Asterisk reached but can't register

I'm new at asterisk and following asterisk example:
sip.conf

[general] transport=udp [friends_internal](!) type=friend host=dynamic context=from-internal disallow=all allow=ulaw [demo-alice](friends_internal) secret=verysecretpassword qualify=yes ; put a strong, unique password here instead qualify=yes [demo-bob](friends_internal) secret=othersecretpassword ; put a strong, unique password here instead

And this is pjsip.conf:

[transport-udp] type=transport protocol=udp bind=0.0.0.0 ;Templates for the necessary config sections [endpoint_internal](!) type=endpoint context=from-internal disallow=all allow=ulaw [auth_userpass](!) type=auth auth_type=userpass [aor_dynamic](!) type=aor max_contacts=1 ;Definitions for our phones, using the templates above [demo-alice](endpoint_internal) auth=demo-alice aors=demo-alice [demo-alice](auth_userpass) password=unsecurepassword ; put a strong, unique password here instead username=demo-alice [demo-alice](aor_dynamic) [demo-bob](endpoint_internal) auth=demo-bob aors=demo-bob [demo-bob](auth_userpass) password=unsecurepassword ; put a strong, unique password here instead username=demo-bob [demo-bob](aor_dynamic)

I used Ekiga softphone to login demo-alice account:

ubuntu*CLI> -- Added contact 'sip:[email protected]:5060' to AOR 'demo-alice' with expiration of 3600 seconds == Contact demo-alice/sip:[email protected]:5060 has been created == Endpoint demo-alice is now Reachable -- Contact demo-alice/sip:[email protected]:5060 is now Unknown. RTT: 0.000 msec [Oct 25 16:40:10] WARNING[16587]: res_pjsip_pubsub.c:3134 pubsub_on_rx_publish_request: No registered publish handler for event presence [Oct 25 16:40:10] WARNING[16587]: res_pjsip_pubsub.c:3134 pubsub_on_rx_publish_request: No registered publish handler for event presence ubuntu*CLI> sip show peers Name/username Host Dyn Forcerport Comedia ACL Port Status Description demo-alice (Unspecified) D Auto (No) No 0 Unmonitored demo-bob (Unspecified) D Auto (No) No 0 Unmonitored 2 sip peers [Monitored: 0 online, 0 offline Unmonitored: 0 online, 2 offline] ubuntu*CLI>

Ekiga show I already registered but Asterisk server didn't. It said: Reached but status is Unknown or Unmonitored with Unspecified IP. Help!!!
I'm using Ubuntu 16.04 and Asterisk 13.11.2 in Ubuntu server 16.04.

1 Answer

You propably want to use chan_sip OR chan_pjsip.

Check modules.conf to prevent one of them from loading...

In your CLI it seems, ekiga is registered on chan_pjsip.

So try "pjsip show endpoints" (-> chan_pjsip) instead of "sip show peers" (-> chan_sip).
