I am new to Python.
I have generated a boxplot (with a swarmplot overlay) in matplotlib/seaborn using the following code. I would now like to add a legend that follows the color scheme of each box. Many solutions I find online does not seem to apply to this particular type of graph (eg. only work with grouped boxplots).
When I try to implement the code suggested here I receive the error message.
All input is greatly appreciated!
# Import libraries and modules import pandas as pd import numpy as np import matplotlib.pyplot as plt import seaborn as sns # Set seaborn style. sns.set(style="whitegrid", palette="colorblind") # Load summary tidy data. tidy = pd.read_csv('tidy.csv') # Define plots for tidy data fig, ax = plt.subplots(figsize=(10,6)) ax = sns.boxplot(x='header1', y='header2', data=tidy, order=["header1", "header2"]) ax = sns.swarmplot(x="header1", y="header2", data=tidy, color=".25", order=["header1", "header2"]) labels = [item.get_text() for item in ax.get_xticklabels()] labels[0] = 'header1' labels[1] = 'header2' ax.set_xticklabels(labels) ax.legend(loc='best') Example of the data I am working with.
Object,Metric,Length MT1,B2A1,3.57675 MT1,B2A2,2.9474600000000004 MT1,B2A3,2.247772857142857 MT1,B2A4,3.754455 MT1,B2A5,2.716282 MT1,B2A6,2.91325 MT10,B2A1,3.34361 MT10,B2A2,2.889958333333333 MT10,B2A3,2.22087 MT10,B2A4,2.87669 MT10,B2A5,1.6745005555555557 MT12,B2A1,3.3938900000000003 MT12,B2A2,2.00601 MT12,B2A3,2.1720200000000003 MT12,B2A4,2.452923333333333 1 Answer
The no handles with labels found to put in the legend error is due to calling ax.legend() while your two artists (boxplot and swarmplot) do not have a label.
sns.boxplot is based on matplotlib's boxplot and sns.swarmplot on scatter, so all you need is to give them respectively a labels and label argument.
ax = sns.boxplot(..., labels=["Metric", "Length"]) ax = sns.swarmplot(..., label="something goes here") Alternatively, according to this you can leave the seaborn part untouched and fiddle with:
handles, _ = ax.get_legend_handles_labels() # Get the artists. ax.legend(handles, ["label1", "label2"], loc="best") # Associate manually the artists to a label.
