I need some help to create a .bat file which need to:
1) Access 192.168.0.1 or tplinklogin.net (my wi-fi router address)
2) Type/insert user and password
3) Click/run "Disconnect" wait 1-3 sec
4) Click/run "Connect" wait 3-5 sec
5) Click/run "Refresh" - not really necessary
6) Exit
1 Answer
I found this link, which seems more or less to answer the problem, though the Linux script above it worked rather better. I found that the process termination code towards the end didn't work properly, so I took it out and all was well. I also changed the service commands in line with the discussion below and finished up with:-
set WshShell = WScript.CreateObject("WScript.Shell") WshShell.Run "cmd" WScript.Sleep 100 WshShell.AppActivate "C:\Windows\system32\cmd.exe" WScript.Sleep 1000 WshShell.SendKeys "telnet 192.168.0.1~" WScript.Sleep 1000 WshShell.SendKeys "admin~" WScript.Sleep 1000 WshShell.SendKeys "admin~" WScript.Sleep 2000 WshShell.SendKeys "wan set service pppoa_0_38_0_d --protocol pppoa --conntrigger manual~" WScript.Sleep 12000 WshShell.SendKeys "~" WScript.Sleep 1000 WshShell.SendKeys "wan set service pppoa_0_38_0_d --protocol pppoa --conntrigger always~" WScript.Sleep 6000 WshShell.SendKeys "~" WScript.Sleep 1000 WshShell.SendKeys "logout~" WScript.Sleep 6000 WshShell.SendKeys "~" WScript.Sleep 1000 WshShell.SendKeys "exit~" You simply copy this to a file with a .vbs suffix, edit it to update the router's IP address, the log-in user and password, and the service name and protocol. For the latter you will need to log into telnet manually and type:
wan show service In your cmd script, invoke the edited script with:
start [/wait] reconnect.vbs Use /wait if you want the script to complete before you continue to the next command.
One problem I found is that if called while the router is on-line it leaves it in a disconnected state, but increasing the delay between the two service calls fixed this, and you may need to tweak this or some of the other delays.
