xarray dataset not working, possibly due to smoothing with a rolling mean

A lot of text, but mostly it is self contained examples. Any help is appreciated.

I have an xarray dataset with Range and time coordinates, and for each time I want to find the Range where the backscatter gradient is the minimum. However, I am running into the ValueError: All-NaN slice encountered, I think this might be because I am smoothing my data first with a rolling mean, but I am not certain. My approach is as follows:

1. create a new data variable for the gradient of backscatter using da.differentiate(coord = 'Range')
2. Get the locations of the minimums in this gradient using min_height = ds['bs_grad'].argmin(dim='Range').values, and min_height = ds['Range'].isel(Range=min_height). This throws the error. To address this I tried da.dropna() along both time and Range coordinates individually with no success. Here are two examples, the first one works, the second one replicates the problem I am encountering in my actual data set.

The approach works fine on a simple xarray, as seen below.

import pandas as pd import numpy as np import xarray as xr import matplotlib.pyplot as plt # create a sample DataArray ds = xr.DataArray([[7, 6, 8, np.nan, 9], [9, 6, 2, np.nan, 4], [3, 4, 1, np.nan, 1]], dims=['Range', 'time'], coords={ 'Range': [10, 20, 30], 'time': ['2022-01-01', '2022-01-02', '2022-01-03', '2022-01-04', '2022-01-05'] } ) plt.pcolormesh(ds['time'], ds['Range'], ds, shading = 'auto') plt.colorbar() plt.gcf().autofmt_xdate() plt.title('xarray') plt.show() ds['bs_grad'] = ds.differentiate(coord = 'Range') plt.pcolormesh(ds['time'], ds['Range'], ds['bs_grad'], shading = 'auto') plt.colorbar() plt.gcf().autofmt_xdate() plt.title('gradient') plt.show() ds = ds.dropna(dim = 'time', how = 'all') ds = ds.dropna(dim = 'Range', how = 'all') plt.pcolormesh(ds['time'], ds['Range'], ds['bs_grad'], shading = 'auto') plt.colorbar() plt.gcf().autofmt_xdate() plt.title('grad, nan dropped') plt.show() ## find the Range of the minimum backscatter for each time step min_Range = ds['bs_grad'].argmin(dim='Range').values # get the index of the minimum backscatter min_Range = ds['Range'].isel(Range=min_Range) # extract the corresponding Range plt.scatter(ds['time'], min_Range), plt.gcf().autofmt_xdate() plt.show()

However, the same approach fails for the example below.

import pandas as pd import numpy as np import xarray as xr import matplotlib.pyplot as plt min_date = "2023-03-01" max_date = "2023-04-20" dates = pd.date_range(min_date, max_date) # Define the dimensions Range = np.arange(0, 1000, 50) time = dates # Create the data array with variables for backscatter, temperature, and humidity data = xr.DataArray( np.random.rand(len(Range), len(time)), # random data for demonstration purposes dims=("Range", "time"), coords={"Range": Range, "time": time}, attrs={"long_name": "example data array"}, ) backscatter = xr.DataArray( np.random.rand(len(Range), len(time)), # random data for demonstration purposes dims=("Range", "time"), coords={"Range": Range, "time": time}, attrs={"long_name": "backscatter", "units": "dB"}, ) temperature = xr.DataArray( np.random.rand(len(Range), len(time))*20, # random data for demonstration purposes dims=("Range", "time"), coords={"Range": Range, "time": time}, attrs={"long_name": "temperature", "units": "K"}, ) humidity = xr.DataArray( np.random.rand(len(Range), len(time))*100, # random data for demonstration purposes dims=("Range", "time"), coords={"Range": Range, "time": time}, attrs={"long_name": "humidity", "units": "%"}, ) # Combine the data arrays into a single xarray dataset ds = xr.Dataset( {"data": data, "backscatter": backscatter, "temperature": temperature, "humidity": humidity} ) plt.pcolormesh(ds['time'], ds['Range'], ds['backscatter'], shading = 'auto', vmin = 0) plt.colorbar() plt.gcf().autofmt_xdate() plt.xlabel('time') plt.ylabel('Range') plt.show() ## Smooth the data with a rolling mean ds['backscatter'] = ds['backscatter'].rolling( Range = 5, center=True).mean().rolling( time = 5, center=True).mean() plt.pcolormesh(ds['time'], ds['Range'], ds['backscatter'], shading = 'auto', vmin = 0) plt.colorbar() plt.gcf().autofmt_xdate() plt.xlabel('time') plt.ylabel('Range') plt.show() ## Artificially add some nan columns, rows, and min gradient ## Set a clear min gradient ds = ds.where(ds['Range'] != 800, other= -20000) ## Set values equal to nan to siumulate problem I'm running into ds = ds.where(ds['time'] != pd.to_datetime('2023-04-01'), np.nan) ds = ds.where(ds['time'] != pd.to_datetime('2023-04-03'), np.nan) ds = ds.where(ds['time'] != pd.to_datetime('2023-03-12'), np.nan) ds = ds.where(ds['Range'] != 550, np.nan) ds = ds.where(ds['Range'] != 300, np.nan) plt.pcolormesh(ds['time'], ds['Range'], ds['backscatter'], shading = 'auto', vmin = 0) plt.colorbar() plt.gcf().autofmt_xdate() plt.xlabel('time') plt.ylabel('Range') plt.show() ## Calculate the gradient ds['bs_grad'] = ds['backscatter'].differentiate(coord = 'Range') plt.pcolormesh(ds['time'], ds['Range'], ds['bs_grad'], shading = 'auto') plt.colorbar() plt.gcf().autofmt_xdate() plt.xlabel('time') plt.ylabel('Range') plt.show() ## Drop nan values ds = ds.dropna(dim = 'time', how = 'all') ## Works ds = ds.dropna(dim = 'Range', how = 'all') ## Does nothing ? plt.pcolormesh(ds['time'], ds['Range'], ds['bs_grad'], shading = 'auto') plt.colorbar() plt.gcf().autofmt_xdate() plt.xlabel('time') plt.ylabel('Range') plt.show() ## Try to find location of the minimum values as in example 1. min_height = ds['bs_grad'].argmin(dim='Range').values # get the index of the minimum backscatter display(min_height) min_height = ds['Range'].isel(Range=min_height) # extract the corresponding height display(min_height) plt.scatter(ds['time'], min_height), plt.gcf().autofmt_xdate() plt.show()

Thanks, and have a nice day.

1 Answer

You can take the argmin of an array with nans by first filling nans with a dummy value (e.g. np.inf):

da.fillna(np.inf).argmin(dim=dimname)

The result will return the first value for any slices with all nans, so you may want to mask the result to exclude these values:

mins = da.fillna(np.inf).argmin(dim=dimname) mins = mins.where(da.notnull().any(dim=dimname))
