I have a K8S pod. Inside pod, I do dns lookup using nslookup. It works fine. But when I do tcpdump on pod interface (eth0), it clearly shows received dns response has bad udp checksum. I checked with netstat the udp counters, but I dont see the checksum error counter (InCsumErrors) at all getting hit. Here are some relevant outputs.
IP config of pod:
root@node:~# ip addr 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever 2: tunl0@NONE: <NOARP> mtu 1480 qdisc noop state DOWN group default qlen 1000 link/ipip 0.0.0.0 brd 0.0.0.0 4: eth0@if10936: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether e2:22:5c:6c:53:bd brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 10.233.85.177/32 scope global eth0 valid_lft forever preferred_lft forever Successfull Nslookup:
bash-4.4# nslookup google.com Server: 169.254.25.10 Address: 169.254.25.10#53 Non-authoritative answer: Name: google.com Address: 216.58.207.238 Name: google.com Address: 2a00:1450:400e:809::200e Tcpdump showing bad udp cksum for above nslookup run:
root@node:~# tcpdump -ni eth0 -vvv tcpdump: listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes 16:02:24.267999 IP (tos 0x0, ttl 64, id 50356, offset 0, flags [none], proto UDP (17), length 82) 10.233.85.177.52764 > 169.254.25.10.53: [bad udp cksum 0x23f2 -> 0xd1bd!] 43806+ A? google.com.qaammuk.svc.cluster.local. (54) 16:02:24.269489 IP (tos 0x0, ttl 64, id 56987, offset 0, flags [DF], proto UDP (17), length 175) 169.254.25.10.53 > 10.233.85.177.52764: [bad udp cksum 0x244f -> 0x2c2a!] 43806 NXDomain*- q: A? google.com.qaammuk.svc.cluster.local. 0/1/0 ns: cluster.local. [5s] SOA ns.dns.cluster.local. hostmaster.cluster.local. 1609862082 7200 1800 86400 5 (147) 16:02:24.269847 IP (tos 0x0, ttl 64, id 50357, offset 0, flags [none], proto UDP (17), length 74) 10.233.85.177.39433 > 169.254.25.10.53: [bad udp cksum 0x23ea -> 0xac65!] 45029+ A? google.com.svc.cluster.local. (46) 16:02:24.270901 IP (tos 0x0, ttl 64, id 56988, offset 0, flags [DF], proto UDP (17), length 167) 169.254.25.10.53 > 10.233.85.177.39433: [bad udp cksum 0x2447 -> 0x06d2!] 45029 NXDomain*- q: A? google.com.svc.cluster.local. 0/1/0 ns: cluster.local. [5s] SOA ns.dns.cluster.local. hostmaster.cluster.local. 1609862082 7200 1800 86400 5 (139) 16:02:24.271206 IP (tos 0x0, ttl 64, id 50358, offset 0, flags [none], proto UDP (17), length 70) 10.233.85.177.59330 > 169.254.25.10.53: [bad udp cksum 0x23e6 -> 0xdaca!] 2633+ A? google.com.cluster.local. (42) 16:02:24.272262 IP (tos 0x0, ttl 64, id 56989, offset 0, flags [DF], proto UDP (17), length 163) 169.254.25.10.53 > 10.233.85.177.59330: [bad udp cksum 0x2443 -> 0x3537!] 2633 NXDomain*- q: A? google.com.cluster.local. 0/1/0 ns: cluster.local. [5s] SOA ns.dns.cluster.local. hostmaster.cluster.local. 1609862082 7200 1800 86400 5 (135) 16:02:24.272527 IP (tos 0x0, ttl 64, id 50359, offset 0, flags [none], proto UDP (17), length 56) 10.233.85.177.53873 > 169.254.25.10.53: [bad udp cksum 0x23d8 -> 0x278c!] 52759+ A? google.com. (28) 16:02:24.272707 IP (tos 0x0, ttl 64, id 56990, offset 0, flags [DF], proto UDP (17), length 82) 169.254.25.10.53 > 10.233.85.177.53873: [bad udp cksum 0x23f2 -> 0xe468!] 52759* q: A? google.com. 1/0/0 google.com. [8s] A 216.58.211.110 (54) 16:02:24.272963 IP (tos 0x0, ttl 64, id 50360, offset 0, flags [none], proto UDP (17), length 56) 10.233.85.177.54691 > 169.254.25.10.53: [bad udp cksum 0x23d8 -> 0x370f!] 47943+ AAAA? google.com. (28) 16:02:24.273141 IP (tos 0x0, ttl 64, id 56991, offset 0, flags [DF], proto UDP (17), length 94) 169.254.25.10.53 > 10.233.85.177.54691: [bad udp cksum 0x23fe -> 0xf8e0!] 47943* q: AAAA? google.com. 1/0/0 google.com. [8s] AAAA 2a00:1450:400e:809::200e (66) netstat output to show udp counters from linux stack. No InCsumErrors:
root@node:~# netstat -s -u Udp: 18 packets received 0 packets to unknown port received 0 packet receive errors 18 packets sent 0 receive buffer errors 0 send buffer errors UdpLite: IpExt: InOctets: 2130 OutOctets: 1101 InNoECTPkts: 18 I tried both with checksum offload enabled and disable on eth0. Same behavior in both cases.
Shouldn't bad udp checksum detected by tcpdump mean that kernel will at some point drop udp packets before handing them over to the socket bound to nslookup?
2 Answers
When you do nslookup google.com 8.8.8.8 everything looks fine. I think that this because since you are using coredns to resolve the domains, the packets run through a Service.
Service in k8s is a virtual entity. It appears as a forwarding rule in iptables. During forwarding process, source ip address is swapped out without recalculating the cksum, thus the error in tcpdump.
And according to RFC 768, UDP checksum is defined as following:
Checksum is the 16-bit one's complement of the one's complement sum of a pseudo header of information from the IP header, the UDP header, and the data
So as you see, IP header also is a part of a checksum and so is the source IP that is swapped out and this is changing the checksum.
Calculating the checksum is usually done using hardware acceleration of NIC before sending/receiving packets to a node. It would require a lot of computation just to compute checksums of all packets doing through iptables. And also it is useless because once you receive a packet on a node's network interface and you confirm that it's valid, you can be sure that it will stay valid within the node even after you forward it with iptables.
Does K8S setup some rules for linux kernel to ignore bad udp checksums for pod interfaces?
I know that e.g. loopback interface does not checksum packets (at least not by default). Maybe brigde interfaces (e.g. docker0 and veth*) also doesn't checksum. I tried to find a strong evidence to prove this statement but I didn't find anything to either prove it or disprove it.
3try:
ethtool --offload eth0 rx off tx off ethtool -K eth0 gso off
