Autograd.grad() for Tensor in pytorch

I want to compute the gradient between two tensors in a net. The input X tensor (batch size x m) is sent through a set of convolutional layers which give me back and output Y tensor(batch size x n).

I’m creating a new loss and I would like to know the gradient of Y w.r.t. X. Something that in tensorflow would be like:

tf.gradients(ys=Y, xs=X)

Unfortunately, I’ve been making tests with torch.autograd.grad(), but I could not figure out how to do it. I get errors like: “RunTimeerror: grad can be implicitly created only for scalar outputs”.

What should be the inputs in torch.autograd.grad() if I want to know the gradient of Y w.r.t. X?

1 Answer

Let's start from simple working example with plain loss function and regular backward. We will build short computational graph and do some grad computations on it.

Code:

import torch from torch.autograd import grad import torch.nn as nn # Create some dummy data. x = torch.ones(2, 2, requires_grad=True) gt = torch.ones_like(x) * 16 - 0.5 # "ground-truths" # We will use MSELoss as an example. loss_fn = nn.MSELoss() # Do some computations. v = x + 2 y = v ** 2 # Compute loss. loss = loss_fn(y, gt) print(f'Loss: {loss}') # Now compute gradients: d_loss_dx = grad(outputs=loss, inputs=x) print(f'dloss/dx:\n {d_loss_dx}')

Output:

Loss: 42.25 dloss/dx: (tensor([[-19.5000, -19.5000], [-19.5000, -19.5000]]),)

Ok, this works! Now let's try to reproduce error "grad can be implicitly created only for scalar outputs". As you can notice, loss in previous example is a scalar. backward() and grad() by defaults deals with single scalar value: loss.backward(torch.tensor(1.)). If you try to pass tensor with more values you will get an error.

Code:

v = x + 2 y = v ** 2 try: dy_hat_dx = grad(outputs=y, inputs=x) except RuntimeError as err: print(err)

Output:

grad can be implicitly created only for scalar outputs

Therefore, when using grad() you need to specify grad_outputs parameter as follows:

Code:

v = x + 2 y = v ** 2 dy_dx = grad(outputs=y, inputs=x, grad_outputs=torch.ones_like(y)) print(f'dy/dx:\n {dy_dx}') dv_dx = grad(outputs=v, inputs=x, grad_outputs=torch.ones_like(v)) print(f'dv/dx:\n {dv_dx}')

Output:

dy/dx: (tensor([[6., 6.],[6., 6.]]),) dv/dx: (tensor([[1., 1.], [1., 1.]]),)

NOTE: If you are using backward() instead, simply do y.backward(torch.ones_like(y)).
